- Page 1 UHD LED MONITOR User Manual...
-
Page 2: Table Of Contents
Contents Important Information ........................2 Safety Warning ..........................2 Notes ..............................2 Introduction to the Product ........................4 Product Appearance ........................4 Performance Features ........................4 External Connections ..........................4 Main Menu ............................6 Main Menu ............................6 Picture Menu ...........................7 Sound Menu ............................7 Option Menu ...........................7 Screen Menu ............................8 Channel Selection ..........................8 How to Clean Product .........................9 Troubleshooting ..........................9... -
Page 3: Important Information
Important Information Safety Warning To use the product safely, correctly, and to keep users from suffering injury or property loss, please observe the following safety precautions when installing, using or maintaining. Please read this handbook before operating the product and keep the handbook for future reference. - Page 4 If the product is installed on the wall, please make sure the wall’s load bearing capacity is sufficient. To avoid falling and injuring people, install according to the included instructions with mounting hardware. The LCD may experience image distortion or color decay when the temperature variation is too large.
-
Page 5: Introduction To The Product
Introduction to the Product Product Appearance （Photos are for reference only） Performance Features Supports 3D comb-filter and 3D de-interlace. Low energy consumption, long service life. High contrast ratio and high luminance. Automatically eliminates ghosting. Rapid response times, no trailing image. ... -
Page 6: External Connections
External Connections Please connect the monitor to external devices according to the following I/O interface list. Choose the corresponding incoming signal channel. Port A： Port B： Port C： VGA INPUT: D-SUB 15 pins Connector HDMI INPUT: HDMI Connector BNC IN: BNC Connector BNC OUT: BNC Connector AUDIO IN: Phone Jack, Stereo USB IN：Support USB update... -
Page 7: Main Menu
Main Menu Main Menu To activate, press the menu button on the bottom left of the bezel. The sub-menus of the main menu are: PC Menu, Picture menu, Audio menu, OSD menu, Function menu and Geometry menu. Press the menu button to select the sub-menu item. The selected menu item will show a bordered wireframe. -
Page 8: Picture Menu
Press the button to change the selected function in OSD menu item. F. “Menu” button Press the button to display the OSD main menu. Press the button to Exit the OSD menu or menu item. G. “Power” button ... -
Page 9: Channel Selection
enable / disable auto sleep. Press ▲▼ button to adjust value when item is selected, press menu button to exit. Screen Menu Screen menu can adjust the H-position, V-position, clock, phase and auto adjust the position of the image within the unit. Press ▲▼ button to adjust value when item is selected, press menu button to exit. -
Page 10: How To Clean Product
