Operation & Safety
Manual
Original Instructions -
Keep this manual with the machine at all times.
RT5394
PVC 2304
31221547
December 2, 2024 - Rev D
Copyright ©
ANSI
AS/NZS MOL70 GB
English (en-US)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RT5394 and is the answer not in the manual?

Questions and answers

Related Manuals for JLG RT5394

Summary of Contents for JLG RT5394

  • Page 1 Operation & Safety Manual Original Instructions - Keep this manual with the machine at all times. RT5394 PVC 2304 31221547 December 2, 2024 - Rev D Copyright © ANSI AS/NZS MOL70 GB English (en-US)
  • Page 2 WARNING Operating, servicing and maintaining this vehicle or equipment can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other repro- ductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle or equipment in a well-ventilated area and wear gloves or wash your hands frequently when servicing.

  • Page 3: Foreword

    Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without prior notification. Contact JLG Industries, Inc. for updated information.
  • Page 4 Indicates a potentially hazardous situation. If not avoided, may result in minor or moderate injury. It may also alert against unsafe practices. This decal will have a yellow background. NOTICE Indicates information or a company policy that relates directly or indirectly to the safety of personnel or protection of property. 3122154700 RT5394...
  • Page 5 NOTICE JLG Industries, Inc. sends safety related bulletins to the owner of record of this machine. Contact JLG Industries, Inc. to ensure that the current owner records are updated and accurate.
  • Page 6 Questions Regarding Product Modifications Contact: Product Safety and Reliability Department JLG Industries, Inc. 13224 Fountainhead Plaza Hagerstown, MD 21742 or Visit www.jlg.com to find your local JLG office. In USA: Toll Free: 877-JLG-SAFE (877-554-7233) Outside USA: Phone: 240-420-2661 Fax: 301-745-3713 E-mail: ProductSafety@JLG.com...

  • Page 7: Revision Log

    REVISION LOG Description Date Revision April 10, 2023 Original Issue July 19, 2023 Revision October 9, 2023 Revision December 2, 2024 Revision Other Publications Available Publication Publication Number Service & Maintenance Manual 31221548 Illustrated Parts Manual 31221549 RT5394 3122154700...
  • Page 8 This Page is intentionally left blank...

  • Page 9: Table Of Contents

    Oscillating Axle — Lockout Cylinder Test (If Equipped) (All Markets Except CE/UKCA) ..........36 SECTION 3 MACHINE CONTROLS, INDICATORS, AND OPERATION................... 39 General ................39 Description...............39 Operating Characteristics and Limitations......40 Platform Loading ..............40 Machine Controls Locations ..........41 Ground Control Station .............41 RT5394 3122154700...
  • Page 10 ClearSky Smart Fleet™ - Locked Out State ......70 SECTION 5 ACCESSORIES................71 Available Accessories ............71 1/2” Air Line ..............72 Footswitch ...............72 Heavy Duty Pipe Racks ............74 Large Material Racks ............75 Nite Bright® ..............77 Pipe Racks ..............77 Platform Rail Padding ............79 Platform Worklights ............80 3122154700 RT5394...
  • Page 11 6.12 EC Declaration of Conformity .......... 113 6.13 UKCA Declaration of Conformity........114 6.14 Supplemental Information Only Applicable to CE/UKCA Machines (EN280:2013+ A1:2015) ........115 6.15 EC Declaration of Conformity .......... 116 6.16 UKCA Declaration of Conformity........117 RT5394 3122154700...
  • Page 12 This Page is intentionally left blank...

  • Page 13: Safety Precautions

    If there are any questions with regard to safety, training, inspection, maintenance, application, and operation, please contact JLG Industries, Inc. (“JLG”). WARNING Failure to comply with the safety precautions listed in this manual could result in machine damage, property damage, personal injury or death.
  • Page 14 Do not travel on unsupported surfaces. • This machine can be operated in nominal ambient temperatures of 0°F to 104°F (-20° C to 40° C). Consult JLG to optimize operation outside of this temperature range. • When operating an internal combustion engine at high altitudes, a decrease in...

