- Page 1 PSSu K S RS232 Operating Manual-1002589-EN-03 - Decentralised system PSSuniversal I/O...
- Page 2 We do assure you that all persons are regarded without discrim- ination and on an equal basis. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for the user's internal purposes. Suggestions and comments for improving this documenta- tion will be gratefully received.
-
Page 3: Table Of Contents
Operation ..........................16 Messages..........................16 Display elements........................16 7.2.1 Display element for operational readiness ................16 7.2.2 Display element for module error ....................17 7.2.3 Display elements for data transmission ..................17 Technical details ........................18 Order reference ........................20 Product............................20 Accessories..........................20 Operating Manual PSSu K S RS232 1002589-EN-03... -
Page 4: Introduction
Introduction Introduction Validity of documentation This documentation is valid for the product PSSu K S RS232. It is valid until new document- ation is published. This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. -
Page 5: Definition Of Symbols
It also highlights areas within the text that are of particular import- ance. INFORMATION This gives advice on applications and provides information on special fea- tures. Operating Manual PSSu K S RS232 1002589-EN-03... -
Page 6: Overview
Receive buffer: 1023 Byte Send buffer: 127 Byte Max. number per system: 6 LEDs for: – Operational readiness – Module error – Data transmission For standard applications in system environment B (automation system PSS 4000) Operating Manual PSSu K S RS232 1002589-EN-03... -
Page 7: Front View
1: Labelling strip with: – 2D code – Order Number – Serial Number – Hardware version number 2: Name of compact module 3: D-Sub connector (male) X1 4: LEDs for status display and module diagnostics Operating Manual PSSu K S RS232 1002589-EN-03... -
Page 8: Safety
The module provides a serial interface. It is designed for communication in non-safety-re- lated applications in system environment B (automation system PSS 4000). The module PSSu K S RS232 can be used as a non-safety-related component in accord- ance with the Lifts Directive 2014/33/EU. It meets the environmental requirements for pas- senger and goods lifts in accordance with EN 81-1/2, EN 81-20, EN 81-22 and EN 81-50, as well as the requirements for escalators and moving walks in accordance with EN 115-1. -
Page 9: Warranty And Liability
In safety-related applications, please comply with the mission time T in the safety-related characteristic data. When decommissioning, please comply with local regulations regarding the disposal of electronic devices (e.g. Electrical and Electronic Equipment Act). Operating Manual PSSu K S RS232 1002589-EN-03... -
Page 10: Function Description
When the PSSu E F PS1(-T) or PSSu E F PS2(-T)(-R) is used to supply the system, the module supply is buffered for 20 ms if the supply voltage is interrupted. The module detects the following errors: Start-up error Configuration error ST communication error Bus termination error Operating Manual PSSu K S RS232 | 10 1002589-EN-03... -
Page 11: Configuration
Receive buffer threshold The number of Bytes in a receive buffer of the module is defined with this value, from which the status bit "Receive buffer full" is set (default value: 512). Operating Manual PSSu K S RS232 | 11 1002589-EN-03... -
Page 12: Installation
Electrostatic discharge can damage components. Ensure against discharge before touching the product, e.g. by touching an earthed, conductive sur- face or by wearing an earthed armband. 5.1.1 Dimensions Schematic representation: 30 mm 49,2 mm 1,18" 1,94" Operating Manual PSSu K S RS232 | 12 1002589-EN-03... -
Page 13: Install Compact Module
– On the mounting rail, carefully slide the compact module to the left, in parallel to the adjoining module, until you hear the lateral mounting hooks on the adjacent module lock into position [4]. Operating Manual PSSu K S RS232 | 13 1002589-EN-03... - Page 14 Installation Schematic representation: Operating Manual PSSu K S RS232 | 14 1002589-EN-03...
-
Page 15: Wiring
D-Sub male connector 1: n.c. 2: Input Rx (receive data) 3: Output Tx (send data) 4: n.c. 5: GND 6: n.c. 7: Output RTS 8: Input CTS 9: n.c. n.c. = not connected Operating Manual PSSu K S RS232 | 15 1002589-EN-03... -
Page 16: Operation
The module has an LED for displaying that the system is ready for operation (LED "Run"). Description Colour Status - - - Module not ready for oper- ation green Module ready for operation Operating Manual PSSu K S RS232 | 16 1002589-EN-03... -
Page 17: Display Element For Module Error
The module has the LEDs Tx and Rx for displaying the data transfer (LEDs "Tx" and "Rx"). Descrip- Colour Status Signal tion - - - No data transfer green Send data - - - No data transfer green Receive data Operating Manual PSSu K S RS232 | 17 1002589-EN-03... -
Page 18: Technical Details
Climatic suitability in accordance with the standard EN 60068-2-30, EN 60068-2-78 Humidity 93 % r. h. at 40 °C Condensation during operation Not permitted Max. operating height above SL 2000 m Operating Manual PSSu K S RS232 | 18 1002589-EN-03... - Page 19 Material Bottom Front Connection type D-Sub male connector Dimensions Height 128,9 mm Width 30 mm Depth 56 mm Weight 81 g Where standards are undated, the 2009-03 latest editions shall apply. Operating Manual PSSu K S RS232 | 19 1002589-EN-03...
-
Page 20: Order Reference
PSSu A LC 0.1 Labelling bracket, scope of delivery: 5 pieces 312966 PSSu A LA0 Labelling strips, laser printable, scope of delivery: 1080 pieces 312958 (10 x DIN A4 sheet, 108 on each) Operating Manual PSSu K S RS232 | 20 1002589-EN-03... - Page 21 We are represented internationally. Please refer to our homepage www.pilz.com for further details or contact our headquarters. Headquarters: Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: info@pilz.com, Internet: www.pilz.com...
