Watts ENWARE FS365 Installation And Maintenance Instructions Manual

Watts ENWARE FS365 Installation And Maintenance Instructions Manual

Food service ultra rinse trigger spray with hose
Hide thumbs

Advertisement

Table of Contents

Food Service Ultra Rinse Trigger Spray
with Hose
Installation and Maintenance Instructions
FS365
technical data
Working Pressure Range
Maximum Working Temperature
Inlet Connection
Flow Rate
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00615_09 Aug 2024
1300 369 273 | info@enware.com.au | enware.com.au
Min 50 kPa
Max 500 kPa
70°C
1/2" BSP
4 L/min (Spray gun - nozzle)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENWARE FS365 and is the answer not in the manual?

Questions and answers

Related Manuals for Watts ENWARE FS365

Summary of Contents for Watts ENWARE FS365

  • Page 1 Food Service Ultra Rinse Trigger Spray with Hose Installation and Maintenance Instructions FS365 technical data Working Pressure Range Min 50 kPa Max 500 kPa Maximum Working Temperature 70°C Inlet Connection 1/2” BSP Flow Rate 4 L/min (Spray gun - nozzle) Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.

  • Page 2: Before Installation

    installation BEFORE INSTALLATION • All supply lines must be flushed thoroughly to remove Nozzle debris prior to the installation of this product, as per AS/ NZS 3500.1. Strainers (40 mesh) are recommended if debris is an ongoing problem. • A pressure reduction valve may be required to comply Apply Thread Sealant with the recommended maximum supply pressure 14mm...

  • Page 3: Bracket Installation

    Apply Thread Sealant IMAGE 05 BRACKET INSTALLATION Position Trigger Gun at desired height on wall, position bracket and mark drill holes on wall. SEE IMAGE 06 Drill 3 holes for the Bracket and fix Bracket on wall using appropriate fixing screws (screws not supplied). WALL BRACKET INSTALLATION DETAIL IMAGE 06...
  • Page 4 operating instructions TRIGGER SPRAY OPERATION Squeeze spray trigger to turn on. Squeeze Trigger to To make the water flow to stay on, slide the Turn ON Use Holding holding ring over the trigger. Ring to Keep ON Release To turn off, let go of the trigger, or slide the Trigger to holding ring off the spray lever handle.

  • Page 5: Maintenance

    maintenance CLEANING Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive. Use of unsuitable cleaning agents may damage the surface.

  • Page 6: Troubleshooting

    troubleshooting Refer to the following troubleshooting guide for specific problems and solutions. PROBLEM CAUSE RECITIFICATION No water flow from trigger Water supply turned off or Connect and turn on water supply spray outlet or pot filler spout disconnected Check valves are blocked by Remove check valves and clean debris Replace check valves (Located inside...

  • Page 7: Spare Parts

    spare parts Description Enware Part Code Ultra-Rinse Pre-Rise Trigger Spray (Standard) FS729 Ultra-Spray Soft Rinse outlet (Non-adjustable spray outlet FS729SS-KIT attachment kit) - Optional Trigger spray spring loaded SBA (cartridge) FS721S Trigger Spray Service Kit FS077NS Trigger Spray Handle & Screw FS790 Trigger Spray guard and nozzle FS795...

  • Page 8: Product Warranty Statement

    - WATTS AUSTRALIA EFFECTIVE FROM 20 November 2023 This Warranty Statement applies to products supplied by Australian Valve 3. Our responsibilities Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662 (a) In the event that the Supplier is reasonably satisfied that there is a...