  • Page 15: Operation

    Do not allow personnel to tamper with or operate the machine from the ground with personnel in the platform, except in an emergency. • Do not carry materials directly on platform railing unless approved by JLG. • When two or more persons are in the platform, the operator shall be responsible for all machine operations.
  • Page 16 Prior to operation, ensure all gates and rails are fastened and secured in their proper position. • JLG Industries, Inc. recommends that all persons in the platform wear a full body harness with a lanyard attached to an authorized lanyard anchorage point while operating this machine. For further information regarding fall protection requirements on JLG products, contact JLG Industries, Inc.
  • Page 17 Allow for machine movement and electrical line swaying. Table 1. Minimum Approach Distances (MAD) Voltage Range (Phase to Phase) Minimum Approach Distance in Feet (Meters) 10 (3) 0 to 50 KV 15 (5) Over 50K V to 200 KV RT5394 3122154700...
  • Page 18 Do not travel on unsupported surfaces. • The user must be familiar with the operating surface before driving. Do not exceed the allowable side slope and grade while driving. 3122154700 RT5394...
  • Page 19 • Never exceed the maximum platform capacity as specified on the platform. Keep all loads within the confines of the platform, unless authorized by JLG. • Keep the chassis of the machine a minimum of 2 ft (0.6 m) from holes, bumps, drop-offs, obstructions, debris, concealed holes, and other potential hazards at the ground level.
  • Page 20 Do not increase the platform size with unauthorized modifications, deck extensions, or attachments. WARNING Do not operate the machine when wind conditions exceed specifications shown in the General Specifications section of this manual or as shown on the capacity placard on the platform billboard. 3122154700 RT5394...
  • Page 21 • During operation, keep all body parts inside platform railing. • Keep hands and limbs out of the scissor arm assembly during operation and when elevated without safety prop engaged. RT5394 3122154700...

  • Page 22: Towing, Lifting, And Hauling

    • When lifting machine with a forklift, position forks only at designated areas of the machine. Lift with a forklift of adequate capacity. • Refer to the Machine Operation section of this manual for lifting information. 3122154700 RT5394...

  • Page 23: Maintenance

    Wear gloves to help protect hands from spraying fluid. • Use only replacement parts or components that are approved by JLG. To be considered approved, replacement parts or components must be identical or equivalent to original parts or components.

  • Page 24: Long-Term Storage

    3 months) with an internal combustion engine, refer to the engine manufacturer’s guidance regarding fuel degradation. • For long-term storage of battery-electric machines, store machines in a cool, dry place away from direct sunlight and heat sources. Avoid storing batteries in a fully discharged or fully charged state. 3122154700 RT5394...

  • Page 25: User Responsibilities, Machine Preparation, And Inspection

    2.1.3 Operator Responsibility The operator must be instructed that they have the responsibility and authority to shut down the machine in case of a malfunction or other unsafe condition of either the machine or the job site. RT5394 3122154700...

  • Page 26: Preparation, Inspection, And Maintenance

    6. Accessories and optional equipment. PREPARATION, INSPECTION, AND MAINTENANCE The following table covers machine inspections and maintenance required by JLG Industries, Inc. Consult local regulations for further requirements for MEWPs. The frequency of inspections and maintenance must be increased as necessary when the machine is used in a harsh or hostile environment, if the machine is used with increased frequency, or if the machine is used in a severe manner.
  • Page 27 Mechanic tenance Manual Service & Main- tenance Manual Note: Inspection forms are available from JLG. Use the Service & Maintenance Manual to perform inspections. NOTICE JLG Industries, Inc. recognizes a factory trained service technician as a person who has successfully completed the JLG Service Training School for the specified JLG product model.

  • Page 28: Pre-Start Inspection

    Refer to Section 3 for more specific instructions on the operation of each function. 10. Accessories/Attachments - Refer to the Accessories section in this manual or accessory installed upon the machine for specific inspection, operation, and maintenance instructions. 3122154700 RT5394...
  • Page 29 12. Lanyard Anchorage Points – JLG Industries, Inc. recommends personnel in the platform wear a full body harness with a lanyard attached to an authorized lanyard anchorage points (1).

