- Page 1 E230C Series LED Monitor User’s Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0...
-
Page 2: Foreword
User’s Manual Foreword General This manual introduces the installation, functions and operations of the E230C device (hereinafter referred to as the "Device"). Read carefully before using the device, and keep the manual safe for future reference. Models DHI-LM24-E230C, DHI-LM27-E230C,DHI-LM32-E230CN. Safety Instructions The following signal words might appear in the manual. -
Page 3: About The Manual
User’s Manual Interface Declaration This manual mainly introduces the relevant functions of the device. The interfaces used in its manufacture, the procedures for returning the device to the factory for inspection and for locating its faults are not described in this manual. Please contact technical support if you need information on these interfaces. -
Page 4: Important Safeguards And Warnings
User’s Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, and comply with the guidelines when using it. Transportation Requirements Transport the device under allowed humidity and temperature conditions. -
Page 5: Operation Requirements
User’s Manual ○ The voltage must meet the SELV (Safety Extra Low Voltage) requirements and not exceed ES-1 standards. ○ When the power of the device does not exceed 100 W, the power supply must meet LPS requirements and be no higher than PS2. ◇... -
Page 6: Maintenance Requirements
User’s Manual ● Use the power cords that are recommended for the region and conform to the rated power specifications. ● In a domestic environment this may cause radio interference in which case you may be required to take adequate measures. ●... -
Page 7: Table Of Contents
User’s Manual Table of Contents Foreword - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Important Safeguards and Warnings - - - - - - - - - - - - - - - - - - - - - - - - - - Product Information... -
Page 8: Product Information
User’s Manual Product Information 1. Packing List DHI-LM24-E230C / DHI-LM27-E230C Figure 1-1 Packing List (1) ⑤ ① ② ③ ④ MONITOR INSTALLATION GUIDE ⑪ ⑥ ⑦ ⑧ ⑨ ⑩ Table 1-1 Packing List (1) Meaning ① Display screen ② Base/Stand ③... - Page 9 User’s Manual DHI-LM32-E230CN Figure 1-1 Packing List (2) ⑤ ① ② ③ ④ MONITOR INSTALLATION GUIDE ⑪ ⑥ ⑦ ⑧ ⑨ ⑩ Table 1-1 Packing List (2) Meaning ① Display screen ② Base/Stand ③ Power cable ④ DP signal cable ⑤...
-
Page 10: Monitor Adjustments
User’s Manual 2. Monitor Adjustments Some displays can be angled by tilting forward and backward, and typically, it can tilt 5±2° forward and 15±2° backwards. The specific adjustment function is subject to the adjustment function of the actual model. Figure 2-1 Monitor adjustments -5°... -
Page 11: Button Description
User’s Manual 3. Button Description DHI-LM24-E230C Figure 3-1 Indicator and button display (1) Table 3-2 Indicator description (1) Name Description The white light indicates that the power supply is normal and the monitor is running normally. Red light indicates no video source, no horizontal or vertical LED indicator light signal or low voltage is detected. - Page 12 User’s Manual DHI-LM27-E230C Figure 3-1 Indicator and button display (2) Table 3-2 Indicator description (2) Name Description The blue light indicates that the power supply is normal and the monitor is running normally. Red light indicates no video source, no horizontal or vertical LED indicator light signal or low voltage is detected.
- Page 13 User’s Manual DHI-LM32-E230CN Figure 3-1 Indicator and button display (3) Table 3-2 Indicator description (3) Name Description The blue light indicates that the power supply is normal and the monitor is running normally. Flashing blue light indicates no video source, no horizontal or LED indicator light vertical signals, or too low a voltage.
-
Page 14: Cable Connection
User’s Manual 4. Cable Connection DHI-LM24-E230C / DHI-LM27-E230C Figure 4-1 input and output interface (1) Input and output ports HDMI HDMI AUDIO OUT Table 4-1 Input and output ports (1) OSD Button Function Used to connect power adapters. x1/ Use the DP cable to connect to a desktop PC. x2/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC. - Page 15 User’s Manual DHI-LM32-E230CN Figure 4-1 input and output interface (2) Input and output ports HDMI AUDIO OUT POWER CONNECTOR Table 4-1 Input and output ports (2) OSD Button Function x1/ Use the DP cable to connect to a desktop PC. x1/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT HDMI interface of a PC.
