Proton S70 2024 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the S70 2024 and is the answer not in the manual?

Questions and answers

Related Manuals for Proton S70 2024

Summary of Contents for Proton S70 2024

  • Page 2 (1-800-888-398) PROTON EDAR SDN. BHD. Centre of Excellence Complex Km33.8 Westbound Shah Alam Expressway 47600 Subang Jaya , Selangor Darul Ehsan , Malaysia.

  • Page 3: Notice To Users

    Multimedia System Operation Multimedia System Operation Operation Instructions Therefore, it is up to the driver to decide which route is the most Notice to Users suitable route. • Do not use mobile phone while • The speed limit stipulated by current driving.

  • Page 4: Safety Information

    Multimedia System Operation Multimedia System Operation Safety Information Asterisk This manual provides relevant information The asterisk “*” symbol following a title of all models. Due to the variety of or name indicates that the configuration configurations, the descriptions in this or function described is equipped on manual may differ from the actual one certain models only.

  • Page 5: Safety Precaution

    Multimedia System Operation Multimedia System Operation Safety Precaution When driving, make sure that the sound volume inside the vehicle will To avoid electric shock, please not affect your ability to hear external do not disassemble it without sounds. authorization. If any internal parts are Handle with care, no heavy objects damaged, please contact the professional can be stacked on this product.
  • Page 6 It is up to the driver to compliance with such laws and regulations decide which is the most suitable currently in force. PROTON reserves the route. right to make such amendments and/ • The speed limit stipulated by current...
  • Page 7 Multimedia System Operation Multimedia System Operation Notes for Navigation PROTON has the right not to provide the service for you in the following cases: Description of Terminology • Violation of local laws and regulations. • Point of Interest (POI): Feature point •...
  • Page 8 “Warning” operation. • Satellite signal reception disclaimer: PROTON will not be responsible for any In general, the navigation map can inconvenience or accident caused by calculate your exact location after negligence of the stated warnings.

  • Page 9: Use Instructions

    Multimedia System Operation Multimedia System Operation Safe Navigation illustrations show conditions which may affect the normal reception Do not operate the navigation function of satellite signals and cause errors. while driving to avoid distraction and cause safety problems. The navigation setup should be done in advance or operated by passengers.
  • Page 10 Multimedia System Operation Multimedia System Operation Notes Before Using driving. This may cause negligent Bluetooth driving that can result in an accident. • Avoid looking at the screen for Description of The Wireless long periods while driving. This Bluetooth Technology is dangerous and may cause an •...
  • Page 11 Multimedia System Operation Multimedia System Operation Devices And Operation Steering Wheel Control Buttons The steering wheel control buttons for multimedia unit is located on the left and right side (Multi-control Function Buttons) of the steering wheel. Buttons Short Press Long Press Home button Press this button briefly to return to the previous menu or...
  • Page 12 Multimedia System Operation Multimedia System Operation Buttons Short Press Long Press Mute button Short press to mute or unmute the audio source. Right Selection Press this button to select items To seek next station button (Next) rightward in the main menu. continuously and to fast forward the song or Press to seek or switch to the :...

  • Page 13: Touch Screen Operation

    Multimedia System Operation Multimedia System Operation Touchscreen Operation Finger Gestures Action Tap : Activate an application, activate button functions and locate the progress bar Horizontal scroll or swipe : Move or drag a page to the left or right Double tap with one finger : to enter the interface or apps Squeeze inwards : squeeze using two fingers inwards to zoom in...

  • Page 14: System Introduction

    Multimedia System (Type I) Multimedia System (Type I) System Introduction System Start-up When the power of the system is OFF, turn the ignition to ACC or ON position and the multimedia system will start automatically. A start-up image and a warning message will pop up on the multimedia screen.
  • Page 15 Multimedia System (Type I) Multimedia System (Type I) Homepage (Home Screen) The home screen is designed to give you the experience similar to that of Android devices. On the homepage, at the most left side widget is set for navigation and the middle / right side widgets are for available applications in multimedia unit.
  • Page 16 Multimedia System (Type I) Multimedia System (Type I) The default setting for homepage is night mode. See Display at Setting section to change the background mode between day mode and night mode. The day mode will provide brighter background as following: Recent used apps widget will display default functions (apps) during its first used, current function is displayed on the far left and other functions will display to the right in turn, recording the last four to eight recent used apps interface.
  • Page 17 Multimedia System (Type I) Multimedia System (Type I) on top right. There are 2 sizes of widget displayed for weather app as following. Recent used apps widget : displays most 8 recently used functions starting from left to right. Default location is on lower right of the homepage screen. Widget Editing Screen •...
  • Page 18 Multimedia System (Type I) Multimedia System (Type I) Sample Layout 2 Sample Layout 3 • Select Widget to open widget size selection interface. Here, users can design homepage with flexibility by choosing from various widget sizes as shown below. This function allows user for creating a personalized and functional homepage layout that meets individual needs perfectly.
  • Page 19 Multimedia System (Type I) Multimedia System (Type I) Tap 4x2 tab to set the widget with this size. Tap 4x4 tab to set the widget with this size. Tap 6x4 tab to set the widget with this size.
  • Page 20 Multimedia System (Type I) Multimedia System (Type I) Apps List Interface Tap Recent used apps widget or swipe the screen left/right to enter the app list interfaces with selection of apps that may entertain and enhance your driving experience. App list interface includes Media, Image and Video Entertainment, Online Navigation, VR Voice recognition, Weather and more Apps that meet most driving scenarios.
  • Page 21 Multimedia System (Type I) Multimedia System (Type I) Apps List Folder Creation Hold and drag one apps icon onto another to create folder. Once a folder is created, tap on the folder to edit its name. Clicking or tap outside the folder area will save the new name automatically.