  • Page 30: Walk-Around Inspection

    Begin the Walk-Around Inspection at Item 1, as noted on the preceding diagram. Continue to the right (counterclockwise viewed from top) checking each item in sequence for the conditions listed in the Walk-Around Inspection checklist. WARNING To avoid possible injury, be sure machine power is off during walk-around inspection. 3122154700 RT5394...
  • Page 31 15. Battery Cables/Routing Installation – See Inspection Note. 16. Front Leveling Jack Assembly – See Inspection Note. 17. Rear Leveling Jack Assembly – See Inspection Note. 18. Rotary Angle (Elevation) Sensor (located on lower arm attach link pin) – See Inspection Note. RT5394 3122154700...

  • Page 32: Function Check

    With the platform elevated on a smooth, firm, level surface with no overhead obstructions, drive the machine to check if the high drive cutout speed limit is engaged at the height indicated in Table - Maximum Cutout Height, page 3122154700 RT5394...
  • Page 33 Table 4. Maximum Cutout Height High Drive Cutout Model 14 ft (4.26 m) RT5394 d. Ensure that all machine functions are disabled when the Emergency Stop Button is activated. e. Ensure all machine functions stop when function control is released or when joystick trigger is released.
  • Page 34 User Responsibilities, Machine Preparation, and Inspection 3122154700 RT5394...

  • Page 35: Oscillating Axle - Lockout Cylinder Test (If Equipped) (Ce/Ukca Markets Only)

    2.6.2 Right Side Wheel Test 1. Place a 4 in (10.16 cm) high block with ascension ramp in front of right wheel of the oscillating axle. 2. From platform control station, select LOW drive speed. RT5394 3122154700...

  • Page 36: Oscillating Axle - Lockout Cylinder Test (If Equipped) (All Markets Except Ce/Ukca)

    3. Set the drive control switch into position and carefully drive the machine up ascension ramp until left oscillating axle wheel is on top of block. 4. Verify the axle oscillates to maintain contact with the ground/ramp. (All four wheels on the ground). 3122154700 RT5394...
  • Page 37 It may be necessary to activate drive to release the cylinder. 9. If the lockout cylinders do not function properly, have qualified personnel correct the malfunction prior to any further operation. RT5394 3122154700...
  • Page 38 This Page is intentionally left blank...

  • Page 39: Machine Controls, Indicators, And Operation

    Ground controls operate lift up and down. Except for performing inspections and function checks, ground controls are to be used only in an emergency to lower the platform to the ground should the operator in the platform be unable to do so. RT5394 3122154700...

  • Page 40: Operating Characteristics And Limitations

    3. All machine systems are functioning properly. 3.3.3 Stability This machine, as originally manufactured by JLG and operated within its rated capacity on a smooth, firm surface, within the limits of the maximum operating slope, provides a stable aerial platform for all platform positions.

  • Page 41: Machine Controls Locations

    3. Emergency Stop Switch 4. Head and Tail Lights (If Equipped) 5. Hourmeter 6. Overload Indicator (LSS) 7. Water Temperature Indicator 8. Oil Pressure Indicator 9. Battery Indicator 10. Platform Lift/Lower Switch 11. Glow Plug (Diesel Engine Only) 12. Start Button RT5394 3122154700...
  • Page 42 With the power select switch in the center off position, power is shut off to both platform and ground controls and the key can be removed to disable the machine. Head and Tail Lights - ON/OFF Switch (If Equipped) - This toggle switch turns the head and tail lights on and off. 3122154700 RT5394...

  • Page 43: Platform Control Station

    Water Temperature Indicator - Illuminates when the engine is overheating. PLATFORM CONTROL STATION 1. Forward/Reverse/Lift/Lower Direction Arrow 11. Emergency Stop Switch 2. Joystick Controller with Trigger Enable 12. Glow Plug Switch (Diesel Only) Switch 3. Steer Control Switch and Decal 13. Gasoline Fuel Select (Dual Fuel Only) RT5394 3122154700...
  • Page 44 Preparation, and Inspection). When platform is lowered below high drive cutout height, high/ mid/low drive speeds are enabled. CAUTION Do not operate machine if high drive speed operates when platform is raised above the high drive cutout height. 3122154700 RT5394...
  • Page 45 Once pressed, glow plugs are active for 20 seconds. Allow the glow plugs a few seconds to heat up before starting the engine within the time frame. Generator Start Switch - (Optional) - This toggle switch, when used, turns the onboard generator on and sets the engine speed. RT5394 3122154700...
  • Page 46 LED will stop blinking and stay lit. Leveling Jacks Set - This indicator light will blink when the leveling jacks are being extended. Leveling Jacks Retracting - This indicator light will blink when the leveling jacks are being retracted. 3122154700 RT5394...
  • Page 47 When auto leveling is selected this switch is used to manually adjust (trim) the leveling of the machine to the left or right. Refer to Manual Level Adjustment (Trim) for operating procedures. System Fault Indicator - This warning light will flash the appropriate distress code (flash code). RT5394 3122154700...

