- Page 1 E331 Series Gaming Monitor User’s Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0...
-
Page 2: Foreword
User’s Manual Foreword General This manual describes the functions, operations, and precautions of the E331 Series Gaming Monitor Devices (hereinafter referred to as the "Devices"). Please read the device carefully before using it, and keep the instruction manual for future reference. - Page 3 User’s Manual We are not liable for losses incurred due to operating the product in ways that are not in compliance with the manual. The manual will be updated according to the latest laws and regulations of related jurisdictions. For detailed information, see the paper user's manual, use our CD-ROM, scan the QR code or visit our official website.
-
Page 4: Important Safeguards And Warnings
User’s Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, and comply with the guidelines when using it. Operation Requirements WARNING Do not tread on or squeeze the power line, especially the plug or connection point of the power line to the product. - Page 5 User’s Manual Do not hang or lean on the product. Doing so can cause the product to fall or become damaged. It may also cause injury to people. Pay special attention when children are nearby. If the product is installed on the wall, please make sure the wall's load bearing capacity is sufficient.
- Page 6 User’s Manual CAUTION Do not adjust, maintain or modify if you do not have appropriate qualifications. Do not open or remove the rear cover, box or cover board of the product. Please contact the dealer or after-sales service center when in need of adjustment or maintenance. Only qualified service people can maintain.
-
Page 7: Table Of Contents
User’s Manual Table of Contents Foreword - - - - - - - - - - - - - - - - - - - - - - - - - -- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -I Important Safeguards and Warnings --------------------------------... -
Page 8: Product Information
User’s Manual Product Information 1. Packing List DHI-LM27-E331 Figure 1-1 Packing List Table 1-1 Packing List Meaning Display screen Base/Stand Power cable Power adapter DP signal cable M4×16mm Screw bolts Legal and regulatory information User's manual QR code stickers NOTE The above appendix products are for reference only, the supporting products of different models of monitors may be slightly different from those in the figure, and everything is subject to reality. - Page 9 User’s Manual DHI-LM27-E331A Figure 1-2 Packing List Table 1-2 Packing List Meaning Display screen Base/Stand Power cable Power adapter DP signal cable M4×16mm Screw bolts Legal and regulatory information User's manual QR code stickers NOTE The above appendix products are for reference only, the supporting products of different models of monitors may be slightly different from those in the figure, and everything is subject to reality.
-
Page 10: Monitor Adjustments
User’s Manual 2. Monitor Adjustments The adjustment functions of the display include tilt angle adjustment, screen vertical rotation angle adjustment, left and right rotation angle adjustment, and height adjustment, as shown in the figure below. Different types of displays have different adjustment functions, and the specific adjustment functions are subject to the actual model adjustment functions. - Page 11 User’s Manual DHI-LM27-E331A Figure 2-2 Monitor adjustments ° 20° 90mm Tilting angle Height adjustment 5.0°(±3.0°) ~ - 20°(±3.0°) 90mm( - 5.0mm) Rotation angle ±20°( - 3.0°) NOTE When adjusting the angle of the monitor, be sure not to touch or press the area of the screen. The above figure is for reference only, and everything is subject to the actual adjustment function.
-
Page 12: Button Description
User’s Manual 3. Button Description DHI-LM27-E331 Figure 3-1 Indicator and button display Table 3-1 Indicator description (1) Name Description The blue light indicates that the power supply is normal and the monitor is running normally. LED indicator light Blinking red and blue lights indicate no video source, no ... - Page 13 User’s Manual DHI-LM27-E331A Figure 3-2 Indicator and button display Table 3-2 Indicator description (1) Name Description The blue light indicates that the power supply is normal and the monitor is running normally. LED indicator light Blinking red and blue lights indicate no video source, no ...
-
Page 14: Cable Connection
User’s Manual 4. Cable Connection DHI-LM27-E331 Figure 4-1 Input and output interface Table 4-1 Input and output ports Port Function x1/ Power interface. x1/ Upgrade only. x2/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC. - Page 15 User’s Manual DHI-LM27-E331A Figure 4-2 Input and output interface Table 4-2 Input and output ports Port Function x1/ Power interface. x1/ Upgrade only. x2/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC.
-
Page 16: Menu Description
User’s Manual 5. Menu Description The color and shape of the OSD menu of the actual computer may be slightly different from that shown in the figure, and everything that has been actually displayed shall prevail. Specifications of the OSD menu may change with improvements of functions without prior notice. DHI-LM27-E331/E331A The On-Screen Display (OSD) menu allows you to adjust the settings of your display, turn on the monitor and move the joystick to the right to display the navigation interface. -
Page 17: Operation Menu(Osd) Function Descriptions
User’s Manual 6. Operation Menu(OSD) Function Descriptions DHI-LM27-E331/E331A Table 6-1 OSD Menu description Main Menu ub Menu Option Option Brightness 0-100 Contrast 0-100 Black Equalize 0-100 Standard/User/Movie/Photo/ Display Preset RTS/FPS1/FPS2 Aspect Ratio Full/16:9/4:3 0、10、20、30、40、50、 Sharpness 60、70、80、90、100 Color Temperature Warm/Normal/Cool/sRGB/User Red/Green/Blue Gamma O /1.8/2.0/2.2/2.4 0-100... - Page 18 User’s Manual Main Menu ub Menu Option Option ENGLISH/简体中文/繁体中文/ Language 한국어 H Position 0-100 V Position 0-100 OSD Setup OSD Timeout /15/30/45/60 System Transparency 0/20/40/60/80/100 Mute O /On Audio Volume 0-100 USB Upgrade Conf irm/Cancel Reset Conf irm/Cancel NOTE The OSD features in the table above are for reference only and may differ from the actual display, so the OSD features of the actual display shall prevail.
-
Page 19: Product Specifications
User’s Manual 7.Product Specifications Table 7-1 Product specifications Product model DHI-LM27-E331 DHI-LM27-E331A Screen Size 27" 27" Aspect Ratio 16:9 16:9 Viewing Angle 178°(H) / 178°(V) 178°(H) / 178°(V) Contrast ratio 1000:1 (TYP) 1000:1(TYP) Colors 16.7M 16.7M Resolution 2560x1440 2560x1440 Maximum refresh rate 180Hz 180Hz 616×57.5×364.3mm... -
Page 20: Appendix 1 Troubleshooting
User’s Manual Appendix 1 Troubleshooting Appendix Table 1-1 FAQ Faults occurring Possible solutions Check if the power is on. The power indicator light is not on Check if the power cord is connected. Check if the function of plug-and-play of the device is compatible with PC. -
Page 21: Appendix 2 Cybersecurity Recommendations
User’s Manual Appendix 2 Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. - Page 22 User’s Manual 6. Enable HTTPS We suggest you to enable HTTPS, so that you visit Web service through a secure communication channel. 7. MAC Address Binding We recommend you to bind the IP and MAC address of the gateway to the device, thus reducing the risk of ARP spoofing.
- Page 23 User’s Manual announcements and the latest security recommendations.
- Page 24 ENABLING A SAFER SOCIETY AND SMARTER LIVING ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. Address: No.1399, Binxing Road, Binjiang District, Hangzhou, P. R. China | Website: www.dahuasecurity.com | Postcode: 310053 Email: overseas@dahuatech.com | Fax: +86-571-87688815 | Tel: +86-571-87688883...
