olympia electronics GR-433 Quick Start Manual

Self testing non-maintained emergency luminaire

Advertisement

Quick Links

Package Contents
Automatic Operational Test
1
Luminaire
This test includes all the operations that are
1
Mounting Accessories
provided in Manual Operational Test and is
1
Manual
conducted automatically every 15 days and lasts 3
1
seconds.
Label for 3 hours duration
Automatic Autonomy Test
General
The Automatic Autonomy Test is conducted every 6
months and measures the device's back up
These devices are used indoors and outdoors
operation and emergency duration. This test
(ta 40 C) in places where emergency light is needed.
o
includes all functions of the Manual Autonomy Test.
Each device must be permanently connected to
mains power supply. In normal operation the battery
Resetting Errors
is charging. In case of a mains power supply failure,
Activate the magnetic contact for a time space
the device enters emergency mode and the
between 10 and 15 seconds to delete all indicated
illumination LED turns on. When the mains power
errors. Then the luminaire enters regular operation
supply is restored the device turns to normal
mode
operation.
ΑΤΤΕΝΤΙΟΝ!!!
Manual Operational Test
1. Operations for installation, maintainance or
This test can be done by activating the magnetic
testing must be done by authorized personnel
contact briefly (less than 5 seconds). The light source
only.
and the emergency circuit of the device are tested.
2. Always use in any case round mains cable, with a
The manual test can be conducted only if the mains
diameter of 5-10mm (H05RN-F type 2x1mm² or
power supply and the battery are connected. During
any other type, at least equal to it's mechanical
this test period the light source will be lit for
and electrical properties). ATTENTION!! The cable
approximately 3 seconds and the green LED will
must not be deformed in any way (This
flash. The battery must have adequate charge. This
requirement is important to ensure the ΙΡ rating).
test lasts for 3 seconds.
3. The device must be connected to the mains
power supply through a circuit breaker that is
Manual Autonomy Test
depends on the total line's power load.
This test can be done by activating the magnetic
4. In case of battery replacement, it must be
contact for a time space between 5 and 10 seconds. In
replaced by the same type, by the manufacturer
order to be performed, the mains power supply should
or a competent person.
be connected and the battery should be fully charged.
5.
In case of
During this test period the light source will be lit and
months, disconnect the battery by pulling out the
the green LED will flash. This test last for the stated
battery's connector.
duration.
6. t i
I
s not allowed to discard batteries into
common trash bins, they must be discarded
only in battery recycling points. Do not
incinerate.
Indications LED Status
CHARGE
BATTERY
LED
FAULT
FAULT
(green)
(red)
(red)
Description
Normal
Charging
(battery test not possible while charging)
Not charging
Battery/Light Source Test
Battery Fault
Battery not connected
or charger fault
Light Source Fault
Dimensions(mm) 160 x 160 x 77
160
77
160
130
1
1
160
Installation Instructions
First, unfasten the front screw and then pull up to remove the cover.
1
inactive use for a period greater than 2
First, unfasten the four retaining screws, without removing them and then pull up to
remove the diffuser.
2
Note:
Permanently
ON
The arrow
indicates the
UP
Slow Blink
correct mounting direction
Fast Blink
Off
Indifferent
Use a drill bit with a 3mm bit to open the four mounting holes, locating in the plastic
160
base. Place the base on the desired mounting location, mark and drill these four
holes. Fit the four supplied wall plugs and mount the base by using the supplied
77
rubber sealing rings, washers and screws. Pay attention to the orientation of the
base.
98
3
UP
17
4
2
923433000_09_001
A A
B
WALL PLUG
Adhesive
tether loop
Tie-Wrap
Cable Entry
Rubber Gasket
Install the supplied rubber gasket to the plastic base. Make a hole in the center of the rubber
gasket by using a small screwdriver. Pass the mains cable through the rubber gasket. Make
sure that the rubber gasket and the cable is not deformed. This requirement is important to
ensure the IP rating. Connect the mains cable to the therminal blocks: L for live wire, N
for neutral. PE terminal is for termination purposes only. Power supply cables cross section
2
should be 0.3 – 3 mm . Install the supplied plastic tie-wrap to fasten securely the power
cable, in order to anchor it.
Warning!! Isolate the mains power supply before making the connections
4
1 2 3 4
1 2 3 4
1h
3h
(default position)
Rubber
Sealing Ring
The user can select one of the 2 available minimum autonomy durations: 1 hour and 3 hours.
Washer
Screw
The selection must be done while the luminaire is disconnected from AC and battery
supplies. The selection is achieved through Switches 2 & 3 of DS1. Switch 1 & 4 are not used.
One additional label is included in the package for 3 hours duration (180). In case the installer
changes the duration, the default 1 hour (60) printing must replaced with the label.
Please take notice of the orientation of the label.
5
Battery Connection
6
A
7
3
923433000_09_001
Power Connections
N
L
Ν for neutral, L for live wire
DS1
Connect the battery cable to its respective
connector on the PCB.
B
Refit the diffuser and then fasten the four
retaining screws.
923433000_09_001
