- Page 1 Quick Installation Guide TEW-654TR 1.01...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English ...................... 1. Before You Start ................. 2. Hardware Installation ................. Configure the TEW-654TR ..............Troubleshooting ..................Version 06.16.2009... -
Page 3: English
1. Before You Start Package Contents TEW-654TR CD-ROM (User’s Guide) Multi-Language Quick Installation Guide Travel case USB to power-pin cable (0.45m/2.5ft.) Cat. 5 Ethernet cable (1.1m/3.6ft.) Power adapter (5V, 1.2A) Installation Requirements A computer with a wireless network adapter properly installed Web Browser: Internet Explorer (6.0 or higher) Broadband Internet Installed Cable or DSL Modem... - Page 4 Application Router Mode Internet 300Mbps Wireless N Travel Router Kit Laptop with Laptop with Wireless N (TEW-654TR) Wireless N USB Adapter USB Adapter (TEW-624UB) (TEW-644UB) AP Mode Laptops with Wireless N USB Adapters Internet (TEW-644UB) Modem 300Mbps Wireless N Router Travel Router Kit (TEW-654TR) AP Client Mode...
-
Page 5: Hardware Installation
2. Hardware Installation Note: 1. Gather all information related to your Internet Connection before you start. If necessary, contact your Internet Service Provider (ISP). 2. The below steps is for router mode configuration. For AP and client mode instructions, please refer to the User's Guide. 1. - Page 6 4. Connect the AC Power Adapter to the wireless router and then to a power outlet. 5. Verify that the following panel lights are on: POWER, LAN and WLAN. 6. Press the WPS button on the TEW-654TR for 5 seconds, then let go.
-
Page 7: Configure The Tew-654Tr
3. Configure the TEW-654TR 1. Open your web browser, type http://192.168.10.1 in the Address bar, and then press Enter. 2. Enter the User Name and Password, and then click Log In. By default: User Name: admin Password: admin 3. Click Wizard. 4. - Page 8 5. Enter a Password, verify the Password and then click Next. By default, the Password is admin. 6. Select your Time Zone and then click Next. 7. Click Next. Note: Do not change default settings unless it is conflicting with your existing hardware.
- Page 9 8. Configure the settings based on information provided by your ISP. Follow the wizard instructions to complete the configuration. Note: Each Internet Connection type may have different options. 9. Enter the desired SSID and then click Next. 10. Click Save. English...
- Page 10 For detailed information regarding the TEW-654TR’s configuration and advanced settings, please refer to the Troubleshooting section, User's Guide CD-ROM, or TRENDnet's website at http://www.trendnet.com. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register...
-
Page 11: Troubleshooting
Troubleshooting I typed http://192.168.10.1 in my Internet Browser's Address Bar, but an error message says “The page cannot be displayed.” How can I get into the TEW- 654TR's web configuration page? First, check your hardware settings again by following the instructions in Section 2. - Page 12 2. Click Internet Protocol (TCP/IP) and then click Properties. Then click on Obtain an IP address automatically. Fourth, press on the factory reset button for 15 seconds. Note: If you are trying to configure the TEW-654TR in AP or AP Client mode, see I am not sure what type of Internet Account Type I have for my Cable/DSL connection.
- Page 13 How do I configure AP or AP Client mode on the TEW-654TR? First, you need to assign a static IP address to your computer's network adapter in the 192.168.10.X subnet. Since the TEW-654TR 's default IP address is 192.168.10.100 in AP and AP Client mode when no DHCP server is connected, do not assign an IP address of 192.168.10.100 to your computer's network adapter.
- Page 14 (AP Client mode) or http://192.168.10.100 into the address bar. Sixth, refer to the User Guide for additional instructions. The User Guide is on the User Guide CD-ROM drive. If you still encounter problems or have any questions regarding the TEW-654TR, please contact TRENDnet's Technical Support Department.
- Page 16 Informations générales GPL/LGPL Ce produit TRENDnet comprend un logiciel libre écrit par des programmeurs tiers. Ces codes sont sujet à la GNU General Public License ("GPL" Licence publique générale GNU) ou à la GNU Lesser General Public License ("LGPL" Licence publique générale limitée GNU).
- Page 17 General Public License) ou ao LGPL (GNU Lesser General Public License). Estes códigos são distribuídos SEM GARANTIA e estão sujeitos aos direitos autorais dos desenvolvedores. TRENDnet não presta suporte técnico a estes códigos. Os detalhes do GNU GPL e do LGPL estão no CD-ROM do produto.
- Page 18 Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register 20675 Manhattan Place Torrance, CA 90501 Copyright ©2009. All Rights Reserved. TRENDnet.
