SOMFY Sonesse 40 PoE Original Instructions Manual

EN
EN
Sonesse2 40 PoE
Short installation guide
O
RIGINAL INSTRUCTIONS
Complete instruction guide available online on www.somfy.info
Connect the PoE drive to the PoE switch with Ethernet
cable Cat 5e mini 24 AWG.
WebGUI (for individual drive settings):
Thanks to a web browser on a computer, tablet or Smartphone
connected to the network, enter the drive's Hostname*
(indicated on the label) in the address field.
And follow instructions.
To integrate the product, a certificate and an API are required. To request this information see:
https://www.somfypro.com/partner-with-us
2
This drive does not require any maintenance operation. No user serviceable parts.
To control the drive, please refer to the installation instructions of the used control point.
3
This reset returns the drive to factory mode.
These instructions apply to all Sonesse2 40 PoE drive, the different versions of which are available in the current catalogue.
FIELD OF APPLICATION
The Sonesse 40 drives are designed to motorise all types of:
– Interior blinds, and interior venetian blinds with bottom bar moves solely by gravity with a mass less than 15 kg.
PoE Switch IEEE 802.3
2 N.m 802.3at Class 4
4 N.m 802.3bt Class 6
6 N.m 802.3bt Class 7
COMMISSIONING
USE
DRIVE RESETTING
12 s
INSTRUCTIONS TO BE RESPECTED
From the Application
"Help me by Somfy"
scan the QR code here to
find complete setting
PoE Config Tool (for discovering multiple drives):
Download the program form:
https://www.somfy.com/projects/downloads
x3
instructions.
"Help me by Somfy"
available on stores
