Summary of Contents for Dahua Technology DHI-LM24-B200
- Page 1 Commercial LED Display User Manual...
-
Page 2: Table Of Contents
Contents Important Information ........................2 Safety Warning ......................... 2 Notes ............................3 Introduction to the Product ......................4 Product Appearance ......................... 4 Performance Features ......................4 External Connections ........................4 Main Menu ............................6 Main Menu ..........................6 PC Menu ........................... 7 Picture Menu .......................... -
Page 3: Important Information
Important Information Safety Warning To use the product safely, correctly, and to keep users from suffering injury or property loss, please observe the following safety precautions when installing, using or maintaining. Please read this handbook before operating the product and keep the handbook for future reference. -
Page 4: Notes
Notes Please put the product in a flat, stable and dry place. Avoid direct sunlight, high temperature, humidity, dust, and corrosive gas. If the product is installed on the wall, please make sure the wall’s load bearing capacity is sufficient. -
Page 5: Introduction To The Product
Introduction to the Product Product Appearance （Photos are for reference only） Performance Features Low energy consumption, long service life. High contrast ratio and high luminance. Automatically eliminates ghosting. Rapid response times, no trailing image. Thin and light. ... - Page 6 Port A： Port B： Port C： VGA INPUT: D-SUB 15 pins Connector HDMI INPUT: HDMI Connector AUDIO IN: 3.5mm audio port AUDIO OUT: 3.5mm audio port Attention Please turn off the power of the external device and the product when connecting.
-
Page 7: Main Menu
Main Menu Main Menu To activate, press the menu button on the bottom left of the bezel. The sub-menus of the main menu are: PC Menu, Picture menu, Audio menu, OSD menu and Function menu. Press the menu button to select the sub-menu item. The selected menu item will show a bordered wireframe. -
Page 8: Pc Menu
PC Menu（PC SOURCE） PC menu sets the contrast, brightness, backlight,color temperature and scale function. Press ▲▼ button to adjust value when item is selected, press menu button to exit. Picture Menu（HDMI SOURCE） Picture menu can set contrast, brightness, backlight, hue, saturation, sharpness, color temperature and scale function. -
Page 9: Osd Menu
OSD Menu OSD menu can adjust the sleep timer, enable / disable auto sleep, change the language, adjust H-position, adjust V-position, adjust duration, adjust transparency, and reset defaults. Press ▲▼ button to adjust value when item is selected, press menu button to exit. Function Menu（HDMI SOURCE）... -
Page 10: Geometry Menu
Geometry Menu（PC SOURCE） Geometry menu can adjust the H-position, V-position, clock, phase and auto adjust. Press ▲▼ button to adjust value when item is selected, press menu button to exit. Channel Selection “Source” menu can select channel (input). The options include VGA, HDMI. Press ▲▼ button to adjust value when item is selected, press menu button to exit. -
Page 11: How To Clean Product
How to Clean Product 1. Please wipe dust and other particles off with a clean soft towel. 2. If it is still not clean, please use a neutral cleaner along with the clean soft towel. Wipe dry after cleaning it. 3. - Page 12 Switch to another channel or input. Check whether the audio signal line is connected. Check whether the video signal line is connected. Interference from by other electric appliance may be present. Adjust fine tuning setting. Adjust luminance setting. Adjust contrast ratio setting. Adjust color setting.
