  • Page 1 UHDS-808VW 8x8 4K Seamless Matrix with Follow us on Youtube and Facebook Video Wall U S E R M A N U A L www.orei.com Page 1...

  • Page 2: Table Of Contents

    Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions IR Remote IR Cable Pin Assignment EDID Management WebGUI User Guide RS-232 Command Control Application Example FAQs & Troubleshooting Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product.

  • Page 3: Registration Page

    Registration Page Please Activate your warranty by registering our product through the link below - www.orei.com/ register Technical Support Need Help? Our experienced Technical Support Team is here for you to answer your questions, give technical advice or help troubleshoot your project to get you installed on time and on budget. Call, email or chat with us now.

  • Page 4: Introduction

    Introduction & Features The UHDS-808VW is an 8x8 Matrix that allows you to switch between 8 media sources and out- put them on 8 displays. It features 8 HDMI inputs and outputs, supporting video resolutions up to 4K@60Hz with an 18Gbps video bandwidth and HDCP 2.2 compliance. The device offers seamless switching and features Optical and 5-pin phoenix Analog audio outputs for audio extraction.

  • Page 5: Package Contents

    Package Contents & Specifications Package Contents UHDS-808VW Matrix 1pcs Power Adapter 1pcs IR Remote 1pcs IR Receiver Cable 1pcs USB to RS-232 Serial Cable (USB A to RS-232 serial DB9 male connector) 1pcs 5pin-3.5mm Phoenix Connector (male) 8pcs Machine Screw...
  • Page 6 Specifications Connection Inputs 8 × HDMI [Type A, 19-pin female] 8 × HDMI [Type A, 19-pin female] Outputs 8 × OPTICAL [S/PDIF] 8 × L/R [5-pin Phoenix] 1 × TCP/IP [RJ45] Control 1 × RS-232 [D-Sub 9] 1 × IR EXT [3.5mm, Stereo Mini-jack] Mechanical Housing Metal Enclosure...

  • Page 7: Operation Controls And Functions

    Operation Controls and Functions Front Panel MENU POWER OUTPUT INPUT ENTER DOWN LOCK Name Function Description OLED screen Displays the matrix switching status, device information, etc. The LED will light up Green when the device is powered on. The LED will PWR LED light up Red when the device is on standby.
  • Page 8 Operation Controls and Functions Rear Panel AUDIO OUT 1 AUDIO OUT 2 AUDIO OUT 3 AUDIO OUT 4 AUDIO OUT 5 AUDIO OUT 6 AUDIO OUT 7 AUDIO OUT 8 OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO OPTICAL...
  • Page 9 Operation Controls and Functions LCD Display Navigation The buttons on the the front panel are used for LCD display navigation, including INPUT(1~8), OUT- PUT(1~8), MENU, ENTER, UP, DOWN. Menu contents are as follows: Level 1 Level 2 Level 3 Level 4 4K×2K60W, 4K×2K50W, 4K×2K60,...
  • Page 10 Operation Controls and Functions Level 1 Level 2 Level 3 Level 4 (Continued) 1920×1200, 2.0CH 1360×768, 2.0CH 1024×768, 2.0CH USER1 USER2 IN1/IN2/IN3/IN4 COPY OUT1 INPUT EDID /IN5/IN6/IN7/IN8 COPY OUT2 COPY OUT3 COPY OUT4 COPY OUT5 COPY OUT6 COPY OUT7 COPY OUT8 OUT1/OUT2/OUT3/ ENABLE OUT4/OUT5/OUT6/...

  • Page 11: Ir Remote

    IR Remote Power on the Matrix or set it to standby mode. Input 1/2/3/4/5/6/7/8: Input Press to select the input source. Output 1/2/3/4/5/6/7/8: Press to select the output channel. Output Select the last or next signal input source. ◀ ▶: All: Select all output channel simultaneously.

  • Page 12: Ir Cable Pin Assignment

    IR Remote & IR Cable Pin Assignment The second way: If the IR receiver window of the Matrix is blocked or the Matrix is installed in a closed area out of infra- red line of sight, the IR receiver cable can be inserted to the “IR EXT” port to receive the IR remote signal. The furthest distance of using the IR remote is 5 meters when the IR remote is directly faced to the IR receiver head, and 3 meters when the angle is ±...