  • Page 22: Drop-Down Menu Bar

    Multimedia System (Type I) Multimedia System (Type I) Drop-down Menu Bar Swipe down from top of the screen to show the drop-down menu bar. All functions can be switched on/off quickly including quick configure to Wi-Fi, Bluetooth, Hotspot, Screensaver, other vehicle settings, screen brightness and volume adjustment. Long press any shortcut icons to add/delete the shortcuts to/from the drop-down menu bar.

  • Page 23: Notification Center

    Multimedia System (Type I) Multimedia System (Type I) Notification Center User will be able to read notifications and messages which can be viewed later or instantaneously by tapping the top right corner of the multimedia unit screen. New message prompt (pop-up) will display for 10 seconds and disappear automatically, some special messages need users to slide to delete it.

  • Page 24: Bluetooth Pairing And Connection

    Multimedia System (Type I) Multimedia System (Type I) Phone Tap to open Phone app at homepage or from app list interface. Before making a call via multimedia unit, it is advised to connect the phone via bluetooth pairing. Bluetooth Pairing and Connection Tap Setting →...
  • Page 25 Multimedia System (Type I) Multimedia System (Type I) Dialing Various methods of making a call using the multimedia unit are as follows. Tap the name or dial and then tap the phone icon to start dialing: Call via keypad. Call via contacts. Call via recent calls.
  • Page 26 Multimedia System (Type I) Multimedia System (Type I) Search for number Call via VR Voice. After awakening the VR Voice, calls can be made via the voice command. Refer to Voice Recognition (VR) section for setting and voice commands. Answering and Hanging Up Answering and hanging up calls can be done via steering wheel control buttons (the multi-function control buttons at the steering wheel).
  • Page 27 Multimedia System (Type I) Multimedia System (Type I) Bluetooth phone call interface For multiple calls, a display of callers will be shown and you can answer, hold or reject. Hang up first call and answer second incoming call Hold on the call and answer second incoming call Reject the second incoming call To answer and hang up directly via VR Voice without awakening it, please see Voice Recognition (VR) section for voice commands.
  • Page 28 Multimedia System (Type I) Multimedia System (Type I) Multimedia Tap to open Media app at homepage or from app list interface to enter the media interface and select between Radio, USB or BT (bluetooth) as source of multimedia entertainment. Radio In the media interface, tap Radio to enter the radio interface to seek and play the preferred radio station.
  • Page 29 Multimedia System (Type I) Multimedia System (Type I) USB and Bluetooth Music In the media interface, tap USB to enter the USB music interface and play audio file in the USB flash drive. Make sure to connect the USB flash drive to USB port first. Tap USB to enter the USB music interface Display song name, artist name and album name (if available).
  • Page 30 Multimedia System (Type I) Multimedia System (Type I) Folder Singer (Artis) Album...
  • Page 31 Multimedia System (Type I) Multimedia System (Type I) Whole (see all files) Bluetooth Music Audio files from a Bluetooth device can be played via Bluetooth connection with the multimedia unit. In the media interface, tap BT to enter the bluetooth interface to play audio file in the connected bluetooth media device.
  • Page 32 Multimedia System (Type I) Multimedia System (Type I) Photo Tap Photo app at homepage or from the app list interface to browse available photos from local drive and USB flash drive. The multimedia system supports the following photo image file formats: JPG, JEPG, PNG, GIF (static) and BMP.
  • Page 33 Multimedia System (Type I) Multimedia System (Type I) Transferring Image File - USB to Multimedia Unit Long press on any image will enter to the edit mode. In this mode, the photos and images files can be transferred between USB flash drive to the local drive of the multimedia unit. Select the image that need to be transferred (one by one or use select all).
  • Page 34 Multimedia System (Type I) Multimedia System (Type I) Transferring Image File - Phone to Multimedia Unit The photo files can also be transferred via phone to multimedia unit. Tap mobile phone transfer icon on top left of the Photo interface. Connect phone to multimedia unit’s hotspot by tapping the ‘Turn on IHU’s hotspot’.
  • Page 35 Multimedia System (Type I) Multimedia System (Type I) Videos Tap Video app at homepage or from the app list interface to browse available videos from local drive (multimedia unit storage) and USB flash drive. At Video interface, the chosen video can be played in full screen and non full screen. The file name is displayed on the top right of the screen, next to return button.
  • Page 36 Multimedia System (Type I) Multimedia System (Type I) Please be aware that the multimedia unit will not allow videos to be played during driving. Hence, the above reminder will be displayed if it was found that the vehicle is currently in drive mode.

