OpenEye OE-C2212B4 Quick Start Manual

CONNECTIONS
1
2
Waterproof Cable
5 4
1 1 Thread lock cap Thread lock cap
2 2 Rubber plug Rubber plug
3 3 RJ45 enclosure RJ45 enclosure
Liberty Lake, WA, USA
509.232.5261
openeye.net
1 1 RJ-45 RJ-45 For network and PoE connections For network and PoE connections
Power Power
2 2 Power connection Power connection
(12vDC)* (12vDC)*
*12vDC power input port should be plugged when not in use.
To restore the camera to To restore the camera to
factory defaults: factory defaults:
1. 1. Disconnect power for 30 Disconnect power for 30
seconds. seconds.
Reset Button Reset Button
2. 2. Reconnect power and wait 30 Reconnect power and wait 30
seconds. seconds.
3. 3. Press and hold the reset but- Press and hold the reset but-
ton for 20 seconds. ton for 20 seconds.
Supports up to 512GB Supports up to 512GB
microSD card for Edge storage. microSD card for Edge storage.
MicroSD Card Slot MicroSD Card Slot Do not add or remove the Do not add or remove the
microSD card when the microSD card when the
camera is powered on. camera is powered on.
3 1
2
4 4 Rubber "O" ring Rubber "O" ring
5 5 Camera cable Camera cable
Copyright ©2024 OpenEye.
All Rights Reserved. Information contained in this document
is subject to change without prior notice. OpenEye does its
best to provide accurate information but cannot be held
responsible for typos or mistakes.
This quick start guide provides
only basic information on the
camera's settings and operation
for initial installation. Please read
the user manual for optimal
camera configurations.
Find the latest product
documentation and software.
Scan the QR code or go to
openeye.net/downloads
QUICK START GUIDE
4MP Outdoor IP Bullet
OE-C2212B4
38200AC
