- Page 1 USER MANUAL LMS-Z400 Series TEL: +1 425-686-3081 | EMAIL: info@laxcoinc.com LMS-DOC-035166...
-
Page 2: Table Of Contents
Troubleshooting Warranty Specifications LAXCO Inc. 22118 20th Avenue SE, Suite 142 TEL: +1 425-686-3081 EMAIL: info@laxcoinc.com Bothell, Washington 98021 © 2017 LAXCO Inc. All rights reserved. Laxco™ is a registered trademark of Laxco Inc., in the U.S. and/or other countries. -
Page 3: Before Use
LMS-Z400 Series LAXCO Inc. Before Use Notice 1. Microscope should be placed in a dry and clean place. Do not expose the microscope in the sun directly. Avoid high temperature and vibration. 2. As microscope is a precision instrument, handle with care, avoiding impact or abrupt movement during transportation. -
Page 4: System Diagram
LMS-Z400 Series LAXCO Inc. 1. System Diagram Trinocular Head Light Path Selection Knob Eyepiece Focus Body Zoom Control Knob Aperture Diaphragm Adjustment Knob Lock Knob Coarse Focus Knob Fine Focus Knob Main Objective Stage Plate Base Clip Reflector Knob... -
Page 5: Assembly
LMS-Z400 Series LAXCO Inc. Assembly Notice 1. The numbered steps below indicate the typical steps required to assemble the LMS-Z400 series stereo microscope systems. -
Page 6: Assembly Steps
LMS-Z400 Series LAXCO Inc. Assembly Focus Bracket Assembly 1. Loosen the lock knob (1) of the focusing bracket group, insert the hole (2) of focusing bracket group into the column (3), until the focusing bracket group to the lowest position. Then tighten the lock knob (1) to prevent the microscope from turning. -
Page 7: Head Assembly
LMS-Z400 Series LAXCO Inc. Head Assembly 1. Loosen the head lock-screw (1) completely with a M4 inner hex spanner. 2. Align the dovetails starting from rear and insert the dovetail on the microscope head into the zoom body. Align the orientation groove (2)of the head with the orientation pin (3) of the body and then tighten the lock Fig.6... - Page 8 LMS-Z400 Series LAXCO Inc. Head Assembly 1. Loosen the head lock-screw (1) completely with a M4 inner hex spanner. 2. Align the dovetails starting from rear and insert the dovetail on the microscope head into the zoom body. Align the orientation groove (2)of the head with the orientation pin (3) of the body and then tighten the lock Fig.6...
- Page 9 LMS-Z400 Series LAXCO Inc. Stage Plate Assembly 1. Using the stage clip can help secure specimens to the stage plate. 2. Insert the clip (1) into the two holes of the base (2) as shown in Fig. 10. Microscope Body Alignment 3.
-
Page 10: Set Illumination
LMS-Z400 Series LAXCO Inc. Operation (LMSP-Z400B2 Stand) Set Illumination 1. Plug the microscope to a power outlet and turn the main power switch to“ON” (1). 2. Adjust the light adjustment knob (2) until the illumination is comfortable for observation. Rotate the light adjustment knob clockwise to raise the brightness. -
Page 11: Adjusting The Focusing Tension
LMS-Z400 Series LAXCO Inc. Operation (LMS-Z400 Head) Adjusting the Focus Knob Tension 1. If the handle is very heavy when coarse focusing, or the specimen leaves the focus plane soon after focusing, or the stage declines itself, these problems can be solved by adjusting the tension adjustment ring①.(See... -
Page 12: Magnification Click-Stop Function
LMS-Z400 Series LAXCO Inc. Magnification Click-Stop Function • Magnification click-stop function provides a click stop position for every zoom magnification indicated on the zoom knob. When the click-stop function is turned to STOP, the zoom magnification can be finely adjusted around the zoom magnification indicated value. -
Page 13: Adjusting The Aperture Diaphragm
LMS-Z400 Series LAXCO Inc. Adjusting the Aperture Diaphragm 1. Adjust the aperture diaphragm by the aperture diaphragm adjustment lever (1). Move it to the left to enlarge the aperture diaphragm and move it to the right to decrease the aperture diaphragm. (See Fig. 21) 2. -
Page 14: Troubleshooting
The warranty does not apply to any instrument which has become worn, defective, damaged or broken due to abuse, misuse, tampering, or unauthorized repairs. Under this warranty, Laxco will repair or replace, without charge to the purchaser, any part which upon our examination, appears to be defective in materials or workmanship. -
Page 15: Optical Specifications
0.35X/0.5X/0.65X/1X C-mount adapter LAXCO Inc. 22118 20th Avenue SE, Suite 142 TEL: +1 425-686-3081 EMAIL: info@laxcoinc.com Bothell, Washington 98021 © 2017 LAXCO Inc. All rights reserved. Laxco™ is a registered trademark of Laxco Inc., in the U.S. and/or other countries.
