Product Description
The insulation monitor RN 5897/010 of the VARIMETER IMD family is a
solution for optimal insulation monitoring of modern IT systems.The device
can be used in the most flexible way for AC, DC and AC/DC systems even
with large leakage capacity to earth (PE). The adjustment of the setting
values is simple and user friendly done on 2 rotary switches on the front of
the device. Via display and LEDs the measured value, device parameters
and device status are indicated easy to read. With a sealable transparent
cover the device is protectet against manipulation.
*)
From firmware version 02.00
All Technical Data in this list relate to the state at the moment of edition. We reserve the right
for technical improvements and changes at any time.
RR 5898
*)
Translation
of the original instructions
Your Advantages
• Preventive fire and system protection
• Detection of symmetric and asymmetric insulation faults
• Quick fault localisation through selective earth fault detection to L+ and L-
• Universal application in non-earthed AC, DC, AC/DC networks
up to AC max. 250 V or DC max. 300 V
• With connection facility of an external coupling device:
RL 5898 for voltages up to AC 400 V / DC 500 V
RP 5898 for voltages up to AC 690 V / DC 1000 V
RR 5898
for voltages up to AC 1000 V / DC 1500 V
*)
• Easy adjustment of response values and setting parameter via
rotational switch and menu display
• Suitable for large leakage capacitances up to 1000 µF
• Optimised reaction time for large leakage capacitances
• Monitoring also with voltage-free mains
• Measuring circuit L(+)/L(-) with broken wire detection (can be switched off)
• Protective conductor PE1/PE2 with broken wire detection
(can't be switched off)
Features
• Insulation monitoring according to IEC/EN 61557-8
• Trigger output for insulation fault locating system
• 2 separate adjustable response thresholds
(using e.g. for pre-Alarm and Alarm)
• Setting range of 1st response value (Pre-Alarm): 20 kΩ ... 2 MΩ
• Setting range of 2nd response value (Alarm): 1 kΩ ... 250 kΩ
• 2 changeover contacts für insulation failures-Pre-Alarm and -Alarm
• Energized or de-energized on trip can be selected for indicator relay
• Display for indication of measured value, device parameters and
device status
• Setting the maximum leakage capacitance to shorten the response time
• Automatic and manual device self-test
• Alarm storage selectable
• Protection against manipulation by sealable transparent cover
• External control input for combined Test-/Reset-button
• 3 wide voltage input for auxiliary voltage
• Width 52.5 mm
Approvals and Markings
2)
Canada / USA
RN 5897 only
1)
RN 5897 and RL / RP 5898 only
2)
Applications
Insulation monitoring of:
• Non-earthed AC, DC, AC/DC networks
• UPS systems
• Networks with frequency inverters
• Battery networks
• Networks with direct current drives
• Hybrid and battery-powered vehicles
• Mobile generator sets
1
1)
AC/DC
03.07.24 en / 892A

Advertisement

loading
Need help?

Need help?

Do you have a question about the VARIMETER IMD Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DOLD VARIMETER IMD Series

  • Page 1 Monitoring Technique VARIMETER IMD Translation Insulation monitor of the original instructions RN 5897/010 Your Advantages • Preventive fire and system protection • Detection of symmetric and asymmetric insulation faults • Quick fault localisation through selective earth fault detection to L+ and L- •...
  • Page 2: Table Of Contents

    Function Diagram Function The device is supplied with DC auxiliary voltage via terminals A1(+) / A2. Switching on the auxiliary voltage (Power-On) is followed by an internal self-test for 12 sec (see „Device test functions“). The test process is visible in the display.
  • Page 3 Function Function Broken wire detection Behavior on faulty connection As described in section "Measuring circut", the measuring circuits L(+)/L(-) When detecting broken wire on terminals L(+)/L(-), the measurement is and the protective conductors PE1/PE2 are constantly monitored for wire disabled. The reaction time could be up to 2 min. The monitoring relays breaks –...
  • Page 4 Default-Setting of Parameters Indicators The colour of the backlight indicates the operating status of the device. Parameter Default-Set Broken wire detect in measuring circuit Off: No auxiliary voltage connected “Broken Wire Detect” Green: Normal operation (Insulation resistance in healthy state) Red: Alarm (measured value below alarm response value, Storing insulation fault message...
  • Page 5: Display Indication

    • The trigger output Y1/Y2 at RN 5897/010 is galvanic separated from the Press test button again rest of the circuit. It determined to be connected to a DOLD insulation or restart the unit by fault location system RR5886 and RR5887. Please do not connect interrupting the auxiliary external voltages.
  • Page 6 Running chart Press button Press button „Set/ESC“ „Set/ESC“ >2s Press button Scroll Down „ ▼“ Set parameters Press button Scroll Up „ ▲“ Parameter 1: Parameter 1: Parameter 1: Broken wire detect in Broken wire detect in Broken wire detect in measuring circuit measuring circuit measuring circuit...
  • Page 7 Technical Data Technical Data Measuring ciruit L(+)/L(-) to PE1/PE2 (without coupling device) Measuring ciruit L1(+)/L2(-) to PE1/PE2 (with coupling device RR 5898 Nominal voltage U AC / DC 0 ... 230 V Nominal voltage U AC 0 ... 1000 V Max.
  • Page 8: Vibration Resistance

    Technical Data Classification to DIN EN 50155 General Data Vibration and shock resistance: Category 1, Class B IEC/EN 61373 Operating mode: Continuous operation Service temperature classes: OT1 compliant Temperature range Protective coating of the PCB: No Operation: - 30 ... + 60 °C (at range 0 …...
  • Page 9: Energized On Trip

    Standard Types RN 5897.12/010/61 DC 12 ... 24 V Article number: 0070013 • Auxiliary voltage: DC 12 ... 24 V RN 5897.12/010/61 AC/DC 24 … 60 V Article number: 0070011 • Auxiliary voltage: AC/DC 24 … 60 V RN 5897.12/010/61 AC/DC 85 …...
  • Page 10: Connection Example

    Connection Example Ungrounded mains Single phase mains, isolated from earth 3/N AC 400V/230V 16...1000Hz AC 0...250V 16...1000Hz Setting of type of network Setting of type of network 3N AC External coupling device: External coupling device: VSG1 L(+) L(-) VSG2 A1(+) VSG1 L(+) L(-)
  • Page 11 Connection Example Single phase mains, isolated from earth RL5898: AC 0...440V 16...1000Hz RP5898: AC 0...760V 16...1000Hz RR5898: AC 0...1150V 16...1000Hz L1(+) L2(-) Setting of type of network: RL5898 External coupling device: RP5898 RR5898 VSG1 L(+) L(-) VSG2 VSG1 L(+) L(-) VSG2 A1(+) RN5897/010...
  • Page 12 Accessories RP 5898/61: RR 5898: Article number: 0066944 Article number: 0069925 • Coupling device for RN 5897.12/010 • Coupling device for RN 5897.12/010 (from firmware version 02.00) • Extension of nominal voltage range U • Extension of nominal voltage range U to DC 1000 V, AC 690 V to DC 1500 V, AC 1000 V •...
  • Page 13 Characteristics M11605 03.07.24 en / 892A...
  • Page 14 Notice 03.07.24 en / 892A...
  • Page 15 Notice 03.07.24 en / 892A...
  • Page 16 E. Dold & Söhne GmbH & Co. KG • D-78120 Furtwangen • Bregstraße 18 • Phone +49 7723 654-0 • Fax +49 7723 654356 dold-relays@dold.com • www.dold.com 03.07.24 en / 892A...
