Monitor User Manual
DHI-LM22-F211
DHI-LM24-F211
DHI-LM27-F211
Please read this manual before use and retain it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DHI-LM22-F211 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dahua Technology DHI-LM22-F211

  • Page 1 Monitor User Manual DHI-LM22-F211 DHI-LM24-F211 DHI-LM27-F211 Please read this manual before use and retain it for future reference.
  • Page 2: Table Of Contents

    TABLE OF CONTENT FOR YOUR SAFETY ��������������������������������������������������������������������������������������������������������������2 PRECAUTIONS �������������������������������������������������������������������������������������������������������������������4 SPECIAL NOTES ON MONITORS �������������������..����������������������������������������������������5 BEFORE YOU OPERATE THE MONITOR ����������������������������������������������������������������������5 FEATURES ����������������������������������������������������������������������������������������������������������������������������5 PACKING LIST ���������������������������������������������������������������������������������������������������������������������5 INSTALLATION INSTRUCTIONS �����������������������������������������������������������������������������6 CONTROLS AND CONNECTORS �������������������������������������������������������������������������������7 ADJUSTING THE VIEWING ANGLE ������������������������������������������������������������������������������8 WALL MOUNTING ���������������������������������������������������..����..����..������..��..�������9 OPERATING INSTRUCTIONS �����������������������������������������������������������������������������������������10 GENERAL INSTRUCTIONS ���������������������������������������������������������������������������������������������10 FRONT PANEL CONTROL ��������������������������������������������������������������������������������������������11...
  • Page 3: For Your Safety

    FOR YOUR SAFETY Before operating the monitor, please read this manual thoroughly� This manual should be retained for future reference� FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to compl with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules�...
  • Page 4 NOTICE: 1� The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment� 2� Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits�...
  • Page 5: Precautions

    PRECAUTIONS • Do not use the monitor near water, e�g� near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement� • Do not place the monitor on an unstable cart, stand, or table� If the monitor falls, it can injure a person and cause serious damage to the appliance�...
  • Page 6: Special Notes On Monitors

    Don’t repair the screen by yourself! BEFORE YOU OPERATE THE MONITOR FEATURES • DHI-LM22-F211: 546.1mm (21�5”) TFT Color Monitor • DHI-LM24-F211: 604.5mm (23.8”) TFT Color Monitor • DHI-LM27-F211: 685.8mm (27”) TFT Color Monitor •...
  • Page 7: Installation Instructions

    INSTALLATION INSTRUCTIONS Attach base: DHI-LM22-F211 Detach base: DHI-LM24-F211 DHI-LM27-F211 POWER CORD Power Source: 1. Please make sure using the correct power cord in your area� 2. This monitor has an external universal power supply that allows operation in either 110/120V AC or 220/240V AC voltage area (No user adjustment is required�) 3.
  • Page 8: Controls And Connectors

    CONTROLS AND CONNECTORS SIGNAL CABLE Connecting the Signal Cable: Connecting the HDMI Cable: (not supplied). Connecting the Power Cord: Caution: If the AC wall outlet is not grounded (with three holes), install the proper grounding adapter (not supplied). 2 3 4 Power input HDMI Signal input D-SUB Signal input...
  • Page 9: Adjusting The Viewing Angle

    ADJUSTING THE VIEWING ANGLE • For optimal viewing, it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference� • Hold the stand so you do not topple the monitor when you adjust the monitor’s angle�...
  • Page 10: Wall Mounting

    WALL MOUNTING Preparing to install an optional wall mounting arm� This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure. Follow these steps: 1. Remove the base� 2. Follow the manufacturer's instructions to assemble the wall mounting arm� 3.
  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off� The other control buttons are located on the side of the monitor (See Figure 4)� By changing these settings, the picture can be adjusted to your personal preferences� •...
  • Page 12: Front Panel Control

    FRONT PANEL CONTROL • Power Button: Press to switch the monitor on or off� • Power Indicator: Blue — Power On mode� Blue blinking — Standby mode� LED off — Off mode� • MENU / ENTER: Active OSD menu or function adjust confirm or Exit OSD menu when in Brightness/ Contrast OSD status�...
  • Page 13: How To Adjust A Setting