-
Page 16: Menu Description
User’s Manual 5. Menu Description The color and shape of the OSD menu of the actual computer may be slightly different from that shown in the figure, and everything that has been actually displayed shall prevail. Specifications of the OSD menu may change with improvements of functions without prior notice. DHI-LM24-E230C / DHI-LM27-E230C The On-Screen Display (OSD) menu allows you to adjust the settings of your display, turn on the monitor and move the joystick to the right to display the navigation interface. - Page 17 User’s Manual DHI-LM32-E230CN The on-screen display (OSD) menu can be used to adjust the settings of the monitor and is displayed on the screen after turning on the monitor and pressing the button. Step 1. Press one of the buttons to activate the Navigation window. Figure 5-1 Navigation window (2) Table 5-1 Icon function (2) Icon...
-
Page 18: Operation Menu(Osd) Function Descriptions
User’s Manual 6. Operation Menu (OSD) Function Descriptions DHI-LM24-E230C / DHI-LM27-E230C Table 6-1 OSD Menu description (1) Main Menu Sub Menu Option Standard Mode Off/On RTS/RPG Mode Off/On FPS Arena Mode Off/On MOBA Arena Mode Off/On Adaptive-Sync Off/On Shadow Balance 0-100 Game Settings Response Time... -
Page 19: Main Menu Sub Menu
User’s Manual Main Menu Sub Menu Option User3 Off/On:0-100(R/G/B) Color Settings 0-100(R/G/B/C/M/Y) Saturation 0-100(R/G/B/C/M/Y) PIP/PBP Mode Off/PIP Mode/PBP 2Win 1:1 Sub-Signal Source DP/HDMI1/HDMI2 Audio Source Auto/DP/HDMI1/HDMI2 PIP/PBP PIP Position TopRight/TopLeft/BottomRight/BottomLeft Small/Medium/Large PIP Size Window Swap Off/On Simplified Chinese/English/한국어 / /Portugues do Brasilazil/Deutsch/ Nederland/Suomi/Français/Eλληvικά/Indonesia/Italiano/Japanese/Malaysia/ Language Polskie/Português/Русский/Español/ไทย/Українська/Tiếng Việt/Chinese... - Page 20 User’s Manual DHI-LM32-E230CN Table 6-1 OSD Menu description (2) Menu Sub Menu Value Range BRIGHTNESS 0-100 CONTRAST 0-100 BRIGHTNESS STANDARD/GAME/RTS/FPS/MOVIE/TEXT ON/OFF ON/OFF H. POSITION V.POSITION IMAGE CLOCK PHASE ASPECT WIDE/AUTO/4:3 COLOR TEMP. WARM/COOL/USER 0-100 COLOR TEMP. GREEN 0-100 BLUE 0-100 ENGLISH / FRANÇAIS / DEUTSCH / SIMPLIFIED CHINESE / ITALIANO / ESPAÑOL / LANGUAGE PORTUGUÊS/TURKCE / POLSKI / NEDERLANDS / PУССКИЙ...
-
Page 21: Appendix 1 Security Commitment And Recommendation
User’s Manual Security Commitment and Recommendation Dahua Vision Technology Co., Ltd. (hereinafter referred to as "Dahua") attaches great importance to cybersecurity and privacy protection, and continues to invest special funds to comprehensively improve the security awareness and capabilities of Dahua employees and provide adequate security for products. - Page 22 User’s Manual Dahua device supports password reset function. To reduce the risk of this function being used by threat actors, if there is any change in the information, please modify it in time. When setting security questions, it is recommended not to use easily guessed answers. 2.
- Page 23 User’s Manual 4.1 Check online users It is recommended to check online users regularly to identify illegal users. 4.2 Check device log By viewing logs, you can learn about the IP addresses that attempt to log in to the device and key operations of the logged users.
- Page 24 E N ABLIN G A SMAR T ER SO C IE TY AN D BE TTE R L IVING ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. Address: No.1399, Binxing Road, Binjiang District, Hangzhou, P. R. China | Website: www.dahuasecurity.com | Postcode: 310053 Email: dhovereas@dhvisiontech.com | Tel: +86-571-87688888 28933188...
