- Page 1 4K Ultra High Definition Professional Monitor 4KDHDN Series All contents of this document may change without prior notice, and actual product appearance may differ from that depicted herein...
-
Page 2: Warranty
Warranty Orion Images Corporation (“OIC”) warrants to the first purchaser that its LCD Display monitors are free from defects in materials and workmanship under normal use. The warranty is three years beginning on the date of invoice, as further described in the following text. -
Page 3: Table Of Contents
[ USER MANUAL ] <TABLE OF CONTENTS> SAFETY INSTRUCTION FCC RF INTERFERENCE STATEMENT INSTALLATION OSD MENU SPECIFICATION TROUBLESHOOTING... -
Page 4: Safety Instruction
[ USER MANUAL ] 1. SAFETY INSTRUCTION • Follow this safety instruction to use the monitor properly and prevent the damage. * This safety instruction has “Warning” & “Caution” as below Warning - If the user does not follow this instruction, it may cause the serious damage to the user. - Page 5 [ USER MANUAL ] Warning For cleaning do not use liquid cleaners. Do not install this monitor on the outside Never touch the power plug with wet- and near water. It may cause damage to hands. the product, electric shock and fire. When lightning and thundering, unplug Unplug this product from the wall outlet, the monitor from the wall outlet and...
- Page 6 [ USER MANUAL ] Cautions Place this product on a stable place. Install this monitor some distance If not, it may fall, causing serious from the wall and do not install unless damages to the monitor and people. proper ventilation is provided. The openings must not be blocked by When carrying this monitor, be careful curtain, rug or other similar surface.
- Page 7 [ USER MANUAL ] Cautions Install this monitor about 50cm far from Do not press the LCD panel with hands or the eyes and an angle of 0~15 degrees the sharpened material hardly. below eyes. Too close installation may cause having weak sight. For cleaning, unplug the monitor from the Do not use the chemical liquid for cleaning.
-
Page 8: Fcc Rf Interference Statement
[ USER MANUAL ] 2. FCC RF INTERFERENCE STATEMENT NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 9: Installation
[ USER MANUAL ] 3. INSTALLATION 3.1 UNPACKING Remove the package cover and place the product on a flat and secure surface or in the installation location. This equipment should be unpacked and handled with care. If an item appears to have been damaged in shipment, notify the shipper immediately. - Page 10 [ USER MANUAL ] 3.3 HOW TO INSTALL 1) KEY BUTTON ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ OSD KEY FUNCTION On/Off the OSD menu or exit the source selection menu Move the cursor the choose on the OSD menu Select the source on the INPUT menu Move up the cursor to choose on the OSD menu Return to normal mode from power saving mode...
- Page 11 [ USER MANUAL ] 2) CONNECTION a. 27” ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① VGA IN ② DVI IN ③ HDMI1 IN ④ HDMI2 IN ⑤ HDMI3 IN ⑥ DP IN : DP signal Input ⑦...
- Page 12 [ USER MANUAL ] 2) CONNECTION b. 32” ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① VGA IN ② DVI IN ③ HDMI1 IN ④ HDMI2 IN ⑤ HDMI3 IN ⑥ DP IN : DP signal Input ⑦...
- Page 13 [ USER MANUAL ] 2) CONNECTION . 43, 55, 65” ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① VGA IN ② DVI IN ③ HDMI1 IN ④ HDMI2 IN ⑤ HDMI3 IN ⑥ DP IN : DP signal Input ⑦...
-
Page 14: Remote Controller
[ USER MANUAL ] 3.4 REMOTE CONTROLLER POWER Power On or Off MUTE Turn on or off the speaker VIDEO1/CVBS1 Not functional VIDEO2/CVBS2 Not functional S-VIDEO Not functional Select VGA signal AUTO Auto adjustment of VGA source COLOR TEMP Select color temperature of screen Select DVI signal Select HDMI signal HDMI... -
Page 15: Osd Menu
[ USER MANUAL ] 4. OSD MENU 4.1 Main OSD Menu Press a menu button “MENU/EXIT” on a KEYPAD or a remote controller to display this menu on the screen. LT-Win ① Information of Windows HDMI1 3840x2160p60Hz LB-Win HDMI2 1920x1080p60Hz ②... - Page 16 [ USER MANUAL ] 4.3 Image HDMI1 3840x2160p60Hz IMAGE Brightness Contrast Gamma Dynamic Range Main Sharpness Sub Sharpness 3D De-interlace Ver : R4N.M.O.3.L.0.3 Default Available ITEM FUNCTION Value Mode Brightness Adjust a bright value between 0 ~ 100 Contrast Adjust a contrast value between 0 ~ 100 Gamma Select a 2.2 gamma Off or ON Select a dynamic range mode Off, DCR (Dynamic Contrast...
