INSTALLATION
INSTRUCTIONS
3312834.000
Form No. 3312834.000 10/08
(French 3312835.000)
©2008 Dometic, LLC
LaGrange, IN 46761
6403 Series Roof-Top Air Conditioner
Part No. 3107541 Analog Relay Kit
3105935 Quick Cool Return Air Cover
3308120 Genesis Air Filtration System
THIS UNIT IS DESIGNED FOR OEM INSTALLATION
ALL INITIAL INSTALLATIONS MUST BE APPROVED BY THE SALES DEPT.
This manual must be read and
understood before installation,
adjustment, service, or mainte-
nance is performed. This unit must
be installed by a qualifi ed service
technician. Modifi cation of this
product can be extremely hazard-
ous and could result in personal
injury or property damage.
Important:
These instructions must stay with
unit. Owner read carefully.
USED WITH
WITH ANALOG THERMOSTAT
DUCTED
used with one of the following:
3105007 Return Air Cover
Lire et comprendre ce manuel vant de
procéder à l'installation, à des réglag-
es, de l'entretien ou des réparations.
L'installation de cet appareil doit être
effectuée par un réparateur qualifi é.
Toute modifi cation de cet appareil
peut être extrêmement dangereuse et
entraîner des blessures ou dommages
matériels.
RECORD THIS UNIT INFORMATION FOR
FUTURE REFERENCE:
Model Number
Serial Number
Date Purchased
Models
640312.301
640315.301
640315.306
Advertisement
Table of Contents
Related Manuals for Dometic 6403 Series
Summary of Contents for Dometic 6403 Series
- Page 1 RECORD THIS UNIT INFORMATION FOR FUTURE REFERENCE: Model Number Serial Number Date Purchased 6403 Series Roof-Top Air Conditioner SERVICE OFFICE Dometic, LLC USED WITH 2320 Industrial Parkway Part No. 3107541 Analog Relay Kit Elkhart, IN 46516 WITH ANALOG THERMOSTAT 574-294-2511...
-
Page 2: Safety Instructions
Analog Ducted Installation Instructions SAFETY INSTRUCTIONS 1. GENERAL INFORMATION Product features or specifi cations as described or il- This manual has safety information and instruc- lustrated are subject to change without notice. tions to help users eliminate or reduce the risk This "Air Conditioner"... - Page 3 A. Read Installation and Operating instructions carefully Dimension Are before attempting to start your unit installation. Nominal Keep Area Free Of B. Dometic, LLC will not be liable for any damages or injury 12" Obstructions incurred due to failure in following these instructions. 14-1/4" x 14-1/4"...
-
Page 4: Air Distribution System Instal- Lation
This properly; however, these alternate confi gurations insulation must be R-7 minimum. and methods must be approved by the Dometic, LLC C. Ducts and their joints must be sealed to prevent con- in writing. The following instructions are based upon... - Page 5 Analog Ducted Installation Instructions AIR DISTRIBUTION DUCT SIZING & DESIGN CHART Return Air Cover Model 3105007 3308120 3105935 Genesis Air Filtration Standard Grill System Roof Cavity Depth 2.0 In. Min. - 5-1/2 In. Max. 2.0 In. Min. - 5-1/2 In. Max. Duct Cross Sectional Area 21.0 Sq.
- Page 6 Analog Ducted Installation Instructions Duct Size And Requirements For 3105007 And 3105935 Return Air Cover FIG. 4 Register Required Register Required Unit Registers Short Duct Run Minimum 8 Min.-- 12 Max. (Per 1/3 Total Duct Length Front Unit) Total Outlet Air Area Return 14 Sq.
- Page 7 Analog Ducted Installation Instructions 7. PLACING THE UNIT ON THE ROOF FIG. 8 A. Remove the unit from the carton and discard carton. The unit mounting bolts are in a separate plastic bag Snap The Open Loop with the control kit. Be sure to place this in the RV. Of Spring Clip On Second Tube In Center OF Evapora-...
-
Page 8: Installation Of Unit
Analog Ducted Installation Instructions 1. Connect the previously run positive (+)12 VDC Center Unit From Below FIG. 10 to the red wire labeled +12V protruding from the Connect AC Power relay control box (Do not connect wires if using the Leads In Control Box 3308120 Genesis Air Filtration System Return Air Kit Return Air Kit). - Page 9 Analog Ducted Installation Instructions 1. Installation of Ceiling Template b. Remove the backing paper from double sided a. Check gasket alignment of the unit over the tape located on ceiling template. See FIG. roof opening and adjust if necessary. Unit may be moved from below by slightly lifting and sliding.
- Page 10 Analog Ducted Installation Instructions B. INSTALLING UNIT WITH 3308120 GENESIS AIR FIG. 17 FILTRATION SYSTEM See section 10-A for 3105007 and 3105935 installa- tion. FIG. 19 Foam Divider Ceiling Template • Excess width is intended to seal the divider Slider plate to the sides of the 14-1/4"...
- Page 11 Analog Ducted Installation Instructions c. Peel the paper off of the foam divider and stick Use Aluminum Foil Tape To Seal The FIG. 23 it in place on the center of the rear edge of the Foam Divider To The Sides of 14-1/4" return air opening on the ceiling template See.
- Page 12 Analog Ducted Installation Instructions 12. RELAY KIT FIELD WIRING DIAGRAM COOLING/FURNACE UNIT FIELD WIRING DIAGRAM AIR CONDITIONERS...