  • Page 37: Starting The Navigation System

    Multimedia System (Type I) Multimedia System (Type I) Navigation Starting the Navigation System After starting up, tap Navigation widget or say the voice command “Open Navigation” to run the navigation system. There are two modes in the navigation system: • Free navigation mode: No destination is set after you enter the navigation system.
  • Page 38 Multimedia System (Type I) Multimedia System (Type I) GPS signal status : Displays the GPS signal strength from Good, Weak or None. Search Destination : Search for a destination by entering keywords or search for nearby facilities such as dining, accommodation, shopping, entertainment, and etc. Vehicle logo : Displays the current precise location and the orientation of the front of the vehicle.
  • Page 39 Multimedia System (Type I) Multimedia System (Type I) Route Navigation Interface Set destination to enter route navigation interface. On the route navigation interface, touch anywhere on the map to enter route navigation touch screen, which will display the following operation buttons. Route overview : Tap this icon to enter route overview mode.
  • Page 40 Multimedia System (Type I) Multimedia System (Type I) Along the route: Tap to search for nearby amenities such as parking lots and coffee shops; or to set the amenities as stop point along the route. Route edit: Tap to edit current route, such as adding, deleting and changing route; or to adjust the sequence of routes.
  • Page 41 Multimedia System (Type I) Multimedia System (Type I) Search Destination If the vehicle is connected to the network, the online map data can be used when searching a destination. Otherwise, the search result is based on the local map data. Otherwise, the search result is based on offline map data.Therefore, the results of online and offline search may be slightly different.
  • Page 42 Multimedia System (Type I) Multimedia System (Type I) Keyword Search (1) Enter keywords such as “hotel”and the search results will be displayed. Then, select an address to view the search location in the map. View Search Location Select an address to view search location in the map as below. Quick fact : Tap to show the address, location, telephone and other information of the destination.
  • Page 43 Multimedia System (Type I) Multimedia System (Type I) Filter Query Results If more search results appear, you can select categories on the left side filter menu for quick search results. Planning and Selecting Routes Navigation routes to destination will be provided on this interface with comparison information including expected arrival time, total distance, and numbers of traffic light.
  • Page 44 Multimedia System (Type I) Multimedia System (Type I) Along the route : To view amenities such as parking lot and coffee shop; set related amenities as pathway. Route option : Change route planning preferences. Show weather : Show weather information along the route. Show R&R : Show services area along the route.
  • Page 45 Multimedia System (Type I) Multimedia System (Type I) View and Navigate to Recent Destination (5) & (6) Tap the recent destination list on Search Main Interface to view and directly navigate to the chosen previously navigated destination (routed navigation). Alternative way is by tapping the icon to view the previously navigated destination (recent destination) on the map and then navigate.

