UHD-402MV 4K@60Hz 4x2 Multiviewer Follow us on Youtube and Facebook Seamless UHD Video Matrix Switcher U S E R M A N U A L www.orei.com page 1...
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions IR Remote EDID Settings Video & Audio Multiview OSD Menu Navigation Controller Software Operation Guide RS-232 Command Application Example Thank you for purchasing this product Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this prod- uct.
Page 3
OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 6 p.m. Central Time Support Email - info@orei.com | Support Number - 877-290-5530 Chat Live on www.orei.com Send us an instant message now. Our Technical Support Team will respond momentarily.
Introduction The UHD-402MV was developed for the purpose of supporting higher output resolution (4K@60) for multiple sources on two screens. It can accept 4 HDMI input digital sources and combine four video signals onto two HDMI UHD or HD monitors independently. Users can manage each input, and create com- binations of the four inputs on two displays, as well as adjust the position of any input.
Features HDMI 2.0b, HDCP 2.2 and HDCP 1.x compliant 18Gbps uncompressed bandwidth, input and output resolution up to 4K2K@60 4:4:4 HDMI audio formats support LPCM, DD+, DTS, Dolby TrueHD, DTS HD-master pass-through Supports seamless switching between input channels Combined multiple images independent layouts to display on two UHD TVs Up to 8 display modes: Single, PIP, PBP(1), PBP(2), Triple(1), Triple(2), Quad(1), Quad(2) Audio de-embedding via analog and optical fiber audio ports...
Operation Controls and Functions Front Panel OUT 1 OUT 2 OUT 1 OUT 2 Name Function Description ▪ Short press this button to turn on the device. Power button ▪ Long press this button for 1 second to enter the standby mode. The Power LED will light up green when the product is powered Power LED on, and red when the product is on standby.
Page 10
Operation Controls and Functions Name Function Description OUT 1 Input source switching button for the HDMI OUT 1 port, only avail- button able in single screen display mode. Multiview display mode switching button for the HDMI OUT 1 port. OUT 1 ▪...
Page 11
Operation Controls and Functions Rear Panel OUT 1 OUT 2 INPUT OPTICAL HDMI OPTICAL HDMI HD 1 HD 2 HD 3 HD 4 RS-232 IR EXT DC 12V 9 10 Name Function Description L/R OUT 1 PCM 2.0 analog audio output port. OPTICAL OUT 1 Optical fiber digital audio output port.
Page 12
Operation Controls and Functions IR Pin Definition IR Receiver pin’s definition is as below: IR Receiver IR Signal Power Grounding IR Receiver page 12...
IR Remote Press this button to power on the product or set it to standby mode. HD 1/2/3/4: Press these buttons to select input source in single screen display mode, and the corresponding input LED on the front panel will light in green. Press these buttons to circularly select the last or next input source in single screen display mode.
EDID Settings Out 1: Press this button to enter the OSD menu of the HDMI OUT 1 port, and set the corresponding function by pressing ▲/▼/◀/▶/OK button. Out 2: Press this button to enter the OSD menu of the HDMI OUT 2 port, and set the corresponding function by pressing ▲/▼/◀/▶/OK button.
Video & Audio The switcher supports multiple resolution video input up to 3840×2160@60, and supports multiple audio formats (PCM 2.0/5.1/7.1CH, Dolby Digital/Plus/ EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio) pass-through function via HDMI cable. The switcher supports following video output resolutions via a powerful scaling engine.
OSD Menu Navigation (1) A total of eight buttons on the IR Remote are used for OSD menu naviga- tion, including OUT 1, OUT 2, Exit, ▲,▼,◀,▶, OK. Menu contents are as follows: 4096×2160p 60Hz/ 4096×2160p 50Hz/ 3840×2160p 60Hz/ 3840×2160p 50Hz/ 3840×2160p 30Hz/ 3840×2160p 25Hz/ 1920×1200p 60Hz RB/...
Page 18
OSD Menu Navigation Single Input select HDMI1, HDMI2, HDMI3, HDMI4 Win1 Select HDMI1, HDMI2, HDMI3, HDMI4 Win2 Select HDMI1, HDMI2, HDMI3, HDMI4 Right Bottom, Right Top, PIP Position Left Bottom, Left Top PIP Size Small, Middle, Large Win1 Select HDMI1, HDMI2, HDMI3, HDMI4 Win2 Select HDMI1, HDMI2, HDMI3, HDMI4 MODE...
Controller Software Operation Guide Installation & Connection Follow the steps below to install the Controller software. Step 1. Double-click the following driver to install the Controller software. Step 2. Select “Anyone who uses this computer (all users)”, and then click “Next”. Step 3.
Page 21
Controller Software Operation Guide Follow the steps below to connect the Controller software and the device. Step 1. Connect the RS-232 port of the switcher to a PC with an RS-232 serial cable and an USB to RS-232 serial cable, as shown in the figure below. Ground 3-pin Phoenix connector RS-232...
