- Page 1 FILLING CHECK VERSION WITH FLOWMETER FILLING CHECK VERSION WITH LEVEL SENSOR 4670615 Software rel. 1.0.0 INSTALLATION, USE AND MAINTENANCE...
-
Page 2: Legend Of Symbols
LEGEND OF SYMBOLS LEGEND OF SYMBOLS • Generic danger Warning IBX100 remote control unit Virtual Terminal Object Pool WARNING: T H E N AT I V E C O N T R O L S I N S I D E Y O U R V I R T U A L TERMINAL HAVE THE PRIORITY ON ALL THE CONTROLS D ER I V I N G FROM THE I BX 10 0. -
Page 3: Table Of Contents
CONTENTS Risks and protections before assembly ..............................4 Product description ....................................4 Intended use ......................................4 Precautions ........................................ 4 Package content ......................................4 Position on farming machine ................................... 5 System recommended composition: FILLING CHECK WITH FLOWMETER ................... 5 System recommended composition: FILLING CHECK WITH LEVEL SENSOR................6 Positioning ...................................... -
Page 4: Risks And Protections Before Assembly
INTRODUCTION • MANUAL USE MODES The section of this manual dedicated to the installation contains information for installers. For this reason we have used technical terms without providing explanations. THE INSTALLATION MUST BE CARRIED OUT BY AUTHORIZED AND SKILLED PERSONNEL ONLY. ARAG IS NOT RESPONSIBLE FOR ANY INSTALLATION CARRIED OUT BY UNAUTHORIZED OR UNSKILLED PERSONNEL. -
Page 5: Installation
INSTALLATION POSITION ON FARMING MACHINE System recommended composition: FILLING CHECK WITH FLOWMETER WARNING: DO NOT CONNECT ISOBUS CONNECTOR. THIS CONNECTION WILL HAVE TO BE PERFORMED ONLY AT A LATER STAGE, ONCE ALL COMPONENTS HAVE BEEN INSTALLED ( Refer to the manual supplied with IBX100 ISOBUS Sprayer - Chap. Isobus system cable connection To connect all parts of the system correctly, make sure to use the proper connection cables. -
Page 6: System Recommended Composition: Filling Check With Level Sensor
INSTALLATION System recommended composition: FILLING CHECK WITH LEVEL SENSOR WARNING: DO NOT CONNECT ISOBUS CONNECTOR. THIS CONNECTION WILL HAVE TO BE PERFORMED ONLY AT A LATER STAGE, ONCE ALL COMPONENTS HAVE BEEN INSTALLED ( Refer to the manual supplied with IBX100 ISOBUS Sprayer - Chap. Isobus system cable connection To connect all parts of the system correctly, make sure to use the proper connection cables. -
Page 7: Positioning
INSTALLATION Positioning Set mounting rail in cabin and fasten it with the relevant screws in a position where VISIO ISOBUS can be easily seen and at hands' reach, but away from any moving organs. Secure VISIO ISOBUS to rail and push down until locked in place. Fasten harnesses so that they do not interfere with any moving parts. -
Page 8: Setup
SETUP SETUP Tests and checks before programming Before setup, check: • that all components are correctly installed; • the correct connection to the power source; • the component connection. Failure to correctly connect system components or to use specified components might damage the device or its components. 8.2 First switching on Keep key pressed for 1 second. -
Page 9: Controls In The Menu
SETUP Controls in the menu SWITCHING ON Keep key pressed for 1 second. Every time the device is switched on, it will shortly show a page with the name of device and software version. SWITCHING OFF Power off... Press for 2 seconds. ... -
Page 10: Communication Between Visio Isobus And Virtual Terminal
PROGRAMMING - FILLING CHECK WITH FLOWMETER VERSION COMMUNICATION BETWEEN VISIO ISOBUS AND VIRTUAL TERMINAL To enable the communication between VISIO ISOBUS and refer to the manual of the application installed IBX100 Sprayer ISOBUS IBX100 Sprayer ISOBUS STRUCTURE OF THE SETUP MENU - FILLING CHECK WITH FLOWMETER VERSION To access the Setup menu, refer to par. -
Page 11: Setup - Filling Check With Flowmeter Version
ALARMS / OPTIONS - FILLING CHECK WITH FLOWMETER VERSION SETUP - FILLING CHECK WITH FLOWMETER VERSION Set the desired alarm display thresholds. 11.1 > Alarms Min flowrate / Max flowrate Set minimum and maximum flowrate thresholds for alarm message. Open Alarms menu ( Setup menu >... -
Page 12: Options > Units Of Measurement
OPTIONS - FILLING CHECK WITH FLOWMETER VERSION 11.3 Options > Units of measurement Set unit of measurement for the values detected by the device. 11.3.1 Flowrate Open flowrate unit of measurement setup menu Unit of measure Setup menu > Options > Units of measurem. > Flowrate Flowrate l/min The display will show the current setting below the selected item. -
Page 13: Options > Alarm Tones
