ETI NETCOM ADH Replacement Procedure page 5

4.
Disconnect the canister power cables
by loosening the captive screw at
each end
connector. See Figure 2.
Carefully note the connections of the
5.
existing
installation
orientation. Because they will be re-
used, carefully disconnect the air
hoses on the inlet side (in front) of the
canisters from the barbed fittings on
the solenoids.
attached to
disconnect only at the solenoid ends.
Twist the hoses first to loosen them,
then carefully pull the hoses off the
solenoid fittings. Retain these hoses
for re-use in this procedure.
Disconnect the air hoses on the outlet
6.
side of (behind) the canisters from the
barbed fittings on the solenoid valves.
Leave the hoses attached to the
canister fittings; disconnect only at the
solenoid ends. Twist the hoses first to
loosen them, then pull the hoses off
the solenoid fittings by slicing the
white tubing off the solenoid fitting.
Cut the black tie wraps securing the
7.
canisters to their mounting brackets.
South Bend, Indiana USA | networketi.com
of the green
air hoses. The
will duplicate
Leave the hoses
the canister fittings;
power
new
this
Disconnect the canister power cables
by loosening the captive screw at each
end of the green power connector.
Figure 2. THE CANISTER POWER
8.
Once the green power cable
connectors
disconnected and the tie wraps
cut, lift the existing canisters out of
the chassis. Carefully remove the
existing inlet hoses from the
canisters and retain them for re-
use.
are already wired with a new
power cable connector, so the
existing
including
connectors, may be discarded.
Retain the existing inlet hoses. As
a precaution, retain the original
outlet hoses until the new outlet
hoses have been made.
5
CABLE CONNECTOR.
have
The replacement canisters
canister assemblies,
the wiring
ADH INSTRUCTION MANUAL | PART NO.
been
and
24056 REV B