Page 22
Controller Software Operation Guide Step 2. Launch the installed Controller software. (The default language is English, and you can set the language in the upper right corner of the main page.) Select “COM Control Mode” on the “General” page, then select the Port number and Baud Rate (default: 115200), and finally click “Connect”.
Page 23
Controller Software Operation Guide Controller Main Interface ■ General Page You can do the following operations on the General page: ① Control Mode Select: Select the “COM Control Mode”. (TCP/IP control is not supported temporarily, so the TCP/IP Control Mode is disabled.) ②...
Page 24
Controller Software Operation Guide ■ Output Page You can do the following operations on the Output page: ① Multi-View Adjustment: Click to select the desired screen display mode. There are eight modes available: SINGLE-PIP-PBP(1)-PBP(2)-Triple(1)-Triple(2)- Quad(1)-Quad(2). ② PIP Adjustment: In the PIP mode, you can switch the location and size of the PIP and set the user-defined PIP, as shown in the following table.
Page 25
Controller Software Operation Guide Relative Position Height and Width of the Size (Starting Position) Inner Frame Start Point X: 71 Width: 30 Small Start Point Y: 71 Height: 30 Start Point X: 61 Width: 40 Middle Start Point Y: 61 Height: 40 Start Point X: 51 Width: 50...
Page 26
Controller Software Operation Guide ■ System Page You can do the following operations on the System page: ① EDID Mode Control: Click the drop-down list on the right to select EDID mode. ② Firmware Upgrade: Click the folder icon on the right to import the firm- ware upgrade file, then click “Upgrade”...
RS-232 Command The product also supports RS-232 command control. Connect the RS-232 port of the product to a PC with a 3-pin phoenix connector cable. Then, open a Serial Command tool on PC to send ASCII commands to control the product. The ASCII command list about the product is shown as below.
Page 28
RS-232 Command Command Code Function Description Example Feedback Default Output Setting Set Output y Resolution (y=1~2, x=1~14) y=1. output 1 y=2. output 2 1. 4096x2160p60, 2. 4096x2160p50, 3. 3840x2160p60, 4. 3840x2160p50, output 1 reso- 5. 3840x2160p30, 3840x2160p s output y res x! s output 1 res 3! lution: 6.
Page 29
RS-232 Command Command Code Function Description Example Feedback Default Output Setting Set output video keep active pattern. (y=1~2, x=1~2) output 1 VKA s output 1 s output y vka x! y=1. output 1 pattern: black screen vka 1! y=2. output 2 black screen x=1.
Page 31
RS-232 Command Command Function Description Example Feedback Default Code Audio Setting Set output y audio source (y=1~2, x=0~4) y=1. output 1 output audio: y=2. output 2 output 1 audio follow s output y s output 1 x=0. follow window 1 follow window 1 window 1 audio x!
Page 32
RS-232 Command Command Function Description Example Feedback Default Code Single Screen Mode Setting Enable/disable auto switch s output y feature (y=1~2,x=0~1) s output 1 output 1 auto auto switch auto y=1. output 1 auto switch off switch x! y=2. output 2 switch 0! 0.
Page 33
RS-232 Command Command Code Function Description Example Feedback Default Get output y multi-viewer output 1 multi- r output y display mode (y=1~2) r output 1 view: multiview! 1. output 1 multiview! single screen 2. output 2 Select output z one input for one display window for the current Multiview mode.
Page 34
RS-232 Command Command Code Function Description Example Feedback Default Get the border mode ofwindows (y=1~2) 1. output 1 2. output 2 r output 1 output 1 r output y (x=0~4) window 1 window 1 window x border! 0. ALL border! border on 1.
Page 35
RS-232 Command Command Code Function Description Example Feedback Default Set PIP window to user define mode (y=1~2) 1. output 1 2. output 2 s output y PIP output 1 PIP Hstart=(1~100) s output 1 PIP Hstart Vstart 10 10 Vstart=(1~100) 10 10 20 20! Hsize Vsize! 20 20...
Page 36
RS-232 Command Command Code Function Description Example Feedback Default Set output y PBP windows display mode (y=1~2) s output 1 s output y PBP 1. output 1 output 1 PBP mode x! 2. output 2 mode 1 mode 1 mode 1! (x=1~2) 1.
Page 37
RS-232 Command Command Code Function Description Example Feedback Default Set output y triple windows display aspect ratio (y=1~2) s output 1 output 1 triple triple s output y triple 1. output 1 triple aspect full aspect: aspect x! 2. output 2 aspect 1! screen full screen...
Application Example TV or Monitor UHDTV IR Receiver OUT 1 OUT 2 INPUT OPTICAL HDMI OPTICAL HDMI HD 1 HD 2 HD 3 HD 4 RS-232 IR EXT DC 12V Power Supply 2.0 Speakers 2.0 Speakers TV box Audio Amplifier Audio Amplifier or Blu-ray Player page 38...
