Assembly Of The Stacking Device - Hoppecke grid XtreneStack Assembly Manual

2 (2) x
Increases
8 (8) x Washer fo
M8
Stacking aid
Stacking rack
depending on the
number of shelves
4,5 or 6.

9 Assembly of the stacking device

After you have completed the assembly preparation, you can start
assembling the stacking devices. It is recommended to perform the assembly
with two professionals to ensure a safe assembly.
You will need the following tools to assemble the fixture:
➢ Rubber hammer
Large ratchet with 13mm socket
➢
➢ 13mm wrench
➢ Spirit level
Folding rule / measuring tape
➢
Raising set
4 (4)x
Connector for Pressure rivet
40 mm profile
4 (4) x Nut M8 8 (8) x PE-cap
Additional kit stacking aid
Spacer strips 150
x 10 x 5 mm
depending on
stack height 14, 18
www.hoppecke.com
4 (4) x 4 (4) x Screw
für M8
Anti-slip adhesive
tape depending on
stack height 4, 5
or 21.
M8x65
or 6.
9/20