  • Page 48: Traveling (Driving)

    Section — General Specifications and Operator Maintenance. 3.8.1 Traveling Forward 1. Position the platform Emergency Stop Switch to the on position. 3122154700 RT5394...

  • Page 49: Traveling (Grade/Side Slope)

    The drive pump will shift back into high drive once the incline decreases to 5°. There will be a 2 second delay before the machine goes back to high drive. RT5394 3122154700...

  • Page 50: Steering

    Note: The level adjustment of the machine may still be improved. (Refer to — Manual Level Adjustment (Trim), page 51). Note: If a 2/5 flash code appears through the system fault light at the platform control station, the machine is unable to level. Reposition and try again. 3122154700 RT5394...

  • Page 51: Platform

    Do not raise platform except on a smooth, firm and level surface free of obstructions and holes. There is a flow control valve which controls both the lift up and lift down speeds. Anytime lift direction abruptly changes, there is a three second delay between lift up and lift down. RT5394 3122154700...

  • Page 52: Platform Cable Hook

    500 lb (227 kg). WARNING Do not lower without completely retracting the platform extension. 3.13 PLATFORM CABLE HOOK Use the hook in the platform to store excess platform cable when platform is retracted. 3122154700 RT5394...

  • Page 53: Engine Operation

    When operating a machine at high ambient temperatures, a decrease in ma- chine performance and an increase in engine coolant temperature may occur. Contact JLG Customer Service for operation under abnormal conditions. 3.14.1 Starting Procedure Note: Perform initial start-up from Ground Controls.

  • Page 54: Dual Fuel System (If Equipped)

    LPG position until the engine regains smoothness, then return the switch to the gas select position. Repeat as necessary until the engine runs smoothly on gasoline. 3. Close the hand valve on the LPG supply tank by turning clockwise. 3122154700 RT5394...

  • Page 55: Platform Rails Fold-Down Procedure

    If driving machine with the platform control station from ground, do not hang the control box on any part of the machine while driving. Hold the control box and keep at least 3 ft (1 m) distance from machine. RT5394 3122154700...

  • Page 56: Parking And Stowing

    1. Drive the machine to a reasonably well-protected and well ventilated area. 2. Ensure the platform is fully lowered. 3. Position the emergency stop switch to the off position. 4. If necessary, cover the instruction placards, caution and warning decals so that they will be protected from hostile environment. 3122154700 RT5394...

  • Page 57: Towing

    Refer to the ClearSky Smart Fleet section for more information. 3.19.2 Amber Beacon This amber-colored beacon flashes in a consistent pattern to alert those nearby that the machine power is on. The device may also use different flash patterns to identify specific machine alerts. RT5394 3122154700...

  • Page 58: Clearsky Smart Fleet

    (if available) restrictions. Refer to the Access Control and Beacons sections of this manual for more information. Visit the ClearSky section of the JLG website for more resources and information about accessing web portal or mobile app data. 3.21 ACCESS CONTROL - CLEARSKY SMART FLEET™...

  • Page 59: Tie Down/Lift Lugs

    These lugs enable the machine to be lifted using cranes or other suitable lifting devices. Note: If lifting becomes necessary from the lifting lugs, JLG Industries Inc. recom- mends the use of a proper spreader bar to avoid damage to the machine.

