Renson ZipShade Top User Manual

Warranty certificate
Dear customer,
You have recently become the owner of a quality sunprotection screen from RENSON
Sunprotection-Screens. We congratulate you on your wise choice. After final inspection your
sunprotection screen was given the serial number that you can find in this booklet.
All the materials we use are top quality and suitable for their purpose. As a manufacturer of
sunprotection screens, we guarantee our products for five years* against any defects occurring
during normal use and maintenance.
In the event of problems, always quote the serial number to your installer.
Because RENSON Sunprotection-Screens places great importance on the quality of its products and
on providing maximum satisfaction for our customers and end-users, we have drawn up special
operating and maintenance instructions.
* A 5-year guarantee also applies to motors
Concerning the coating of aluminium elements, a 10-year guarantee applies for the colour stability.
A 5-years guarantee applies on the gloss of the coated profiles.
User manual & warranty conditions
1 • Electrical specifications
Category
Power supply
Current
Output
Protection class
Max. operating time
2 • Wind class
Depending on the quality of the product the ZipShade
Guarantee up to 120 km/h (≈ 74 mph*) for fully unrolled sunprotection screen (standing).
For information the following are the wind classes according to the DIN 13561:2004 standard.
Wind class Wind force (on Beaufort scale)
Class 0
Class 1
Class 2
Class 3
3 • Function
Sunprotection screen for external use, specially designed to exclude the sun and create an optimal internal climate. Depending on the type of fabric
selected, the values for light permeability and heat protection may vary. The specific design of the ZipShade
4 • Guarantee
All materials used by RENSON Sunprotection-Screens are top quality and suitable for their purpose. As a manufacturer, RENSON Sunprotection-
Screens guarantees its products for five years against any defects occurring during normal domestic use and regular maintenance.
There is also a 5-year guarantee on the electrical controls. Concerning the coating of aluminium elements, a 10-year guarantee applies for the colour
stability. A 5-years guarantee applies on the gloss of the coated profiles.
* Converted for your convenience. Rounding errors may occur, certificate is based on tests in km/h
Rating
120 Volt AC - 60 Hz
2,1 Amps
250 Watt
IP 44
Approx 5 minutes
Top is conform wind class 3.
®
Product not tested/not in compliance
4 bft
5 bft
6 bft
7 bft
8 bft
9 bft
10 bft
11 bft
12 bft
Sunprotection-Screens
RENSON ZipShade
Wind speed
20 - 28 km/h
29 - 38 km/h
39 - 49 km/h
50 - 61 km/h
62 - 74 km/h
75 - 88 km/h
89 -102 km/h
103 - 117 km/h
> 117 km/h
To makes it extremely resistant to wind gusts.
®
Top
®
Wind speed (mph*)
≈ 13 - 17 mph
≈ 18 - 24 mph
≈ 25 - 30 mph
≈ 31 - 38 mph
≈ 39 - 46 mph
≈ 47 - 54 mph
≈ 55 - 63 mph
≈ 64 - 73 mph
≈ ≥ 74 mph
1
