MOTOPLASTIC, S.A.
CÚPULA ADAPTABLE A - SCREEN FOR - WINDSCHUTZSCHEIBE FÜR
KTM 1290 SUPERADVENTURE
Mod. TOURING
Cúpula ORIGINAL
ORIGINAL screen
A
A
PIEZA ORIGINAL SOLO EN ALGUNOS MODELOS KTM.
A
ORIGINAL PART, ONLY IN SOME KTM MODELS.
Pg. 1/2
Ref.: 6494
(Mod. TOURING)
1050/1090/1190 ADVENTURE
1290 SUPERADVENTURE T
1
A
A
INSTRUCCIONES DE MONTAJE
MOUNTING INSTRUCTIONS
MONTAGEANLEITUNG
Mod. SPORT
ID. PIEZA/PART DESCRIP .
Cúpula TOURING
TOURING screen
1
Cúpula SPORT
SPORT screen
Tornillo especial M5x9+Hexagonal Long. 20mm
Special screw M5x9+Hexagonal Length 20mm
FOR KTM 1050/ 1090 / 1190 ADVENTURE
2
Tornillo especial M5x9+Hexagonal Long. 20mm
Special screw M5x9+Hexagonal Length 20mm
FOR KTM 1290 SUPERADVENTURE ADVENTURE
Arandela de goma Ø ext. 15 Ø int. 5x4
3
Ø outer 15 x Ø inner 5x4 rubber washer
Ref.: 6847
(Mod. SPORT)
QTY.
1
2
4
4
4