  • Page 60: Lifting And Tie Down Chart

    Machine Controls, Indicators, and Operation 3.23 LIFTING AND TIE DOWN CHART WHEELBASE MODEL (in) (cm) (in) (cm) (in) (cm) RT5394 58.5 148.5 39.2 99.5 3.24 SAFETY DECALS 3.24.1 ANSI, ANSI Export Safety Decals Note: Some components have been removed for illustrative clarity. 3122154700...
  • Page 61 Machine Controls, Indicators, and Operation RT5394 3122154700...
  • Page 62 Machine Controls, Indicators, and Operation 3122154700 RT5394...
  • Page 63 Machine Controls, Indicators, and Operation 3.24.2 CE, UKCA, AUS, and MOL70 Safety Decals Note: Some components have been removed for illustrative clarity. RT5394 3122154700...
  • Page 64 Machine Controls, Indicators, and Operation Item # CE/UKCA AUS/MOL70 1703687 1703687 80463053 80463053 1703811 1703811 3122154700 RT5394...
  • Page 65 Machine Controls, Indicators, and Operation Item # CE/UKCA AUS/MOL70 1703814 1703814 1703819 1703819 1704277 1704277 1705019 1705019 1705372 1705372 1705671 1705671 1706338 1706338 1701785 1701785 1705036 (AUS) 1705036 Single Extension 1001269840 (MOL70) 1001191733 (AUS) 1001191733 1001269879 (MOL70) Dual Extension 1001191735 1001191735 RT5394 3122154700...
  • Page 66 This Page is intentionally left blank...

  • Page 67: Emergency Procedures

    INCIDENT NOTIFICATION JLG Industries, Inc. must be notified immediately of any incident involving a JLG product. Even if no injury or property damage is evident, JLG must be contacted by telephone and provided with all necessary details. • USA: 877-JLG-SAFE (554-7233) •...

  • Page 68: Emergency Operation

    3. Use cranes, forklifts or other equipment to stabilize motion of the machine to prevent a tip over as required. 4. From the ground controls, carefully free the platform from the object. 5. Once clear, restart the machine and return the platform to a safe position. 3122154700 RT5394...

  • Page 69: Platform Auxiliary Descent

    1. Locate the button at the front of the machine. 2. Push and hold the button until the platform reaches its desired height, then release. WARNING Keep hands and arms out of the path of the scissor arms and platform while lowering. RT5394 3122154700...

  • Page 70: Clearsky Smart Fleet™ - Locked Out State

    If the CS550 (ClearSky® LED Motion / Amber Beacon) is removed from a machine or disconnected from the control system through damage, the machine may also be placed into a Locked Out state. NOTICE Contact the ClearSky Smart Fleet™ account owner if the machine is in a Locked Out state. 3122154700 RT5394...

  • Page 71: Accessories

    UKCA Only) 1/2” Air Line Heavy Duty Pipe Racks Large Material Racks Nite Bright® Pipe Racks Platform Rail Padding Platform Rail Padding (with Proximity Switches) Platform Worklights SkyPower® - 7.5 kW Generator - 4 kW SkySense® SkyWelder® Workstation RT5394 3122154700...

  • Page 72: 1/2" Air Line

    Note: This accessory is only available in Korean markets. 5.3.1 Operation To operate a function, engage the footswitch and joystick trigger in any sequence before operating a function. 3122154700 RT5394...
  • Page 73 Accessories Figure 8. Footswitch Assembly RT5394 3122154700...

  • Page 74: Heavy Duty Pipe Racks

    Weight in racks plus weight in platform must not exceed rated capacity. NOTICE Retract platform extension before loading material. • Ensure no personnel are beneath the platform. • Do not exit platform over rails, or stand on rails. • Do not drive machine without material secured. 3122154700 RT5394...

  • Page 75: Large Material Racks

    The racks may be used with both single and dual deck extensions. 5.5.1 Safety Precautions WARNING Multiple material-handling accessories may be installed but only one may be loaded at a time unless approved by JLG Industries, Inc. RT5394 3122154700...
  • Page 76 1. Position material on racks with weight evenly distributed between both racks. 2. Route the tie-down straps at each end across loaded material. Hook into place and tighten until secure. 3. To remove material, unhook tie-down straps, then carefully remove material from racks. 3122154700 RT5394...

  • Page 77: Nite Bright

    Pipe Racks store pipe or conduit inside the platform in order to prevent rail damage and optimize platform utility. This accessory consists of two racks mounted to the top handrail with adjustable straps and hooks to secure the load in place. RT5394 3122154700...
  • Page 78 Maximum length of material is 20 ft (6 m). Maximum diameter of material is 10" (254 mm). WARNING Multiple material-handling accessories may be installed but only one may be loaded at a time unless approved by JLG Industries, Inc. • Ensure no personnel are beneath the platform. •...