  • Page 46: Route Planning

    Multimedia System (Type I) Multimedia System (Type I) Route Planning If current destination has already been set, user can add pathway by using relevant keywords and pinning on the map to re-plan the route. Tap anywhere on the map and tap on the Destination to see as below: …...
  • Page 47 Multimedia System (Type I) Multimedia System (Type I) Navigation Alert When navigation is active, image will be zoomed in when passing turn junctions. When approaching destination, navigation system will automatically recommend nearby parking lot for you. You can view parking lot on the map and click the “ ”...
  • Page 48 Multimedia System (Type I) Multimedia System (Type I) Navigation Update Please visit an authorised PROTON service outlet and ask the staff to update your offline map data. Online Map Data Update If the navigation system detected a new map data need to be updated to the system, an online full map data update will be triggered when launching the navigation.
  • Page 49 • If the network connection is poor, try again several times. • If the above attempts still fail, please contact your authorised PROTON service outlet. Step 5 : If the message Map Download Failed is displayed during the download process,...
  • Page 50 • If the network connection is poor, try again several times. • If the above attempts still fail, please contact your authorised PROTON service outlet. Step 6 : Once the progress reaches 100%, the download has completed. The system will start local update and install, as shown below.
  • Page 51 • If multiple attempts fail, restore factory settings and download again. • If the above attempts still fail, please contact your authorised PROTON service outlet. Step 8 : After the installation has completed, the following screen will be displayed, indicating that the map data update and installation of the entire map is completed.
  • Page 52 Multimedia System (Type I) Multimedia System (Type I) Difference in Map Versions If there is offline map data in the vehicle, but the version of the map data is old, when the car is successfully connected to the Internet, the navigation can automatically determine the age of the map data.
  • Page 53 Multimedia System (Type I) Multimedia System (Type I) Map Report In the settings interface, you can use “Map feedback” as shown below if you would like to report about location on the map. … Tap “ ” → Settings → Map feedback. Select “New place” for reporting new places or select “Place wrongs”...
  • Page 54 Multimedia System (Type I) Multimedia System (Type I) Report a New Place If you find a new place but it does not exist in the map data, you can use New place in Map feedback interface above to report this new place. The Feedback new place interface consist of : I am here : Report current location of the vehicle as a new place.
  • Page 55 Multimedia System (Type I) Multimedia System (Type I) The Feedback wrong place interface consist of : • Type : Select error type between non-existent place or wrong information recorded. Name : Enter error place name. • • Position : Identify position of error on the map. •...
  • Page 56 Multimedia System (Type I) Multimedia System (Type I) The A-Store supports search inputs. Individual apps can be downloaded, updated, installed, and deleted. For example, if you select Theme from the A-Store main interface, the multimedia screen display will go to Theme interface for downloading the new update or to view the theme details.

  • Page 57: Member Center

    Member Center manually. The PROTON Link application with the associated account linked to the vehicle upon purchase can also be used to scan the QR code displayed on the multimedia unit to login.
  • Page 58 Multimedia System (Type I) Multimedia System (Type I) Internet data and purchased data can also be viewed in the Member Center. Weather Tap Weather widget in the homepage or tap Weather app at app list interface to enter weather interface. The following will be displayed when using the weather app.
  • Page 59 Multimedia System (Type I) Multimedia System (Type I) Theme Tap Theme app in the App List to enter the interfaces for theme, wallpaper, screensaver, and me (personalized interface). Switch Theme Tap Theme app → Theme to open theme interface. Choose from a selection of themes and switch between them for more personalization options according to user preferences.
  • Page 60 Multimedia System (Type I) Multimedia System (Type I) Switch Wallpaper Tap Theme app → Wallpaper to open wallpaper interface. Choose from the selected wallpapers and switch more personalized options between them according on user preferences. Click on the preferred wallpaper to select and see its details. Click apply and confirm the selection to switch the wallpaper.
  • Page 61 Multimedia System (Type I) Multimedia System (Type I) Switch Screensaver Tap Theme app → Screensaver to open screensaver interface. Switch to preferred screen saver and set screensaver for the screen lock page. Click on the preferred screensaver to select and see its details. Click apply and confirm the selection to switch the screensaver.
  • Page 62 Multimedia System (Type I) Multimedia System (Type I) Tap Theme app → Me to enter user personalized (Me) interface. The Me interface supports classification by “Theme”, “Wallpaper”, and “Screensaver” to view, edit and delete the content that currently has been downloaded or purchased on the vehicle multimedia unit.
  • Page 63 Multimedia System (Type I) Multimedia System (Type I) Calendar Tap Calendar app at in the App List to enter the calendar interface and view the selected date calendar as well as personalized schedule.Calendar can be viewed by year, month, and date. Holiday information is also available. Calendar view by month Calendar view by date Schedule created in the multimedia unit can be displayed with dates and annotations.

  • Page 64: Voice Recognition (Vr)

