Invacare® LiNX
The maximum speed of the power wheelchair can be set by the user to
match the personal requirements and the surrounding conditions. The
current maximum speed set is displayed on the power wheelchair
speed display a nd can also be preset there. You can carry out further
fine adjustments to the maximum speed on the IDC using the speed
potentiometer.
Setting Maximum Speed
1. Set maximum speed with speed
2. Pull trigger lever to start driving.
A
Controlling Speed
The more the trigger lever is pulled, the
faster the power wheelchair drives.
To brake quickly, simply let go of the handle. The power
wheelchair brakes. If you pull the trigger lever with full force,
the power wheelchair carries out an "Emergency Stop".
9
potentiometer A.
3.3 "Emergency Stop" Function
When using Emergency stop function while driving, the power
wheelchair brakes harder, than when you just let go of the
trigger lever.
There are three ways to emergency stop the power wheelchair.
If the power wheelchair needs to be
stopped immediately due to a hazard
situation, pull the trigger lever A firmly as
far as possible. This causes an immediate
forced drive switch-off. Once you release
the trigger lever A and the attendant LED
A
stops flashing, you can start to drive the
power wheelchair again immediately.
Alternatively, press "forwards or reverse"
push button to stop the power wheelchair.
The attendant LED stops flashing and you
can start to drive the power wheelchair
again immediately.
Or, press the power button. The power
wheelchair needs to power up, before you
can drive the power wheelchair again.
1643411-C
