11 Fixing the grid | XtremeStack

It is essential that the stacking device is fixed to the wall to prevent it from
tipping over.

11.1 Wall- and floor mounting

➢ The 1-row stacking devices must be connected to the wall on each
side using the bracket supplied once the batteries have been
successfully fitted.
➢ Alternatively, it is possible to use optional floor fixings to prevent the
racks from tipping over. The floor fixings are screwed to the
connecting screws of the floor section facing inwards and then fixed
to the floor using suitable fixing material (not included).

11.2 Aisle connector

➢ If 1- and 2-row racks are used to construct a larger system, these
racks must be connected to each other with optional aisle connectors
to create an overall connection and thus prevent the stacking device
from tipping. The aisle connectors are bolted to the upper base
assembly and the side section.