    Common Voice Command Wake Up There are three ways to wake up (activate) the VR app. Use voice command to multimedia unit : Hi Proton. • • Press the voice button on the steering wheel to wake up the VR app.
  • Page 65 Multimedia System (Type I) Multimedia System (Type I) Voice Control Command List of common voice command below can be used after wake up command. Voice Example of Voice Command Function Control “Open map.” Voice control for navigation “Navigate to ‘KLCC’.” can also be used to check “Stop navigation.”...
  • Page 66 Multimedia System (Type I) Multimedia System (Type I) List of common voice command below can be used after wake up command. Voice Example of Voice Command Function Control “Make a call.” “Dial ‘Rick’.” “Call ‘112’.” Voice control for phone can “Call ‘police’.”...
  • Page 67 Setting → System → VR Settings, to customize voice recognition settings such as changing the VR Voice (selection between Atlas for man’s voice or Aethra for woman’s voice), enable/disable the auto wake up function (Hi Proton), setting user’s name and accessing the VR manual.
  • Page 68 Multimedia System (Type I) Multimedia System (Type I) VR Manual The VR manual provides user with more information about voice supported functions, features and characteristics. VR Control At multimedia unit, select and tap in sequence: Setting → System → VR Settings → VR Manual, to access the VR Control that introduces the VR functions and voice commands examples that can be used to communicate with multimedia unit.
  • Page 69 Multimedia System (Type I) Multimedia System (Type I) Air Conditioner (A/C) The air conditioner setting can be customized based on user preferrences via A/C Control Panel in multimedia unit display screen, A/C quick bar in homepage and through voice command (refer to VR manual section for the example of voice command that can be used for A/C system).
  • Page 70 Multimedia System (Type I) Multimedia System (Type I) Description of A/C Quick Bar Buttons A/C Control Button Description Front windshield defrosting/ Activate to quickly remove fog or frost on the defogging button front windshield Rear windshield defrosting/ Activate to quickly remove fog or frost on the defogging button rear windshield Switch between external circulation (fresh air)
  • Page 71 Multimedia System (Type I) Multimedia System (Type I) A/C Control System Buttons Description Tap here to open the seat ventilation speed selection interface and select Front passenger seat ventilation button the desired ventilation speed level between 1, 2 or 3 for left front seat. Shows temperature for left zone Front passenger side temperature (front passenger area).
  • Page 72 Multimedia System (Type I) Multimedia System (Type I) Tap the air vent mode button at the A/C quick bar to adjust the air blowing mode between face blowing mode, foot blowing mode, windshield blowing mode and the mix of it. Tap the temperature button (driver or front passenger) at navigation bar (bottom of the screen) to open the A/C temperature scroll bar pop-uo and adjust the temperature.

  • Page 73: Vehicle Information

    Multimedia System (Type I) Multimedia System (Type I) Setting Tap to open Setting app at homepage or from app list interface to enable/disable, set, and change settings within four categories : Vehicle setting, Cockpit setting, ADAS setting and System setting. Vehicle Information Tap Setting →...
  • Page 74 Tap Setting → Cockpit → Sound. You can set the sound effect of the complete vehicle: [Equalizer]: Control the adjustment of vehicle audio. Selection between PROTON, ROCK, JAZZ, CLASSICAL, POPULAR, VOCALS, CUSTOM. [Balance and Fader]: Adjust the sound effect position of the vehicle.
  • Page 75 Multimedia System (Type I) Multimedia System (Type I) [Volume Adjustment] : Adjust the Media Volume, Bluetooth Volume, Navigation Volume, System Volume, Voice Volume. [Safety Tone]: Low / Medium / High. [Mixing Mode] : Direct Mix / Auto Mix. [Touch screen sound] : On/off touch screen sound.
  • Page 76 Multimedia System (Type I) Multimedia System (Type I) Display Setting Open [Setting] → [Cockpit] → [Display] in turn. Screen brightness display effect, meter/switch brightness adjustment, day/night mode selection. Central Control Screen Brightness Adjustment: the brightness of the central control display screen can be adjusted. [Instrument/on-off brightness adjustment] : When the lamplet is turned on, the instrument/ switch brightness can be adjusted.

  • Page 77: System Setting

    Multimedia System (Type I) Multimedia System (Type I) System Setting Tap Setting → System in sequence. System Information: Software Updates, Voice Recognition (VR) Setting, Wi-Fi, Bluetooth Device, Personal Hotspot, Notification, System Message.
  • Page 78 Open Setting → System → Software Update in sequence. The local software can be accessed through the Settings. Voice Recognition (VR) Setting Open Setting → System → VR Setting in sequence. VR Voice (ATLAS, Aethra), “Hi Proton”, user name, VR manual.
  • Page 79 Multimedia System (Type I) Multimedia System (Type I) Wireless Network (Wi-Fi) Open Setting → System → Wi-Fi in sequence. Control the ON and OFF of the wireless network. After turning on the wireless network, select the corresponding WiFi for connection. Bluetooth Device Open Setting →...
  • Page 80 Multimedia System (Type I) Multimedia System (Type I) Personal Hotspot Open Setting → System → Personal Hotspot in sequence. The hotspot name, hotspot password, and connected device are displayed in Settings. Notification Open Setting → System → Notification in turn. The settings include flag reminders and sound notifications.
  • Page 81 Multimedia System (Type I) Multimedia System (Type I) System Message Open Setting → System → System Message in sequence. System Message consists of Storage, About IHU, Restore Factory Settings. Storage contains storage usage information which is categorised by Application, System, Multimedia and Others;...
  • Page 82 Multimedia System (Type II) Multimedia System (Type II) System Overview System Introduction The vehicle-mounted multimedia infotainment system is mainly composed of vehicle- mounted basic terminal assembly, front central control display screen assembly, GPS antenna, speakers (woofer, tweeter, full frequency), microphone, switch buttons related to the system on the steering wheel, and various interfaces.
  • Page 83 Multimedia System (Type II) Multimedia System (Type II) The APP list interface provides various APPs such as multimedia, phone, user center, Autonavi map, intelligent life, voice magic book, schedule, theme, etc., to respond to most of the scenarios in the process of using your vehicle. At the same time, the system is becoming more and more perfect, and more easy-to-use apps are gradually introduced.

