Orei UHD44-EX230-K User Manual

Hdbaset 4×4 hdmi matrix over cat5e/6/7
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HDBaseT 4×4 HDMI Matrix
over CAT5e/6/7
VER 2.0
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric
shook, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend
the life of your equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHD44-EX230-K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Orei UHD44-EX230-K

Summary of Contents for Orei UHD44-EX230-K

  • Page 1 HDBaseT 4×4 HDMI Matrix over CAT5e/6/7 VER 2.0 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shook, lighting strikes, etc.

  • Page 2: Table Of Contents

    Table of Contents 1.Introduction 2.Features 3.Package Contents 4.Specifications 5. Panel Functions 5.1 Front Panel 5.2 Rear panel 6. Remote Control 7. IR Control system(IR Call-back of Matrix and Source Devices) 8. HDBT Receiver 9. Operate and Connect 1. Introduction The HD BaseT 4x4 HDMI Matrix with simultaneous CAT5e/6/7 and HDMI outputs connects four HDMI sources to eight displays.

  • Page 3: Package Contents

    Support wideband IR(30-60Khz) matrix system, IR transport channel can be forward or backward and supports GLOBAL IR. ​ ※ See the description 2. Support RS-232 4 channel bypass.​ ※ See the description 3​ . Support simultaneous HDMI and CAT outputs Support RS-232, remote control, on-panel control and TCP/IP Control Support smart EDID management 3.
  • Page 4 Number Name Function description Display the information of each input and output setting and EDID management. IR Receiver window (accepts the remote control signal of this device only). POWER Press this button to power the device on/off. The LED will illuminate green when the power is on, red when it is in 'Standby' mode.

  • Page 5: Rear Panel

    4K x 2K@30Hz , DOLBY/DTS 5.1 4K x 2K@30Hz , HD AUDIO 4K x 2K@60Hz, 2CH AUDIO 4K x 2K@60Hz , DOLBY/DTS 5.1 4K x 2K@60Hz , HD AUDIO Copy from HDMI OUTPUT A Copy from HDMI OUTPUT B Copy from HDMI OUTPUT C Copy from HDMI OUTPUT D Copy from HDBT OUTPUT A Copy from HDBT OUTPUT B...

  • Page 6: Remote Control

    the transmission of RS-232 commands. HDMI INPUT Connect to the HDMI input source devices such as a DVD player or a Set-top Box with HDMI cable. HDMI OUTPUT The HDMI OUTPUT connect to HDMI equipped TVs or monitors and the HDBT OUTPUT connect to the HDBT Receiver. The coaxial and analog audio output connect to the audio amplifier.
  • Page 7 01. At Matrix end: Insert the 3.5mm jacks of the IR TX Emitters included with the unit into the IR TX Emitter ports at the rear of the matrix according to input. The IR signal is added to the HDMI of the input device, for example, if the user is watching Blue-ray on input 1, the IR signal will be directed through the IR TX1 socket to control the device.

  • Page 8: Hdbt Receiver

    8. HDBT Receiver Number Name Function description POWER This LED illuminates when the device is connected with power supply DC 24V Plug the 24V DC power supply into the unit. HDBaseT In Standard HD BaseT signal input port. Connect HD BaseT transmitter with a UTP cable.
  • Page 9 ※Illuminate: The Transmitter and Receiver are in good connection Connection Signal Indicator Lamp status. ※Flashing: The Transmitter and Receiver are in poor connection status. ※Dark: The Transmitter and Receiver are not connected. ※Illuminate: The HDMI signal with HDCP. Data Signal ※Flashing: The HDMI signal without HDCP.
  • Page 10 ※ Description 3 Bidirectional RS-232 control Application Example This system provides 4 channel RS-232.

  • Page 11: Operate And Connect

    Operate and Connect 1. Connect up to 4 sources such as a Blue-Ray Player, game console, A/V Receiver, Cable or Satellite Receiver, etc. to the HDMI inputs on the unit. Do not hot plug! Insert and extract cables carefully with the power switch off.
  • Page 12 ports, starting with output 1, to the HDBT Receiver display receivers (sold separately) (using well terminated or pre-terminated Cat5e/6/7 cables no longer than 230 ft/70M) 3. If utilizing UTP, connect the output HDMI ports of the HDBT Receiver display receivers (sold separately) to high-definition displays such as an HDTV or HD projector that use HDMI inputs.
