General Assembly Guidelines Ensure that all parts and hardware are available before beginning assembly. Follow each step carefully to ensure the proper assembly of this product. III. Two people are recommended for ease in the assembly of this product. The three main types of hardware used to assemble this product are wood dowels, screws and bolts.
Parts List The side drawer with WARNING LABEL, should be mou ted in highest drawer. Description Description Part # Part # Top panel 0 pc 0 pcs Bottom side rail Left side panel 0 pc 0 pcs Bottom front rail Right side panel 0 pc 0 pcs...
Page 5
Step 1 Attention to the dowel size: Ø10*20mm Insert ood dowel ( ) into part Ø10*20mm Step 2 Insert wood dowel (A) into part s 1, 2 3, 12, 13, 14, 15 and 16. Ø8*30mm...
Page 6
Step 3 Secure parts 17 to part 2, 3 and 15 with screw (F) and screwdriver. Ø4,0*25mm...
Page 7
Step 4 1 - Ensure cam bolt is installed straight and not at an angle. 2 - Tighten cam bolt until shoulder on cam bolt is flush. Do not over-tigh- ten. Screw cam bolts (K) into parts 1, 2, 3, 8 and 15 with a screwdriver.
Page 8
Step 5 Secure part 16 to part 1 with screw (G) and screwdriver. Ø4,0*30mm Step 6 Align the opening in cam lock to the cam bolt and press into opening. Using a screwdriver, rotate the cam lock until it engages with the cam bolt and locks in place (anywhere between 90-180 degrees).
Page 9
Step 7 Secure part 14 to part 15. Insert cam locks (L) into part 14, and tighten with a screwdriver. Ø15*11mm Step 8 Secure part 1, 14 and 16 to part 2. Insert cam locks (L) into part 1, 14, 16, and tighten with a screwdriver.
Page 10
Step 9 Secure part 1, 14 and 16 to part 3. Insert cam locks (L) into part 1, 14, 16, and tighten with a screwdriver. Ø15*11mm Step 10 Ø7,0*50mm P.10...
Page 11
Step 11 Secure part 4 to part 2, 3 and 15 with screw (H) and screwdriver. Ø4,0*40mm Step 12 Secure part 12 to parts 13, with screw (I) and screwdriver. Ø4,5*50mm P.11...
Page 12
Step 13 Secure part 11 to parts 13, with screw (I) and screwdriver. Ø4,5*50mm Step 14 Secure part 11 to parts 13, with screw (I) and screwdriver. Ø4,5*50mm P.12...
Page 13
Step 15 Secure parts 11 and 12 to part 4 with screw (G) and Ø4,0*30mm screwdriver. Step 16 Ø3,5*20mm P.13...
Page 14
Step 17 Name and address of the supplier and date of production. Ø8,0*8mm Step 18 Secure part 5 and 6 to part 8. Secure part 5 and 7 to part 8. Insert cam locks (L) into parts 5, 6, 7, and tighten with a screwdriver.
Page 15
Step 19 Insert part 9 and 10 between parts 5, 6 and 7. Secure part 10 with screw (G) and screwdriver. Ø4,0*30mm Step 20 Ø3,0*12mm Secure handle (J) with screw (D) and screwdriver, in the pre-drilled holes on the drawer front. P.15...
Page 16
Step 21 Insert ood dowel ( ) into part to be the stop of the drawer. Ø8*30mm Step 22 The assembled drawer with this warning must be placed on top of the unit. Insert wood dowel (B) on the inside of all drawers, with the drawer inside the unit, after having passed the wood dowel that is in the drawer slide.
Page 17
Step 23 WARNING Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend that it is permanently fixed to the wall. Wall anchor and hardware are included with this product. Please make sure hardware is suitable for your walls before installing, as different wall materials may require different types of anchors.