  • Page 84: Lock Screen

    Multimedia System (Type II) Multimedia System (Type II) You can add and delete data. Boot When the system is turned off, the user can directly start it by starting the vehicle. In non-remote mode, ACC ON can only turns on automatically if the vehice is not locked. Lock screen After the screen is locked, click anywhere on the desktop to unlock the screen again.

  • Page 85: Starting The Navigation

    Multimedia System (Type II) Multimedia System (Type II) Navigation Starting the Navigation You can start the navigation by clicking on the desktop app [Map] or the navigation widget on the home page, or you can evoke the navigation by voice. Navigation Interface Search destination: Click to search for the destination you want to go to.
  • Page 86 Multimedia System (Type II) Multimedia System (Type II) Searching Destination Manual Search Click the search destination button in the main interface, enter keywords in the search box, select the destination from the search results, and then start navigation. Map Spot Drag the map, click the selected destination directly on the map, click [Go Here] to open the navigation.

  • Page 87: Updating The Map

    Multimedia System (Type II) Multimedia System (Type II) Activating Navigation via Voice Command After voice wake-up, the common voice navigation instructions are as follows: I’m going to Town Hall. Updating the Map Open my - [Offline data] - [Offline map] in turn. You can download the offline map data of your city, and once you have the offline map data, you can navigate without the Internet.
  • Page 88 Multimedia System (Type II) Multimedia System (Type II) Map Feedback If any POI is not found or not accurate when searching in navigation app, user can provide feedback by selecting New place or Wrong place on the interface.
  • Page 89 Multimedia System (Type II) Multimedia System (Type II) Feedback New Adding new POI If user is at the designated location, please select ‘I am here (Feedback directly).. If user is not at the designated location and want to add a new POI, disable ‘I am here (Feedback directly), pin point the place on the map and fill in the details to register the new POI.
  • Page 90 Multimedia System (Type II) Multimedia System (Type II) Feedback Wrong For POI which is not accurate and not found User can select ‘non-existent’ or ‘wrong info’. Then, fill in the details to feedback...
  • Page 91 Click on the desktop voice image. • Click on the voice assistant APP on the desktop. • Wake-up words wake up: “Hi, Proton”. Voice Navigation After voice wake-up, the common voice navigation instructions are as follows: • I’m going to Town Hall.
  • Page 92 Multimedia System (Type II) Multimedia System (Type II) Voice Call via Voice Command After voice wake-up, the common voice calls instructions are as follows: • Call Gear. Song Request via Voice Command After voice wake-up, the common instructions for song request by voice are as follows: •...
  • Page 93 Multimedia System (Type II) Multimedia System (Type II) Voice Query for Weather and Time After voice wake-up, the common instructions for voice query are as follows: • How’s the weather? • What time is it? Note: The temperature displayed in weather app/widget is based on data received from an online database and may not same as the temperature displayed in meter instrument.
  • Page 94 Multimedia System (Type II) Multimedia System (Type II) • Set the air conditioner to 25 degrees Celsius. • Turn up the temperature a little. Vehicle Body Control by Voice After voice wake-up, the common instructions for vehicle body control by voice are as follows: •...
  • Page 95 Multimedia System (Type II) Multimedia System (Type II) Voice Control Settings, Applications After voice wake-up, the common instructions for volume control and application are as follows: • Open [Settings]. • Turn on the Bluetooth.
  • Page 96 Multimedia System (Type II) Multimedia System (Type II) Multimedia Music Accompanying Music accompanying has a large number of music resources and radio resources, so that you can experience the charm of music while driving. Searching Song Search for music through JOOX, and search for the music you want to listen to in JOOX.

