Functions compatible with the 2015 Lexus GS 350 (Smart Key)
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Arm Factory Security
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Locks Status
Door Unlock
Driver Priority Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Fuel level/EV battery level
Ignition Activation
Ignition Status
Immobilizer Bypass-Data No Key Req'd
SmartStart
Start (Crank) Activation
Tach / RPM Output
Trunk / Hatch Release
933.TL6
v2.26.198.12
2015 Lexus GS 350 (Smart Key)
THTON6 Compatible
(Sold Separately)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 933.TL6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Voxx Electronics 933.TL6

  • Page 1 933.TL6 v2.26.198.12 2015 Lexus GS 350 (Smart Key) THTON6 Compatible (Sold Separately) Functions compatible with the 2015 Lexus GS 350 (Smart Key) *Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro. * Odometer...
  • Page 2: Table Of Contents

    Contents Introduction Pre-installation and application warnings OEM remote starter information Installation Wiring diagram with T-Harness (THTON6) Wiring diagram Locating components in the vehicle Vehicle connections Module programming IMPORTANT!Before programming your module, you must first check if your vehicle is equipped with an OEM remote starter and disable it.
  • Page 3: Introduction

    To configure via DirectLink mobile app (Android/iOS): 1. Follow and complete the wiring diagram(s) related to your installation through the app. 2. When installation is complete, select Configure DS4/DS4+. 3. Follow the on-screen instructions. 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 4: Pre-Installation And Application Warnings

    [4] Autolights: This connection is only required if vehicle is equipped with autolights. [5] Security-Only: For security-only installations, refer to the "Locating components in the vehicle" section for optional starter disable connection 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 5: Oem Remote Starter Information

    Depending on your vehicle, a telematics interrupt may be required. A status output must be assigned and an external relay must be used. Refer to Directwire on www.directechs.com for vehicle-specific telematics interrupt wire color and location. 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 6: Installation

    (black connector at PTS switch) Legend: disable connection section for relay and connection details. Mandatory Connections Security Only Remote Start Only (-) PTS: Green, Pin 1 Remote Start + Security 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 7: Wiring Diagram

    (black connector at PTS switch) under steering column) Remote Start + Security (-) PTS: Green, pin 1 (-) SLP: Blue, pin 4 (-) Lock: Gray, pin 16 (-) Unlock: Violet, pin 24 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 8: Locating Components In The Vehicle

    When flashing your module for Remote Start & Security, you must Security Only manually assign the designated output to Anti Grind (AG) Starter Kill. Remote Start Only (Applicable to CORE 194+.) Remote Start + Security 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 9: Vehicle Connections

    No Connection No Connection H2/14 Brown No Connection No Connection H2/15 White/Blue No Connection No Connection H2/16 Red/Blue No Connection No Connection H2/17 Black/White No Connection No Connection 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 10 No Connection No Connection H4/7 Violet No Connection No Connection H4/8 Orange No Connection No Connection H4/9 Red/White No Connection No Connection H4/10 Pink No Connection No Connection 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 11: If Equipped With An Oem Starter, But Will Prevent The Aftermarket Remote Start From Functioning Properly

    (+) 12 Volt Temperature sensor harness, 2-pin black connector (H7) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H7/1 Black Temperature Sensor H7/2 Black Temperature Sensor 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 12: Module Programming

    Pair remotes (if applicable). For information on how to pair a specific remote, please refer to its corresponding owner documentation, which can be found inside the product packaging of the complete system or on www.directechs.com.* 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 13 "Initialize Virtual Tach" (not needed with hardwired or data tach applications). * Your aftermarket remote may differ from the model shown in the illustrations. You have successfully completed the module programming sequence. 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 14: Module Programming For Security-Only Installations

    Your aftermarket remote may differ from the model show in the illustration. You have successfully completed the module programming sequence. 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 15: Pairing Remotes

    Directed SmartStart unit: ® SmartStart with Loops – The brown loop must be cut. SmartStart with Pigtails – The gray wire must be connected to a ground source. 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 16: When Used In Conjunction With Smartstart

    The white D2D1 port is reserved ONLY for SmartStart, Module flashing or 3rd Party bypass. The two black D2D2 ports are reserved for the Control Center (antenna) and digital sensors (8504D). 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 17: Manual Transmission

    Must be connected to a working tachometer signal in the vehicle (fuel injector, ignition coil, true tach, etc.) and (Violet/White, pin 22) learned successfully to the DS4+. See Tech Tips 10001 - https://directechs.blob.core.windows.net/techtips/10001.pdf 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 18: Led Diagnostics And Troubleshooting

    The Violet/Green or Violet/Brown wire did not detect the expected voltage value. Refer to “Installation MUX not detected. (wiring diagrams & vehicle wiring reference charts)” to check the connections. Flashes red x 7 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 19: Shutdown Codes

    The smart key was not detected, which prevents the system from shutting down the vehicle. Flashes red x 3 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down. Flashes red x 4 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 20: Soft Reset

    DS3+: Release the programming button. The LED turns solid red. & Solid Release DS4+: Release the programming button. The LED turns ON blue for 1 second then solid red. & & Solid Solid x1 Sec Release 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 21: Tach Learning Procedure (Not Needed With Virtual Tach)

    Therefore, there is no Over-Rev protection. If the vehicle attempts to remote start, but is unsuccessful, the remote start will keep the ignition on for the entire runtime period. 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 22: Limited Lifetime Consumer Warranty

    This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 23: Quick Reference Guide

    2-way interaction with your vehicle. Connectivity is managed through the Directed Cloud Services (DCS) network linking car, app, end user, and the Internet. For more information, visit www.mysmartstart.com. 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
  • Page 24 Notes 933.TL6 2.26.198.12 2015 Lexus GS 350 (Smart Key) ©2023 Directed. All rights...
