2 Setup
CAUTION!
Risk of Injury or Damage
If clamping lever or handle and housing screws are fitted too
tightly or replaced by hardware not approved by Invacare,
IDC internal parts might get damaged. This could lead to an
unintended drive signal and the IDC could start running by
itself when IDC is controlling the wheelchair.
— Do NOT tighten handle screws at all. Handle may get
stuck or blocked.
— Tighten clamping lever and housing screws hand-tight
only (max. 6 Nm).
— Tighten screw on monoblock to 1 Nm.
— Only use clamping lever and screws provided by Invacare
for fixing IDC.
— Test power wheelchair before use.
2.1 Installing / Removing the IDC
NOTICE!
If an IDC is installed it will increase the footprint of the
wheelchair. When driving without attendant, the IDC could
get damaged, for example, when driving backwards against
an obstacle.
— Remove or fold in the IDC before driving without
attendant.
1643411-C
Installing
1. Position the adapter bracket A onto
A
2. Push the IDC downwards until it locks
B
Removing
1. Press the red KLICKfix button A and
A
2. Lift the IDC upwards to remove it from
Folding in the IDC
1. Remove the IDC from the adapter.
A
B
2. Press the red KLICKfix button A and
C
3. Position the lower edge of the adapter
4. Release the KLICKfix button.
the KLICKfix adapter B.
automatically.
hold it.
the adapter.
hold it.
bracket B inside the lower fixation of
the adapter C.