  • Page 97: Playback Control

    Multimedia System (Type II) Multimedia System (Type II) Playback Control Switching Songs in the Playlist You can perform operations such as previous song, next song, pause, and song switching on the music in the playlist. USB and Bluetooth Music After USB flash drive is inserted, its music file can be read and played. The supportable USB flash drive’s file system format is FAT16/FAT32, and the rest cannot be recognized.
  • Page 98 Multimedia System (Type II) Multimedia System (Type II) Bluetooth connection: You can play music in your mobile phone via Bluetooth connection. App Store App Store Introduction The application market of user center includes system native application and third-party application. Users can download their favorite applications through the application market (the specific applications are determined according to the actual push apps).
  • Page 99 Multimedia System (Type II) Multimedia System (Type II) Telephone Bluetooth Connection Open [Setting] - [System] - [Bluetooth Device] in turn. Enable the Bluetooth Device function, and turn on the Bluetooth on your mobile phone at the same time. Select your mobile Bluetooth for pairing. Your mobile phone will receive a paired message.
  • Page 100 Multimedia System (Type II) Multimedia System (Type II) Select a Contact to Dial Click on the contact to dial the number. Voice Dialing After voice wake-up, the common voice calls instructions are as follows: • I need to make a phone call. Answer and Hang up Answer and hang up through the Answer and Hang Up buttons on the steering wheel;...
  • Page 101 Multimedia System (Type II) Multimedia System (Type II) Theme Theme Switching Open [Theme] → [Theme] in turn. Currently, only the default theme is pushed. Wallpaper Open [Theme] → [Wallpaper] in turn. Select your favorite wallpaper, download and apply the wallpaper to switch the home page background.

  • Page 102: Screen Saver

    Multimedia System (Type II) Multimedia System (Type II) Screen Saver Open [Theme] → [Screensaver] in turn. Select your favorite screen saver clock, download it and apply the Screen Saver Clock to switch the pattern when locking the screen. Member Center Registration Registered users shall log in using mobile phone number registered to the vehicle.
  • Page 103 Multimedia System (Type II) Multimedia System (Type II) Setting Vehicle Information Open [Setting] → [Vehicle] → [Vehicle Information] in turn. The basic information of the vehicle can be set; the “Car Nickname” and License Plate No. can be edited except for the VIN. Cockpit Open [Setting] →...

  • Page 104: System Setting

    You can set the sound effect of the complete vehicle: Open [Setting] → [Cockpit] → [Sound] in turn. You can set the sound effect of the complete vehicle: [Equalizer] : Control the adjustment of vehicle audio. -PROTON, ROCK, JAZZ, CLASSICAL, POPULAR, VOCALS, CUSTOM.
  • Page 105 Multimedia System (Type II) Multimedia System (Type II) [Balance and Fader]: Adjust the sound effect position of the vehicle. [Volume Adjustment] : Adjust the Media Volume, Bluetooth Volume, Navigation Volume, System Volume, Voice Volume. [Safety Tone]: Low / Medium / High. [Mixing Mode] : Direct Mix / Auto Mix.
  • Page 106 Multimedia System (Type II) Multimedia System (Type II) [Touch screen sound] : On/off touch screen sound. The volume control can also be adjusted in the drop-down menu bar.
  • Page 107 Multimedia System (Type II) Multimedia System (Type II) Display Setting Open [Setting] → [Cockpit] → [Display] in turn. Screen brightness display effect, meter/switch brightness adjustment, day/night mode selection. Central Control Screen Brightness Adjustment: the brightness of the central control display screen can be adjusted. [Instrument/on-off brightness adjustment] : When the lamplet is turned on, the instrument/ switch brightness can be adjusted.
  • Page 108 Multimedia System (Type II) Multimedia System (Type II) System Setting Open [Setting] → [System] in sequence. System Information: Software Updates, Voice Recognition (VR) Setting, Wi-Fi, Bluetooth Device, Personal Hotspot, Notification, System Message.
  • Page 109 Open [Setting] → [System] → [Software Update] in sequence. The local software can be accessed through the Settings. Voice Recognition (VR) Setting Open [Setting] → [System] → [VR Setting] in sequence. VR Voice (ATLAS, Aethra), “Hi Proton”, user name, VR manual.
  • Page 110 Multimedia System (Type II) Multimedia System (Type II) Wireless Network (Wi-Fi) Open [Setting] → [System] → [Wi-Fi] in sequence. Control the ON and OFF of the wireless network. After turning on the wireless network, select the corresponding WiFi for connection. Bluetooth Device Open [Setting] →...
  • Page 111 Multimedia System (Type II) Multimedia System (Type II) Personal Hotspot Open [Setting] → [System] → [Personal Hotspot] in sequence. The hotspot name, hotspot password, and connected device are displayed in Settings. Notification Open [Setting] → [System] → [Notification] in turn. The settings include flag reminders and sound notifications.
  • Page 112 Multimedia System (Type II) Multimedia System (Type II) System Message Open [Setting] → [System] → [System Message] in sequence. System Message consists of Storage, About IHU, Restore Factory Settings. Storage contains storage usage information which is categorised by Application, System, Multimedia and Others;...

