On:
A compatible EcoFlow product (EcoFlow Smart Extra Battery, EcoFlow
Smart Generator, etc) is connected via the Extra Battery port.
5
Charging Status
On:
The power station is charging.
6
Total Output Power
On:
Displays total output power.
7
USB-C Output
On:
The USB-C ports are enabled.
8
USB-A Output
On:
The USB-A ports are enabled.
9
12V DC Output
On:
The Cigarette Lighter and DC5521 ports are enabled.
10 AC Output
On:
The AC output sockets are enabled.
11 Frequency
On:
Displays operating AC power frequency (50 Hz / 60 Hz).
Battery Level Details
1 Charging / Discharging Limit
On:
The charging limit (green) or discharging limit (red) is set in the EcoFlow
app.
2 Remaining Charging / Discharging time
On:
Displays the remaining charging or discharging time.
3 Battery Level
On:
Displays current battery level.
Error Message
