Before driving the loudspeakers
ensure to load the proper loudspeaker factory
preset on Kommander-KA amplifier
Any Domino-KF loudspeaker has an on-board passive filter
that automatically adjusts the frequency response and
phase response of the speaker and can be match with any
professional amplifier. It means that can be driven without the
need of a dedicated preset.
Especially in this case, make sure to adhere to the correct wiring
and the correct impedance configuration
The following installation procedures can
be applied to both the Domino-KF26 I, the
Domino-KF210 and the Domino-KF212 even if the
pictures show theDomino-KF210 only.
Installation
Domino-KF loudspeakers can be installed both as a free-
standing device on any flat surface, or applique on the wall with
dedicated brackets that are included in the package or with
mounting accessories that can be purchased separately.
With the dedicated mounting frame, the Domino-KF26/KF26C/
KF26M, Domino-KF210 and Domino-KF212 can be installed in a
recessed position, either in-wall and in-ceiling.
Free-Standing Installation
The Domino-KF feature four rubber feet screwed on the
bottom side. The rubber feet can be adjusted along the four
M4 threaded holes located on the sides of the loudspeaker,
allowing the user to tilt the speaker for vertical free-standing.
DOMINO-KF
User Guide
Tilt 90° the
adhesive logo
horizontal
vertical
9
