- Page 1 P1.86 Indoor Full-color LED Display （320×160） V1.0.0...
-
Page 2: Table Of Contents
Catalogue Chapter 1 Product Introduction ......................1 Chapter 2 Appearance Structure ......................2 2.1 Appearance Picture ........................2 2.2 Technical Parameter ........................2 2.3 Packing List .............................4 2.4 Power Supply Configuration Project ....................4 2.5 Accessories ............................. 4 Chapter 3 Interface Definition ........................ 6 Chapter 4 Installation .......................... -
Page 3: Chapter 1 Product Introduction
Chapter 1 Product Introduction High refresh、 High gray scale The refresh rate can reach more than 3840Hz, the gray scale is 12~14 bit, the display picture is fine and true, the brightness is stable and uniform, there is no flicker and graininess. Driving solutions ... -
Page 4: Chapter 2 Appearance Structure
Chapter 2 Appearance Structure 2.1 Appearance Picture Picture 2-1 Appearance Picture 2.2 Technical Parameter Table 2-2 Technical Parameter Item Parameter Ordinary Standard Configuration Product Mode IFS-CIA1.8S-C Pixel Composition SMD1515 3-in-1 LED Pixel Pitch（mm） 1.86 Module Resolution（W×H） 172×86=14792 Module Size（mm） 320×160×14.7 Module Module Weight（kg）... - Page 5 Item Parameter Ordinary Standard Configuration Cabinet Material Die-casting Aluminum Single point brightness correction Single Dot Color Amended White Balance Brightness ≥500 Optical （nits） Parameter Color Temperature（K） 2000—9300 (adjustable) Visual Angle 160°/ 140° （Horizontal/Vertical） Brightness / Colorful Evenness ≥99% Contrast Ratio 3000:1 The Max Power Consumption of Cabinet（W）...
-
Page 6: Packing List
2.3 Packing List Table 2-3 Packing List Packing List Unit LED Display User Manual Approved Certificate Warranty Card Construction Notification 2.4 Power Supply Configuration Project Table 2-4 Power Supply Configuration solution Power Supply Configuration Project 40A Power Supply Can load 6pcs modules 60A Power Supply Can load 10pcs modules 2.5 Accessories... - Page 7 Accessories Name Picture Cabinet fixing bolts (according to different cabinets and installation methods, common specifications include M8 * 60 and M8 * 20)
-
Page 8: Chapter 3 Interface Definition
Chapter 3 Interface Definition Picture3-1 Interface Picture（HUB75） Table 3-2 Interface Definition Signal Function Signal Function Red Data Signal Green Data Signal Blue Data Signal Power Ground Red Data Signal Green Data Signal Blue Data Signal Power Ground Row Decoding Signal Row Decoding Signal Row Decoding Signal No Signal... -
Page 9: Chapter 4 Installation
Chapter 4 Installation 4.1 Kit Installation Picture 4-1 Hole Installation Diagram for Kit... -
Page 10: Cabinet Installation
4.2 Cabinet Installation Table 4-2-1 Diagram for Cabinet installation 4.2.2 Cabinet Front Installation Picture 4-2-2 Explosion diagram of Cabinet Front Installation... -
Page 11: Cabinet Rear Installation
Picture 4-2-3 Completion Cabinet Front Installation 4.2.3 Cabinet Rear Installation Picture 4-2-4 Explosion diagram of Cabinet Rear Installation... - Page 12 Picture 4-2-5 Completion Cabinet Rear Installation...
-
Page 13: Display Installation
4.3 Display Installation 4.3.1 Diagram for Cable Connection Picture 4-3-1 Diagram for Connection... -
Page 14: Networking Introduction
4.3.2 Networking Introduction Picture 4-3-2 Topographic Picture for networking... -
Page 15: Installation Method
4.3.3 Installation Method Installation Type Picture Wall Mounted Installation Floor Mounted Installation... -
Page 16: Chapter 5 User Manual
Chapter 5 User Manual Table 5-1 Notification Item Notification Keep the work temperature within -20℃～40℃ Temperature Keep the storage temperature within -10℃～30℃ Keep the work humidity within 10%RH～65%RH Humidity Keep the storage humidity within 10%RH～60%RH Waterproof Cabinet: IP30; Module: IP30 Dust-proof Cabinet: IP30;... -
Page 17: Chapter 6 Acceptance Request And Method
Chapter 6 Acceptance Request and Method Table 6-1 Acceptance Request and Method for LED display Item Acceptance Request and Method Brightness of LED Switch LED display to work as full brightness, use light-gun to Display measure the brightness of LED display within 10 minutes. When measuring its brightness, the light-gun need be vertical to LED display, to adjust the distance of light-gun and LED display, ensure the view window, black area, cover above 16 pixels, adjust focal...
