Alarm.Com ADC-AC-X200 Installation Manual page 4

Input monitor expansion module for x200

Advertisement

Wiring
Connections
TB1-1
IN+
INPUT 1
Input 1
TB1-2
IN-
TB1-3
IN+
INPUT 2
Input 2
TB1-4
IN-
TB1-5
IN+
INPUT 3
Input 3
TB1-6
IN-
TB1-7
IN+
INPUT 4
Input 4
TB1-8
IN-
TB1-9
IN+
INPUT 5
Input 5
TB1-10
IN-
TB2-1
IN+
INPUT 6
Input 6
TB2-2
IN-
2
TB2-3
IN+
INPUT 7
Input 7
TB2-4
IN-
TB2-5
IN+
INPUT 8
Input 8
TB2-6
IN-
TB3-1
NOT USED
Relay 1 Normally
TB3-2
NO
Open Contact
TB3-3
RELAY 1
C
Relay 1 Common Contact
Relay 1 Normally
TB3-4
NC
Closed Contact
TB4-1
IN+
INPUT 9
Input 9
TB4-2
IN-
TB4-3
IN+
INPUT 10
Input 10
TB4-4
IN-
TB4-5
IN+
INPUT 11
Input 11
TB4-6
IN-
TB4-7
IN+
INPUT 12
Input 12
TB4-8
IN-
TB4-9
IN+
INPUT 13
Input 13
TB4-10
IN-
TB5-1
IN+
INPUT 14
Input 14
TB5-2
IN-
TB5-3
IN+
INPUT 15
Input 15
TB5-4
IN-
TB5-5
IN+
INPUT 16
Input 16
TB5-6
IN-
TB6-1
NOT USED
Relay 2 Normally
TB6-2
NO
Open Contact
TB6-3
RELAY 2
C
Relay 2 Common Contact
Relay 2 Normally
TB6-4
NC
Closed Contact
TB7-1
TMP+
TMP
Tamper
TB7-2
TMP-
TB7-3
AC+
AC
AC Fail
TB7-4
AC-
TB7-5
BT+
BT
Battery Fail
TB7-6
BT-
TB7-7
GND
Input Power Ground
12-24 VDC
Input Power Ground
TB7-8
VIN
(from local power)
3
