TOOLS REQUIRED FOR INSTALLATION
Electric Drill
1/8" wood or metal drill bit
5/16" masonry drill bit
Tape measure
Screwdriver
Level
ALL PICTURES SHOWN ARE FOR ILLUSTRATION PURPOSE ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENT.
ErgoAngleBar
with Optional Toilet Paper Holder
INSTALLATION INSTRUCTIONS
4017-SSB, 4017-SSP, 4017-MB, 4017-ORB
IMPORTANT
Check local code for proper placement
of ErgoAngleBar to meet requirement
such as ADA or ANSI 117.1 Consumer
Safety Requirements.
ERGOANGLEBAR CAN BE MOUNTED
THROUGH SHOWER WALL AND
SCREWED DIRECTLY TO WOOD OR
METAL STUD WHEN APPLICABLE.
INSTALLATION QUESTIONS
Before returning your ErgoAngleBar to
the store or have any question about
installation or missing parts please
visit the CUSTOMER CARE area on our
website www.PulseShowerSpas.com.
WARRANTY
Please visit
www.PulseShowerSpas.com for
our Manufacture's Lifetime Limited
Warranty information.
Advertisement
Related Manuals for Pulse Shower Spas Seville ErgoAngleBar 4017
Summary of Contents for Pulse Shower Spas Seville ErgoAngleBar 4017
- Page 1 ErgoAngleBar with Optional Toilet Paper Holder INSTALLATION INSTRUCTIONS 4017-SSB, 4017-SSP, 4017-MB, 4017-ORB TOOLS REQUIRED FOR INSTALLATION INSTALLATION QUESTIONS IMPORTANT Before returning your ErgoAngleBar to Check local code for proper placement the store or have any question about of ErgoAngleBar to meet requirement installation or missing parts please such as ADA or ANSI 117.1 Consumer visit the CUSTOMER CARE area on our...
- Page 2 STEP 1 PARTS INCLUDED Position bar on wall at your desired location. Make sure bar is leveled. • Stainless steel rail Trace around mounts with pencil to create your mounting template. • Installation manual Use an allen wrench to remove set screws and remove bar from mounts. •...
