HONDA CBR500R/CB500F/ CB500X '21-
M
O
RE F 21146
1 Person
40 min
EASY
ID
PIEZA/PART
1
2
3
4
5
6
7
8
*
Algunos componentes se suministran montados.
Some components are supplied assembled.
U
N
T
I
N
G
GUARDABARROS TRASERO / REAR MUDG UARD
DESCRIPCIÓN
Guardabarros
Soporte derecho
Tuerca enjaulada de aluminio M6
Tornillo Allen M6x20 Ø14 ISO7380
Tornillo Allen M6x16 Ø14 ISO7380
Silentblock Ø18x Ø9 xØ11 x8
Casquillo con valona Ø15 xØ9 x7,5
Tapón tornillo M6
www.puig.tv
www.puigusa.com
I
N
S
T
R
DESCRIPTION
Rear mudguard
Right Support
M6 lock nut
M6x20 Ø14 ISO7380 Allen screw
M6x16 Ø14 ISO7380 Allen screw
Ø18x Ø9 xØ11 x8 silentblock
Ø15 xØ9 x7,5 bush with flange
M6 screw cap
Pg. 1/4
info@puigusa.com
U
C
T
I
O
N
QTY
1
1
2
1
3
4
4
4
Illustrations and layout by: www.ciandisseny.com
info@puig.tv
S
Nº 8
Nº 13
ALLEN
Nº 4
Nº 8
REF
21146J/CM3
SOP1P3----21146
TUERCAJFM6--319
TORNI-I7380-404
SILENBGONE--064
CASQUI-1A---324
TAPON--------86
V0.07/22