- Page 17 [ USER MANUAL ] 4.4 Color HDMI1 3840x2160p60Hz COLOR Color Temperature Green Blue Ver : R4N.M.O.3.L.0.3 Default Available ITEM FUNCTION Value Mode Color Select the color Temperature Normal Temperature Warm/Normal/Cool/User Adjust red gain value between 0 ~ 255 Green Adjust green gain value between 0 ~ 255 User Blue Adjust blue gain value between 0 ~ 255...
-
Page 18: Multi Window
[ USER MANUAL ] 4.5 Multi-Window HDMI1 3840x2160p60Hz MULTI-WINDOW PIP Type Select Input2 Select Input3 Select Input4 PIP1 Size PIP1 Pox PBP1 Size Ver : R4N.M.O.3.L.0.3 ※ HDMI1 and HDMI3 can not be selected at the same time (Error on selection) Default Available ITEM... - Page 19 [ USER MANUAL ] 4.6 OSD HDMI1 3840x2160p60Hz Horizontal Vertical Transparency OSD Time Out OSD Rotation Ver : R4N.M.O.3.L.0.3 Default Available ITEM FUNCTION Value Mode Adjust a horizontal position of the main menu between Horizontal 0 ~ 100 Vertical Adjust a vertical position of the main menu between 0 ~ 100 Transparency Adjust a transparency of the main menu between 0 ~ 10 OSD Time Out...
- Page 20 [ USER MANUAL ] 4.7 SYSTEM HDMI1 3840x2160p60Hz SYSTEM Language Aspect Ratio Over Scan Over Driver Audio Mute Audio Source Pixel Shift DP Speed FW Update Reset Ver : R4N.M.O.3.L.0.3 Default Available ITEM FUNCTION Value Mode Language Select a language type of OSD Menu. But now, English only English Select an aspect ratio mode of the main window Full...
-
Page 21: Specification
[ USER MANUAL ] 5. SPECIFICATION General Specifications General Features 4K27DHDN 4K32DHDN 4K43DHDN 4K55DHDN 54.64 Screen Size (inch) 31.5 42.51 3840 x 2160 Resolution 3840 x 2160 3840 x 2160 3840 x 2160 0.315*0.315 mm Pixel Pitch (mm) 0.1554 x 0.1554 0.18159 x 0.18159 0.2451 x 0.2451 500 cd/m²... - Page 22 [ USER MANUAL ] 5. SPECIFICATION General Specifications General Features 4K65DHDN 64.53 Screen Size (inch) 3840 x 2160 Resolution 0.372*0.372 mm Pixel Pitch (mm) 500 cd/m² Brightness 1100:1 Contrast Ratio Display 16:9 Aspect Ratio 178/178 degrees Viewing Angle (H/V) 1.07 Billion Display Color 8 ms Response Time...
- Page 23 [ USER MANUAL ] 5.2 Timing Mode Table Vertical MODE Resolution Input Standards Frequency(Hz) EDTV 480p 720x480 59.94 EDTV 576p 720x576 50.00 HDMI/DP HDTV720p 1280x720 50/60 HDTV1080i 1920x1080 50/60 HDMI/DP EIA-861B HDTV1080p 1920x1080 24/25/30/50/60 HDMI/DP UHDTV2160p 3840x2160 24/25/30/50/60 HDMI UHDTV2160p 3840x2160 24/25/30 640x480...
-
Page 24: Troubleshooting
[ USER MANUAL ] 6. TROUBLESHOOTING When the following troubles are occurred, follow the trouble shooting. Before contacting a service center. Troubleshooting Troubleshooting Tip 1. Make sure if the power supply is connected property The screen doesn’t show up 2. Turn on the power. 3. - Page 25 ORION IMAGES Corp.(USA Office) OIC KOREA Co., Ltd.(Headquater/Factory) 7300 Bolsa Avenue, Westminster, CA 92683 5F, OIC Korea B/D, 12, Annam-Ro 369beon-Gil, Tel. (714)766-6300 / Fax. (714)766-6310 Bupyeong-Gu, Incheon, 21312, Korea Email: sales@oriominages.com Tel. +82-32-719-7590 / Fax. +82-32-719-7591 http://www.orionimages.com Email: sales@oickorea.com...
