- Page 1 EcoFlow DELTA 2 MAX User Manual V1.0...
- Page 2 EcoFlow reserves the right of final interpretation of this document and all related documents of this product where permitted by laws and regulations. These documents are subject to update, revision or termination from time to time without prior notice, please visit EcoFlow website for the latest product information.
-
Page 3: Table Of Contents
Safety Instructions EcoFlow App What's in the Box Product Details Overview LCD screen Power On/Off Charge Your Devices Charge DELTA 2 Max AC Charging Solar Charging Car Outlet Charging Smart Extra Battery X-Boost and EPS X-Boost Storage and Maintenance Troubleshooting... -
Page 4: Specifications
Specifications General Info Model EFD350 Weight Approximately 23 kg Dimension 497 × 242 × 305 mm Capacity 2,048Wh Frequency range: 2,402-2,480 MHz Bluetooth Maximum output power: 7.3 dBm Frequency range: 2,412-2,472 MHz/2,422-2,462 MHz Wi-Fi Maximum output power: 17.67 dBm Output Ports Pure sine wave, 2,400W total (surge 4,800W) AC (×4) 230V~ 50Hz/60Hz... -
Page 5: Safety Instructions
Operating Temperature Optimal operating temperature 20°C to 30°C Discharging temperature -10°C to 45°C Charging temperature 0°C to 45°C Storage temperature -10°C to 45°C (optimal: 20°C to 30°C) Add-ons (supplied separately) Smart extra battery Up to 2 units Smart generator Supported 1. - Page 6 Please take anti-electric shock measures before touching the product. Following this, place the product in a safe, waterproof and open area. Once complete contact EcoFlow Customer Service immediately. 27. This product is not recommended for powering medical emergency equipment related to...
- Page 7 29. When the power supply is connected in normal mode to a refrigerator, power fluctuations may cause the power supply to shut down automatically. When connecting the power supply to a refrigerator that stores medicine, vaccines or other valuable items, it is recommended to set the AC output to "Always on"...
-
Page 8: Ecoflow App
EcoFlow App Control, monitor and customize your EcoFlow DELTA 2 Max from afar with the EcoFlow App. Download at: https://download.ecoflow.com/app Privacy policy By using EcoFlow Products, Applications and Services, you consent to the EcoFlow Term of Use and Privacy Policy, which you can access via the “About”... -
Page 9: Product Details Overview
Product Details Overview Schweiz 1. The type of AC socket varies in different countries or regions, the picture above is for illustration only, please refer to the actual product. 2. Due to local laws and regulations the Swiss version has only one AC output socket. -
Page 10: Lcd Screen
LCD Screen 1. Remaining battery percentage 10. Fan 2. Battery level 11. Input power 3. Remaining charging/discharging time 12. Output power 4. Extra battery 13. Overload warning 5. AC output 14. State of charge 6. USB-A Output 15. Wi-Fi status 7. -
Page 11: Power On/Off
Power On/Off Press the main power button once to turn on the product, then the LCD screen lights up and the main power indicator becomes breathing white; press and hold the main power button for at least 3 seconds to turn off the product, meanwhile, the LCD screen goes off. 1. -
Page 12: Charge Delta 2 Max
EcoFlow’s X-Stream fast charging technology is specifically designed for AC charging. The AC charging speed can be adjusted via the EcoFlow app. In case of unusual situations where the AC input current remains higher than 20A, the X-Stream charging input port will initiate a self-protection function, and the Overload Protection Switch on the product will automatically pop up. -
Page 13: Solar Charging
1. Solar charging cable (MC4-XT60 adapter cable) and the solar panel are supplied separately. 2. When using an EcoFlow solar panel to charge the product, please follow the instructions that come with the solar panel. 3. Before connecting the solar panel, please ensure that the solar panel’s output voltage... -
Page 14: Car Outlet Charging
Car charging cable Smart Extra Battery A single DELTA 2 Max can connect up to 2 Smart Extra Battery for additional capacity. Please check the user manual of DELTA 2 Max Smart Extra Battery for more information. 1. Turn off both the Smart Extra Battery and DELTA 2 Max before connecting or disconnecting them. -
Page 15: X-Boost And Eps
1. X-Boost is not available when the AC output is turned on in a recharging state (in bypass mode). 2. X-Boost is enabled by default, you can adjust it in the EcoFlow App. 3. X-Boost is not available for all electrical appliances; it’s incompatible with appliances with strict voltage requirements. -
Page 16: Faq
1. What battery does the product use? High-quality LFP battery. 2. What devices can the product’s AC output port power? With high rated power and peak power, the product’s AC output port can power most household appliances. Before you use it, we recommend that you confirm the power of the appliances first and ensure the power sum of all loaded appliances is lower than the rated power. -
Page 17: Troubleshooting
If the Alarm Prompt shows on the product LCD screen during use and does not disappear after a restart, please stop using it immediately (do not try to charge or discharge). If you require any other assitance, please contact EcoFlow Customer Service. - Page 18 Your retailer will accept used products and return them to an environmentally-sound recycling facility. Hereby, EcoFlow Inc. declares that the radio equipment type portable power station is in compliance with Directives 2014/53/EU, 2011/65/EU(RoHS), (EU) 2015/863(RoHS). The full text of the EU declaration of conformity is available at the following Internet address: eu: http://www.ecoflow.com/eu/eu-compliance...