  • Page 79: Platform Rail Padding

    1. Release the selected function. 2. Press and hold the Horn button on control console. 3. Reverse the direction of the selected function. Note: The machine will move in creep mode until proximity switch is no longer triggered. 4. Continue normal operation. RT5394 3122154700...

  • Page 80: Platform Worklights

    30 Amp (7.5kW) circuit breaker protects the generator from overload. 5.10.1 Output SkyPower 7.5 kW Specifications: • 3-phase: 240 V, 60 Hz, 7.5 kW (Peak: 8.5 kW) • 1-phase: 240 V/120 V, 60 Hz, 6 kW (Peak: 6 kW) 3122154700 RT5394...

  • Page 81: Skysense

    The operator must not rely on SkySense as a substitute for following the instructions and warnings on machine placards and in this manual. RT5394 3122154700...
  • Page 82 6. Remove hand or object from the sensor zone, then release the joystick and enable switch. Lower the platform to stowed. 7. Lift the platform with no hand or object above the sensor. The platform should lift without interruption. 8. Lower the platform to stowed. 3122154700 RT5394...
  • Page 83 A bi color LED indicator on the platform control box signals SkySense activity. • No LED: Normal operation. • LED Flashing Yellow: Machine is in SkySense warning zone and will reduce to elevated drive height speed. Flash frequency correlates to proximity of the object. RT5394 3122154700...
  • Page 84 Note: Override button is only required to be engaged if the operator desires to move the platform closer to an object that is in or entering the stop zone. 3122154700 RT5394...
  • Page 85 Accessories 5.11.8 SkySense Coverage Areas Level Three Note: Sensor Cones shown are approximations for reference only. RT5394 3122154700...

  • Page 86: Skywelder

    3-phase: 240 V, 60 Hz, 7.5 kW • 1-phase: 240 V/120 V, 60 Hz, 6 kW 5.12.2 Welding Accessories • 12 ft welding leads with clamp and stinger (stored in the platform) • Fire extinguisher 5.12.3 Safety Precautions WARNING Do not overload platform. 3122154700 RT5394...
  • Page 87 • Ensure there is a good ground connection and observe proper polarity. 5.12.5 Operation Start the engine, turn on the generator, then turn on the welder. Refer to the Miller Welder Owner’s Manual (PN 31215476) for more information. RT5394 3122154700...

  • Page 88: Workstation

    5-200 A 79 VDC 150 Amp at 28 V, —— —— 100% Du- ty Cycle 5.13 WORKSTATION 1. Adjustable Work Surface 2. Decal The Workstation offers an adjustable work surface and additional space for storage of tools and objects. 3122154700 RT5394...
  • Page 89 Ensure the Workstation is secured to the platform. • Check for missing or damaged components. Replace if necessary. • Check for loose nuts and bolts. Torque to JLG Torque Chart Specifications if necessary. • Replace any missing or illegible decals.
  • Page 90 This Page is intentionally left blank...

  • Page 91: Machine Specifications And Operator Maintenance

    Preventive Maintenance and Inspection Schedule included in the Service & Maintenance Manual. MACHINE SPECIFICATIONS Specification RT5394 Maximum Occupants Maximum Workload (Capacity): 1500 lb (680 kg) Main Platform: Max.
  • Page 92 Machine Specifications and Operator Maintenance Specification RT5394 1.0 mph (1.61 kph) (> 14 ft) Platform Elevated: 0.5 mph (0.8 kph) Lift Up Speed (No Load, Stowed to Full Height) 65 seconds 85 - 90 seconds (Dual Fuel) Lift Down Speed (No Load, Full Height to Stowed)
  • Page 93 Hydraulic Tank 32.3 gal (122.2 L) Engine Oil Diesel: 6 qt (5.7 L) Dual Fuel: 3.6 qt (3.4 L) Engine Coolant 7 qt (6.67 L) Drive Brake (Each) 2.7 oz (0.08 L) Drive Hub (Each) 17 oz (0.5 L) RT5394 3122154700...