  • Page 113: Basic Operations

    Multimedia System (Type III) Multimedia System (Type III) Basic Operations Introduction of HiBoard Turning on the System for the First Time Press the start switch to set the power mode to ACC or ON, and the system will start automatically. Once the system is started, the display screen displays the power on and warning screen.
  • Page 114 Multimedia System (Type III) Multimedia System (Type III) Using the Touch Screen Bluetooth Single press: to open applications, set Prior-use Instructions progress bars, perform button functions, What Is Wireless Bluetooth etc. Technology Press and hold: HiBoard to add or delete. •...
  • Page 115 Multimedia System (Type III) Multimedia System (Type III) Pairing Your Mobile Phone operation of Bluetooth devices while for the First Time driving is prohibited. • Watching the screen for a long time is dangerous and may lead to accidents. When driving a vehicle, do not look at the screen for a long time.
  • Page 116 Multimedia System (Type III) Multimedia System (Type III) Multimedia Operation device will appear in the [paired device]. Radio When the connection fails, the information Click the [Radio] icon in the multimedia of Bluetooth connection failure will be interface to enter the radio interface. displayed on the screen.
  • Page 117 Multimedia System (Type III) Multimedia System (Type III) Music and lower right corners: Proton, pop, rock, jazz, classical, Hip Hop, Heavy Click [Music] to play songs and Bluetooth Metal, Custom and Loud. The playing music in the USB drive (Bluetooth mode can be selected by operating connection is required).
  • Page 118 Multimedia System (Type III) Multimedia System (Type III) Progress Bar: Drag the progress bar Click the right lower button to rotate to fast forward/fast rewind. 90°to the right: rotate the picture 90° to the right. Left/Right Video: Click the left/right button to play the previous or next Previous/Next: This can be done video.

  • Page 119: Telephone Function

    Multimedia System (Type III) Multimedia System (Type III) Telephone Function Contacts Telephone Function Click “Bluetooth Device” “Connection” in “Settings” to turn on Bluetooth function. Click the [Phone] component on the main interface, then click [Contacts] icon, and the contact interface will appear. The number is very easy to view and find, similar to the use of mobile phones, you “Bluetooth...

  • Page 120: Settings Vehicle Settings

    Multimedia System (Type III) Multimedia System (Type III) Settings Vehicle Settings List dialing You can select the contact to make a call. Calling Touch screen sound setting: touch screen sound can be turned on or off. Date: The date can be displayed. Directly enter the phone number Click the [Phone] component on Version (switch to display versions)

  • Page 121: Connection Setting

    Multimedia System (Type III) Multimedia System (Type III) Connection Setting Display Setting Bluetooth Devices: after clicking to Screen brightness adjustment: you enter, you can operate the switch of can adjust the screen brightness. the Bluetooth device, connect to the Vehicle backlight adjustment: the Bluetooth device and display the host brightness of vehicle backlight can be name, and clear the pairing function.

  • Page 122: Creating New Account

    PROTON Link Mobile App Download Please download “PROTON Link” app in application market. For iOS mobile phone, please search for “PROTON Link” in the Apple App Store. For Android mobile phone, please search for “PROTON Link” in the Google Play Store. For HuaWei mobile phone, please search for “PROTON Link”...
  • Page 123 PROTON Link App Centre PROTON Link App Centre Dashboard home page shows weather information, vehicle status, dashboard Slide up the home page to view dashboard and internet data usage information. information, total range, total mileage, average fuel consumption, average Notification speed, oil pressure and electric parking brake (EPB) status.

  • Page 124: Remote Control

    For some models that is equipped with the power assisted tailgate function, the unlock tailgate function via PROTON link remote control may not be applicable due to safety purpose. You are required to activate the PIN code settings. this 4 Digit PIN code will be used to operate remote control feature.

  • Page 125: Poi Search

    PROTON Link App Centre PROTON Link App Centre Press this icon to show your current Select a location by pressing your finger vehicle location. Your vehicle location on the map to set your destination. A will be shownon the map.
  • Page 126 PROTON Link App Centre PROTON Link App Centre Geo-fence About “My Account” Press icon at your map interface of Press icon to enter your exclusive your phone to set the fence range. When page. the vehicle exits or enters the set range,...

  • Page 127: Call Service

    PROTON Link App Centre PROTON Link App Centre My Service Centre Press “Time selection” to query the time range of the trip log. Press “Preferred service centre” to enter the setting page. The preferred service centre by default is the service centre where you purchased the vehicle, which can be customized and modified later.
  • Page 128 Internet Data Add On In case you need to top up your internet data, there are two methods to get the internet data add on. Data Add On via Proton Link • Via Proton Link app (at homepage) Press the “Trip log function” switch to enable or disable the trip log function.
  • Page 129 PROTON Link App Centre PROTON Link App Centre Data Add On via It is i mportant that the correct email MyProton Application address is being used during sign To purchase data add on via MyProton app, make sure you have MyProton app MyProton app account.