    NOTES • Do not install the monitor in a location near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, or excessive dust or mechanical vibration or shock� • Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your monitor�...
  • Page 14: Adjusting The Picture

    ADJUSTING THE PICTURE The descriptions for function control: Main Menu Main Menu Sub Menu Item Sub Menu Description Item Icon Contrast Contrast from Digital-register� Brightness Backlight Adjustment Text Text Mode Internet Internet Mode Game Game Mode Luminance Eco Mode Movie Movie Mode Sports Sports Mode...
  • Page 15 Main Menu Main Menu Sub Menu Item Sub Menu Description Item Icon Auto/D-SUB/ Input Select Select input source HDMI DDC/CI Select DDC/CI on or off Extra Reset Reset the menu to default� Show the information of the Information main image source�...
  • Page 16: Plug And Play

    PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD� It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities�...
  • Page 17: Technical Support (Faq)

    TECHNICAL SUPPORT (FAQ) Problem & Question Possible Solution • Check if the Power Switch is in the ON position� Power LED is not on • Power Cord should be connected� • Check if the PC system is Plug & Play compatible� No Plug &...
  • Page 18: Error Message & Possible Solution

    ERROR MESSAGE & POSSIBLE SOLUTION NO SIGNAL 1� Check that the signal-cable is properly connected� If the connector is loose, tighten the connector’s screws� 2� Check the signal-cable’s connection pins for damage� INPUT NOT SUPPORT Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table on page 21�...
  • Page 19: Appendix

    APPENDIX SPECIFICATIONS (DHI-LM22-F211 ) Driving system 21�5” TFT Color LCD LCD Panel Size 546.1mm diagonal Pixel Pitch 0�24795mm(H) × 0�24795mm(V) R, G, B Analog Interface Video HDMI/D-SUB Input Separate Sync� H/V TTL H-Frequency 30kHz – 83kHz V-Frequency 50-76Hz Display Colors 16�7M Colors...
  • Page 20 APPENDIX SPECIFICATIONS (DHI-LM24-F211 ) Driving system 23�8” TFT Color LCD LCD Panel Size 604.5mm diagonal Pixel Pitch 0�2745mm(H) × 0�2745mm(V) R, G, B Analog Interface Video HDMI/D-SUB Input Separate Sync� H/V TTL H-Frequency 30kHz – 83kHz V-Frequency 50-76Hz Display Colors 16�7M Colors Dot Clock 170MHz...
  • Page 21 APPENDIX SPECIFICATIONS (DHI-LM27-F211 ) Driving system 27” TFT Color LCD LCD Panel Size 685.8mm diagonal Pixel Pitch 0�3114mm(H) × 0�3114mm(V) R, G, B Analog Interface Video HDMI/D-SUB Input Separate Sync� H/V TTL H-Frequency 30kHz – 83kHz V-Frequency 50-76Hz Display Colors 16�7M Colors Dot Clock 170MHz...
  • Page 22: Factory Preset Timing Table

    640x480@60Hz 31.469 59.940 640x480@72Hz 37.861 72.809 640x480@75Hz 37.500 75.00 800x600@60Hz 37.879 60.317 800x600@72Hz 48.077 72.188 800x600@75Hz 46.875 75.000 1024x768@60Hz 48.363 60.004 1024x768@70Hz 56.476 70.069 1024x768@75Hz 60.023 75.029 1440x900@60Hz 55.935 59.887 1440x900@75Hz 70.635 74.984 1680x1050@60Hz 65.290 59.954 1280x1024@60Hz 69.981 60.020 1280x1024@75Hz 79.976 75.025 1920x1080@60Hz...
  • Page 23: Connector Pin Assignment

    CONNECTOR PIN ASSIGNMENT 15 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. DESCRIPTION Green Ground Blue Ground Ground DDC-Serial Data Detect Cable H-Sync R-Ground V-Sync G-Ground DDC-Serial Clock B-Ground 19 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO.