OPTIONS - FILLING CHECK WITH FLOWMETER VERSION 11.5 > Options Alarm tones Enable/disable the alarm tones. Open Alarm tones menu ( Setup menu > Options > Alarm tones Options Unit of measure The display will show the current setting below the selected item. Display contrast Alarm tones Press... -
Page 14: Options > User Access
OPTIONS - FILLING CHECK WITH FLOWMETER VERSION 11.7 > Options User access Select user access level. Open user level menu ( ). Set the user access Setup menu > Options > User access Options level to the control parameters. Alarm tones Keytones The preset access mode is Technician. -
Page 15: Setup Management
SETUP MANAGEMENT - FILLING CHECK WITH FLOWMETER VERSION 11.10 Setup management - The IBX100 Sprayer ISOBUS settings can be saved or loaded in a USB* pendrive. - The VISIO ISOBUS settings can be loaded or saved in a USB* pendrive so as to reconfigure the device if necessary, solve problems or configure another VISIO ISOBUS without repeating all operations manually. -
Page 16: Setup Management > Save Setup
SETUP MANAGEMENT - FILLING CHECK WITH FLOWMETER VERSION 11.11 > Setup management Save setup Setup management It allows saving VISIO ISOBUS configuration file in a USB pendrive: it will be possible to load IBX file managem. it again any time the same settings need to be retrieved. Save setup Load setup Select the desired control through... -
Page 17: Device Management
DEVICE MANAGEMENT - FILLING CHECK WITH FLOWMETER VERSION 11.13 Device management It allows selecting an update file (.s19) saved in a USB* pendrive and to update the IBX100 ISOBUS devices and ISOBUS arag auxiliary devices present on the CAN network. To be able to use the following functions it is necessary to plug a USB pendrive in the relevant port at the bottom of VISIO ISO- BUS. - Page 18 TEST - FILLING CHECK WITH FLOWMETER VERSION 11.14 Test This menu allows user to view some data and carry out an operating test of VISIO ISOBUS. Open the device test menu ( Setup menu > Test Setup menu Test Press the key on the side to scroll the items. Setup management Firmware version Device management...
-
Page 19: Fill Settings
FILLING SETUP - FILLING CHECK WITH FLOWMETER VERSION 11.15 Fill settings It is possible to set filling valve trip time, i.e. the time between valve closing signal and valve actual closing. To find this value, refer to the technical data sheet of the filling valve of the system. Open valve activation time menu ( Setup menu >... -
Page 20: Use - Filling Check With Flowmeter Version
USE - FILLING CHECK WITH FLOWMETER VERSION The main page shows the display divided into three horizontal parts: - top part: item refers to the key on the side allowing user to start the procedure (key Start Start - central part: the value is the set filling quantity. -
Page 21: Structure Of The Setup Menu - Filling Check With Level Sensor Version
PROGRAMMING - FILLING CHECK WITH LEVEL SENSOR VERSION STRUCTURE OF THE SETUP MENU - FILLING CHECK WITH LEVEL SENSOR VERSION To access the Setup menu, refer to par. “8.5 Controls in the menu" on page 9: Setup menu Menu Default Other values that can be set / Notes Alarms Tank reserve... -
Page 22: Setup - Filling Check With Level Sensor Version
ALARMS - FILLING CHECK WITH LEVEL SENSOR VERSION SETUP - FILLING CHECK WITH LEVEL SENSOR VERSION Set the desired alarm display and audible message thresholds. 14.1 > Alarms Tank reserve Set the value of the minimum fluid quantity left in the tank. Open tank reserve alarm menu ( Alarms Setup menu >... -
Page 23: Fill Settings
FILLING SETUP - FILLING CHECK WITH LEVEL SENSOR VERSION 14.7 Fill settings This menu allows you to define the percentage of advance or delay with which the pump stop must stop the pump in order to reach the preset volume more accurately. -
Page 24: Maintenance - Diagnostics - Repairs
MAINTENANCE - DIAGNOSTICS - REPAIRS MAINTENANCE - DIAGNOSTICS - REPAIRS • Clean only with a soft wet cloth. • Do not use aggressive detergents or products. • Do not clean equipment with direct water jets. 15.1 Troubleshooting Trouble - Displayed message Cause Remedy No power supply... -
Page 25: Guarantee Terms
GUARANTEE TERMS 1. ARAG s.r.l. guarantees this apparatus for a period of 360 days (1 year) from the date of sale to the client user (date of the goods delivery note). The components of the apparatus, that in the unappealable opinion of ARAG are faulty due to an original defect in the material or produc- tion process, will be repaired or replaced free of charge at the nearest Assistance Center operating at the moment the request for interven- tion is made. - Page 26 Only use genuine ARAG accessories or spare parts to make sure manufacturer guaranteed safety conditions are maintained in time. Always refer to the internet address www.aragnet.com. 42048 RUBIERA (Reggio Emilia) - ITALY Via Palladio, 5/A Tel. +39 0522 622011 Fax +39 0522 628944 http://www.aragnet.com info@aragnet.com...
