Summary of Contents for Ryobi R18PHT130

  • Page 1 FRONT PAGE R18PHT130...

  • Page 2: Intended Use

    ■ When operating a power tool outdoors, use an IMPORTANT! extension cord suitable for outdoor use. Use of a It is essential that you read the instructions in this manual cord suitable for outdoor use reduces the risk of electric before assembling, operating, and maintaining the shock.

  • Page 3: Additional Safety Warnings

    tool or these instructions to operate the power tool. POLE HEDGE TRIMMER SAFETY WARNINGS Power tools are dangerous in the hands of untrained ■ Do not use the hedge trimmer in bad weather users. conditions, especially when there is a risk of ■...

  • Page 4: Transporting Lithium Batteries

    operator requires a clear view of the work area to identify Store the product in a cool, dry, and well-ventilated place potential hazards. that is inaccessible to children. Keep the product away from corrosive agents, such as garden chemicals and ■...

  • Page 5: Symbols In This Manual

    Do not expose the product to rain or damp conditions. To prevent serious injury, do not touch the cutting blades. Wear non-slip, heavy-duty gloves. Wear non-slip safety footwear when using the product. Regulatory Compliance Mark (RCM). The product meets applicable regulatory requirements.
  • Page 7 R18PHT130 Harness Shaft coupling Telescopic release latch Blade Operator's manual Telescopic pole Angle button release Powerhead shaft Shaft coupling Harness hanger Lock-out trigger On/Off trigger Battery port Blade cover HEDGESWEEP debris sweeper Extension pole Screwdriver Socket wrench Spray lubricant Battery pack...
  • Page 8 Always wear eye, ear, and head Connect the telescopic pole to the powerhead shaft. protection, non-slip, heavy-duty gloves, and non-slip safety footwear when using the product. WARNING: Keep bare hands away Slide HEDGESWEEP debris Remove the blade cover. from the blades at all times. sweeper over the blade.
  • Page 9 Slide the shaft coupling downwards Connect the pole hedge trimmer attachment to the telescopic pole. Turn the shaft and turn it counterclockwise to secure coupling clockwise to secure the connection. the connection. Attach the harness to the harness Insert the battery pack into the battery Slide the lock-out trigger forwards, and hangers.
  • Page 10 Operating the Installing the p. 11 p.14 product extension pole Removing the Cleaning the Installing the blade Storing the product p. 16 p. 18 p. 19 p. 20 blade product...

  • Page 11: Operating The Product

    ≤60˚ ≥15m (50ʹ) OPERATING THE PRODUCT DANGER! Risk of electrocution! Do not operate within 10 m of overhead electrical lines. Position the product at an angle of 60° or less, depending on the specific situation. Keep bystanders at least 15 m away. WARNING: Always use two hands to operate the product.
  • Page 12 2. Slide the shaft coupling downwards and turn it counterclockwise to secure the connection. 3. Connect the hedge trimmer attachment to the telescopic pole. 4. Lay the product on the ground. 5. Press the angle button release and adjust the pole of the required working angle. NOTE: The working angle of the pole hedge trimmer can be adjusted to -60°, -30°, 0°, 30°, 60°, and 90°.
  • Page 13 6. Slide HEDGESWEEP debris sweeper over the blade. Remove the blade cover. 7. Attach the harness to the harness hangers. NOTE: The harness has a quick- release mechanism. Practice using it before you start using the product. Its correct use may prevent serious injury in the case of an emergency.
  • Page 14 INSTALLING THE EXTENSION POLE 1. Press the latches and remove the battery pack from the battery port. 2. Connect the extension pole to the telescopic pole. Turn the shaft coupling clockwise to secure the connection. WARNING: Do not use more than one extension pole at any time.
  • Page 15 WARNING: Always use two hands to operate the product. Hold the product with one hand on the front handle and the other hand on the rear handle. 6. Insert the battery pack into the battery port until the latches click into place. 7.

  • Page 16: Removing The Blade

    REMOVING THE BLADE 1. Press the latches and remove the battery pack from the battery port. 2. Turn the shaft coupling counterclockwise and slide the pole hedge trimmers forwards to remove it from the extension pole. 3. Turn the pole hedge trimmer attachment upside down.
  • Page 17 6. Using a socket wrench, turn the blade shaft screws counterclockwise to loosen them. 7. Remove the blade shaft screws from the blade. 8. Remove the blade from the pole hedge trimmer attachment. Maintenance...

  • Page 18: Installing The Blade

    INSTALLING THE BLADE 1. Turn the pole hedge trimmer attachment upside down before installation. Install the blade to the pole hedge trimmer attachment. 2. Install the blade shaft screws to the blade. 3. Using a socket wrench, turn the blade shaft screws clockwise to tighten them.

  • Page 19: Cleaning The Product

    CLEANING THE PRODUCT 1. Press the latches and remove the battery pack from the battery port. 2. Remove HEDGESWEEP debris sweeper. 3. Clean HEDGESWEEP debris sweeper and body and handles of the product with a soft, dry cloth. Clean the blades with a stiff brush.

  • Page 20: Storing The Product

    STORING THE PRODUCT WARNING: Make sure that the product is clean before storing. 1. Press the latches and remove the battery pack from the battery port. 2. Install the blade cover. 3. Turn the shaft coupling counterclockwise, and remove the pole hedge trimmer attachment from the telescopic pole.

  • Page 21: Product Specifications

    Compatible battery packs RB1815C, RB1820C, RB1840C, RB1840X, RB18L13, RB18L26, RB18L15, RB18L15A, RB18L15B, RB18L20, RB18L20A, RB18L25, RB18L25A, RB18L30, RB18L30A, RB18L40, RB18L40A, RB18L50, RB18L50A, RB18L60, RB18L60A, RB18L90, RB18L90A NOTE: Visit your local special orders desk or contact RYOBI customer service for replacement parts.
  • Page 24 Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. HEDGESWEEP is a trade mark of Techtronic Outdoor Products Technology Limited. 961476036-01...