  • Page 94: Engine Specifications

    - Ultra Low Sulfur (15 ppm) (Required to meet EPA Tier 4 Final, EU Stage V) - Up to 5% biodiesel Number of Cylinders Engine RPM Control Engine Control Unit (ECU) Low RPM Set 1400 RPM High RPM Set 2600 RPM Alternator 40 Amp, 12V, Belt-Driven 3122154700 RT5394...
  • Page 95 1.85 lb/hr (0.84 kg/hr) High RPM 9.3 lb/hr (4.23 kg/hr) Displacement 0.962 L (58.7 cu. in.) Gross Power Gas — 31.1 Hp (23.2 kW) @ 3600 RPM LP — 29.5 Hp (22.0 kW) @ 3600 RPM Gross Torque RT5394 3122154700...

  • Page 96: Engine Oil Operating Temperature

    LP — 48.8 ft. lb. (66.2 Nm) @ 1800 RPM ENGINE OIL OPERATING TEMPERATURE NOTICE Machine operation using non-JLG approved engine oil or operation outside of the temperature boundaries outlined in the “Engine Oil Operating Temperature” charts may result in premature wear or damage to components of the engine.

  • Page 97: Lubrication

    GL-3, and sufficient chemical stability for mobile hydraulic system service. Note: Aside from JLG recommendations, it is not advisable to mix oils of different brands or types, as they may not contain the same required additives or be of comparable viscosities.

  • Page 98: Scissor Arm Safety Prop

    — Hydraulic Oil, Operating Temperature Specifications, page 98 NOTICE Machine operation using non-JLG approved hydraulic fluids or operation outside of the temperature boundaries outlined in the “Hydraulic Fluid Operating Temperature Chart” may result in premature wear or damage to components of the hydraulic system.
  • Page 99 Lock the actuator rod in place with the rod keeper plate till next use. WARNING To avoid personal injury, use safety prop for all maintenance requiring platform to be elevated. RT5394 3122154700...

  • Page 100: Operator Maintenance

    If oil is not visible, add oil until oil is visible in both ADD and FULL sight windows on tank. Do not overfill tank. Any time the pump coupling is removed, coat splines of coupling with Texaco Code 1912 grease prior to assembly. 3122154700 RT5394...
  • Page 101 5. Scissor Arm - Sliding Wear Pads 11. Engine Coolant 6. Oil Change w/ Filter - Kubota 6.7.3 Fuel Tank • Fuel - Diesel or Gasoline (Per Engine Type - Reference Decal on Machine) • Capacity - 22 gal (83.2 L) RT5394 3122154700...
  • Page 102 Lube - EO - Minimum API SL (For viscosity, refer to Figure - Engine Oil Operating Temperature Specifications - Kubota (Dual Fuel Engine).) • Interval - Every Year or 200 hours of operation • Check oil level daily, maintain within marked level (1)/Change in accordance with engine manual. 3122154700 RT5394...
  • Page 103 • Lube - HO - API service classification GL-3, Reference - Figure - Hydraulic Oil Operating Temperature Specifications • Interval - Check oil every 10 hours of operation; change oil every 2 years or 1200 hours of operation. RT5394 3122154700...
  • Page 104 Tighten drain. 6.7.9 Hydraulic Charge Filter • Lube Point - Replaceable Element • Interval - Change after first 50 hours and after every six months or 300 hours 3122154700 RT5394...
  • Page 105 Interval - Every Year or 600 hours of operation 6.7.11 Fuel Filter (Gas) - Kubota Note: Mounted inside fuel/hydraulic cabinet on left-rear cabinet wall behind fuel tank. • Lube Point(s) - Replaceable Element • Interval - Check every 100 hours; change every year RT5394 3122154700...
  • Page 106 Engine Coolant • Lube Point - Fill Cap/Fill Level • Interval - Check coolant level daily. Ensure it is between the "FULL" and "LOW" lines (1). If coolant level is low, allow fluid to cool, then add as required. 3122154700 RT5394...

  • Page 107: Propane Fuel System

    Tire Damage For polyurethane foam-filled tires, JLG Industries, Inc. recommends that when any of the following are discovered, measures must be taken to remove the JLG product from service immediately and arrangements must be made for replacement of the tire or tire assembly.
  • Page 108 JLG recommends a replacement tire be the same size, ply and brand as originally installed on the machine. Please refer to the JLG Parts Manual for the part number of the approved tires for a particular machine model. If not using a JLG approved...
  • Page 109 Check torque every 3 months or 150 hours of operation. Table 6. Wheel Torque Chart TORQUE SEQUENCE 1st Stage 2nd Stage 3rd Stage 85 ft. lb. (115 Nm) 110 ft. lb. (149 Nm) 170 ft. lb. (230 Nm) RT5394 3122154700...