  • Page 13: Edid Management

    EDID Management This Matrix has 12 factory defined EDID settings, 2 user-defined EDID modes and 8 copy EDID modes. You can select defined EDID mode or copy EDID mode to input port through front panel buttons, RS-232 control or WebGUI. On-panel button operation: On the initial OLED display screen, press “MENU”...
  • Page 14 EDID Management The defined EDID setting list of the product is shown as below: EDID Mode EDID Mode 4K60, 2.0CH 1024×768, 2.0CH 4K60, 5.1CH USER1 4K60, 7.1CH USER2 4K30, 2.0CH COPY OUT1 4K30, 5.1CH COPY OUT2 4K30, 7.1CH COPY OUT3 1080P, 2.0CH COPY OUT4 1080P, 5.1CH...

  • Page 15: Webgui User Guide

    WebGUI User Guide The Matrix can be controlled by the WebGUI. The operation method is shown as below: Step 1: Get the current IP Address. The default IP address is 192.168.0.100. You can get the current Matrix IP address in two ways: The first way: You can get the IP address via panel buttons.
  • Page 16 WebGUI User Guide ■ Status Page The Status page provides basic information about the product model, installed firmware version and the network settings of the device. ■ Matrix Page In Matrix page, you can configure the HDMI matrix freely and create a preset if needed. Page 16...
  • Page 17 WebGUI User Guide ① Matrix: You can click and select an output (1~8) first, and then select an input source (1~8) below which will appear in the selected output area. ② Presets: You can set, save or clear any route video matrix configuration if needed. For example, if you have a specific configuration where you want a specific input to go to a specific output, you can save that scene and recall it.
  • Page 18 WebGUI User Guide Make sure to select the correct file, then you can check the name of the selected file. Then select destination “User Define1/User Define2”, and click “Upload”. After successful setting, it will prompt as follows: ⑥ Download EDID to your computer: If you want to download the existing EDID, click the drop-down box of “Select EDID File”...
  • Page 19 WebGUI User Guide ■ Output Page You can do the following operations on the Output page: ① Outputs: Output channel of the device. ② Cable: It indicates the connection status of output ports. When the output port is connected to the display, it lights up Green, otherwise, it lights up Gray.
  • Page 20 WebGUI User Guide ⑤ Color Space: Set the color space for current output. Click the drop-down menu and select the option required. There are four options to select from. ⑥ HDCP: Set the HDCP version that the current output device supports. There are five options to select from: •...
  • Page 21 WebGUI User Guide ⑧ Stream: Click ON/OFF button to turn on/off the output stream. ■ Video Wall Page You can do the following operations on the Video Wall page: ① Video Wall Setting: Set the splicing mode, such as 1x8, 2x3. The range of Rows and Columns is 1~8.
  • Page 22 WebGUI User Guide Note: Before splicing, it is necessary to assign each spliced screen to the output port via right- click menu. To the splicing screens, you can configure them at the same time using the right-click menu. • Cancel the screen spicing. •...
  • Page 23 WebGUI User Guide ■ Ext-Audio Page You can set the audio mode on the Ext-Audio page. There are three modes: Bind to Input, Bind to Output and Audio Matrix. Bind to Input: The Audio Output follows the HDMI Input. And there is a consistent one-to-one match between each HDMI input and audio output.
  • Page 24 WebGUI User Guide Bind to Output: The Audio Output follows the HDMI Output. For example, if the HDMI Input 3 is assigned to the HDMI Output 1, the audio of AUDIO Output 1 is from HDMI Input 3. Click Enable/Disable button to turn on/off the audio channel. In this mode, the input sources can’t be selected.
  • Page 25 WebGUI User Guide ■ Network Page You can do the following operations on the Network page: ① Modify Network Setting: Modify the IP Mode/IP Address/Gateway/Subnet Mask/Telnet Port as required, click “Save” to save the settings, and then it will come into effect. Page 25...
  • Page 26 WebGUI User Guide If the Mode is “Static”, you can manually set the IP Address/Gateway/Subnet/Telnet Port as required. If the Mode is “DHCP”, it will be filled with the IP Address assigned by the router automatically. You can't modify it now. ②...
  • Page 27 WebGUI User Guide Note: Input rules for changing passwords: (1) The password can’t be empty. (2) New Password can’t be the same as Old Password. (3) New Password and Confirm Password must be the same. ③ Set the Default Network: Click “Set Network Defaults”, there will be a prompt, as shown in the following figure: Click “OK”...
  • Page 28 WebGUI User Guide You can do the following operations on the System page: ① Panel Lock: Click “ON/OFF” to lock/unlock panel buttons. “ON” indicates that panel buttons are unavailable; “OFF” indicates panel buttons are available. ② Beep: Turn on/off the beep. ③...

