Summary of Contents for Discount Car Stereo BTH-GM1
- Page 1 Courtesy of: DiscountCarStereo.com Serving the internet community since 1995 BTH-GM1 BLUETOOTH HANDS-FREE, STREAMING INSTALLATION GUIDE FOR 1995-05 GM WITH SEPARATE /SLAVE UNIT Created August 16, 2024 Revised September 23, 2024...
- Page 2 Purchase our BLU-GM1 instead. This module does not support phone calls. Purchase our BTH-GM1 instead. Warning: The AM/FM/CD or TAPE radio (See Fig. 11) in upper dash is not a Fig. 2 separate or slave player. Separate or slave players (See Fig. 12) are installed 2.
- Page 3 4. Connect installation harness 16-pin plug (See Fig. 5) to module 16-pin socket (See Fig. 6) Fig. 3 9-pin socket Fig, 5 16-pin plug 3. Connect installation harness 9-pin plug (See Fig. 4) to radio 9-pin socket vacated in Step 1. Fig.
- Page 4 Optional USB extension cable installation Note: 1. Optional USB dash mount extension cable is not required for operation, however it extends USB charging port (See Fig. 9) to dashboard, glovebox etc. The USB port supports charging only Drill a ¾” hole to dash or panel using a step drill bit or equivalent (See Fig. Fig.
-
Page 5: Operation
Pairing Operation Pairing process varies among devices but the basic steps are the same. This process is done upon initial install and will not have to be repeated. Turn ignition and radio “ON” 2. Press “TAPE AUX” or “CD AUX” button on AM/FM Theftlock radio Turn Ignition and radio “ON”... -
Page 6: Feature Comparison
Fig. 14). For the BTA-GM1 (formerly A2D-GM1) to work as described, your vehicle must have at least one fully functioning separate unit (See Fig. Feature AUX-GM1 DCS-GM1 BTA-GM1 BTH-GM1 BLU-GM1 14) otherwise it will not work as described. Retains separate player* ✓ ✓... - Page 7 •We recommend professional installation. Email support@discountcarstereo.com © 1995-Feb-19 Discount Car Stereo, Inc. All rights reserved. Information in this document is subject to change without notice. Other products and companies referred to herein are trademarks or registered trademarks of their companies or mark holders.