  • Page 110: Radio Frequency (Rf) Information

    Sky Smart Fleet telematics must be received by countries that are certified to have ClearSky Smart Fleet. For a full listing of ClearSky Smart Fleet certified countries, please refer to the ClearSky webpage on the JLG website. 6.10.1 Federal Communications Commission (FCC)
  • Page 111 JLG Industries, Inc. declares that the radio equipment ClearSky Smart Fleet CS550 Connectivity Module complies with Directive 2014/53/EU. Full details can be found on the declaration of conformity. The CS550 is intended to be mounted on JLG machines and has integrated beacon functionality. Additionally, it provides telematics data via WiFi or Cell, and provides local diagnostic data exchange with a mobile device connected via WiFi and BLE.

  • Page 112: Supplemental Information Only Applicable To Ce/Ukca Machines (En280-1:2022)

    The vibration highest root mean square value of weighted acceleration to which the whole body is subjected during driving or lifting does not exceed 0.5 m/s². JLG declares that machines included in this manual, before placing on the market, have been subjected to the required tests in accordance with EN280-1:2022, clause 5.3.

  • Page 113: Ec Declaration Of Conformity

    EN 61000-6-2:2005 • EN 60204-1:2018 • EN 280-1:2022 • EN ISO 12100:2010 JLG Industries, Inc. hereby declares that the above mentioned machine conforms with the requirements of: • 2006/42/EC — Machinery Directive • 2014/30/EU — EMC Directive • 2014/53/EU — RED Directive (If fitted with optional equipment) Note: This declaration conforms with the requirements of annex II-A of the council directive 2006/42/EC.

  • Page 114: Ukca Declaration Of Conformity

    EN 60204-1:2018 • EN 280-1:2022 • EN ISO 12100:2010 JLG Industries, Inc. hereby declares that the above mentioned machine conforms with the requirements of: • 2008 No. 1597 - Supply of Machinery (Safety) Regulations 2008 • 2016 No. 1091 - Electromagnetic Compatibility Regulations 20165 •...

  • Page 115: Supplemental Information Only Applicable To Ce/Ukca Machines (En280:2013+ A1:2015)

    . The highest root mean square value of weighted acceleration to which the whole body is subjected does not exceed 0,5 m/s Note: EC/UKCA Declarations of Conformity may vary. Refer to the original serial number-specific declaration for your machine to determine which is applicable. RT5394 3122154700...

  • Page 116: Ec Declaration Of Conformity

    EN 61000-6-2:2005 • EN 60204-1:2018 • EN 280:2013+ A1:2015 • EN ISO 12100:2010 JLG Industries, Inc. hereby declares that the above mentioned machine conforms with the requirements of: • 2006/42/EC — Machinery Directive • 2014/30/EU — EMC Directive • 2014/53/EU — RED Directive (If fitted with optional equipment) Note: This declaration conforms with the requirements of annex II-A of the council directive 2006/42/EC.

  • Page 117: Ukca Declaration Of Conformity

    EN 60204-1:2018 • EN 280:2013+ A1:2015 • EN ISO 12100:2010 JLG Industries, Inc. hereby declares that the above mentioned machine conforms with the requirements of: • 2008 No. 1597 - Supply of Machinery (Safety) Regulations 2008 • 2016 No. 1091 - Electromagnetic Compatibility Regulations 20165 •...
  • Page 118 This Page is intentionally left blank...
  • Page 119 Inspection, Maintenance and Repair Log Serial Number ___________________________________ Any additional required certificates can be attached to the rear cover of this manual or stored in the manual box. Date Comments...
  • Page 120 Inspection, Maintenance and Repair Log...
  • Page 122 Corporate Office JLG Industries, Inc. 1 JLG Drive McConnellsburg, PA 17233-9533 USA (717) 485-5161 (Corporate) (877) 554-5438 (Customer Support) (717) 485-6417 Visit our website for JLG Worldwide Locations. www.jlg.com...