  • Page 29: Rs-232 Command Control

    RS-232 Command Control The product also supports RS-232 control. Connect the RS-232 port on Matrix to a PC with the provided USB to RS-232 serial cable. The connection method is as follows: RS-232 Then open a Serial Command tool on PC to send RS-232 commands to control the product. The command list of the product is as below.
  • Page 30 RS-232 Command Control Command Code Function Description Example Feedback Default r power! Get current power state r power! power on /power off Enable/disable buzzer function, beep on s beep z! s beep 1! beep of z=0~1 (z=0 beep off, z=1 beep on) beep of r beep! Get buzzer state...
  • Page 31 RS-232 Command Control Command Code Function Description Example Feedback Default Output Setting Set output x resolution (x=0~8 (0=all output), y=1~16) 1. 4096x2160p60, 2. 4096x2160p50, 3. 3840x2160p60, 4. 3840x2160p50, 5. 3840x2160p30, 6. 1920x1080p60, 7. 1920x1080p50, output 1 resolution: s output x res y! s output 1 res 3! 3840x2160p60 8.
  • Page 32 RS-232 Command Control Command Code Function Description Example Feedback Default Output Setting Get output x mirror status (x=0~8 r output x mirror! r output 1 mirror! output 1 h mirror off (0=all output)) Set output x stream enable/dis- able (x=0~8 (0=all output), y=0~1) s output 1 stream s output x stream y! output 1 stream: enable enable...
  • Page 33 RS-232 Command Control Command Code Function Description Example Feedback Default Video Matrix Setting Set output display mode (x=0~1) display mode: mar- s display mode x! s display mode 0! matrix x=0 matrix mode trix x=1 video wall mode display mode: mar- r display mode! Get output display mode r display mode!
  • Page 34 RS-232 Command Control Command Code Function Description Example Feedback Default Video Wall Setting s vw group z Set video wall group z screen s vw group 2 vw group 2 screen 2367! screen abcd! number (z<=1~4) screen 2367! s vw group z Set video wall group z select s vw group 1 vw group 1 source 1!
  • Page 35 RS-232 Command Control Command Code Function Description Example Feedback Default Video Wall Setting Save video wall state to save vw pre- save vw preset z! save to preset 1 preset z, z=1~8 set 1! Recall video wall preset z recall vw pre- recall vw preset z! recall from preset 1 scenarios, z=1~8...
  • Page 36 RS-232 Command Control Command Code Function Description Example Feedback Default CEC Setting Set input x power on by cec, x=0~8 (0=all s cec in x on! s cec in 1 on! input 1 power on input) Set input x power off by cec, x=0~8 (0=all s cec in x off! s cec in 1 off! input 1 power off...
  • Page 37 RS-232 Command Control Command Code Function Description Example Feedback Default CEC Setting s cec hdmi out y Set hdmi output y power off by s cec hdmi out 1 hdmi output 1 power off off! cec, y=0~8 (0=all hdmi output) off! s cec hdmi out y Set hdmi output y volume mute...
  • Page 38 RS-232 Command Control Command Code Function Description Example Feedback Default Network Setting set gateway:192.168.0.1 (please use “s net reboot!” s gateway xxx. s gateway command or repower device Set network gateway xxx.xxx.xxx! 192.168.0.1! to apply new config!) dhcp on, device can’t config gateway, set dhcp off first.

  • Page 39: Application Example

    Application Example 2.0 Speakers Amplifier AUDIO OUT 1 AUDIO OUT 2 AUDIO OUT 3 AUDIO OUT 4 AUDIO OUT 5 AUDIO OUT 6 AUDIO OUT 7 AUDIO OUT 8 OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO OPTICAL AUDIO...

  • Page 40: Faqs & Troubleshooting

    Please refer to Page 19. Still have some questions? Please feel free to contact us at: info@orei.com. OR Fill out the form on the ‘Con- tact Us’ page on the website. Our team will be more than happy to help you.
  • Page 41 8x8 4K Seamless Matrix with Video Wall UHDS-808VW www.orei.com © 2024 Page 41...
