Chapter 6 Cisco ASR 1006 Router Overview and Installation

Rear View

Figure 6-2
installed.
Figure 6-2
5
4
1
2
3
4
Internal fans draw cooling air into the chassis and across internal components to maintain an acceptable
operating temperature. (See
grounding lug is located on the side of the chassis. Two power supplies, either two AC power supplies
or two DC power supplies, are accessed from the rear of the router.
Note You have already unpacked your chassis and read all the site requirements for your new equipment.
Proceed with the installation.
Note Do not combine AC and DC power supplies in the same chassis.
OL-13208-09
shows the rear of the Cisco ASR 1006 Router with the ASR1006-PWR-AC power supply
Cisco ASR 1006 Router Rear View with the AC Power Supply (ASR1006-PWR-AC)
AC power supply fan
AC power supply DB-25 alarm connector—A
female DB-25 sub connector which enables
you to attach an external alarm monitoring
facility to the router, thus supporting a
telco-style of handling alarm conditions in the
router.
For a description of the DB-25 alarm
connector, see the "How Cisco ASR1000-RP
Alarm Monitoring Works" section on
page 2-21.
Cable tie wrap tabs
AC power supply captive screws
Figure
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
6 7
100-240V~ 16-7A
50-60HZ
This unit might have more than
one power supply connection.
All connections must be removed
to de-energize the unit.
3
5 AC power supply handle
6
AC power inlet
7
AC power supply Standby switch. A Standby
switch is not considered a disconnect.
8
AC power supply LEDs
6-2.) The fans are located at the rear of the chassis. A two-hole
Cisco ASR 1006 Router Description
8
OUTPUT INPUT INPUT
FAIL OK OK
ALARMS
60V
1A MAX
2 1
6-3
