Industrial Flat Panels V2 Hygienic

SIMATIC HMI

HMI devices

Industrial Flat Panels V2 Hygienic

Compact Operating Instructions

07/2024

A5E52905290-AB

Preface

Overview

Safety instructions

Installing and connecting

the device

Commissioning and

advanced functions

Maintenance and repairs

Technical specifications

Technical Support

List of abbreviations

Table of Contents

Need help?

Do you have a question about the SIMATIC IFP1200 V2 ext. Hygienic and is the answer not in the manual?

Questions and answers

Summary of Contents for Siemens SIMATIC IFP1200 V2 ext. Hygienic

Page 1 Industrial Flat Panels V2 Hygienic Preface Overview SIMATIC HMI Safety instructions Installing and connecting the device HMI devices Industrial Flat Panels V2 Hygienic Commissioning and advanced functions Maintenance and repairs Compact Operating Instructions Technical specifications Technical Support List of abbreviations 07/2024 A5E52905290-AB...
Page 2: Legal Information
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
Page 3: Preface
These compact operating instructions apply to the following hygienic HMI devices based on the following Industrial Flat Panels V2: Hygienic HMI device, Type Based on Industrial Flat Panel V2, article number article number SIMATIC IFP1200 V2 ext. Hygienic Siemens SIMATIC IFP1200 V2 extended, 6AV7285-6NH00-0AA0 6AV7863-1MA10-2AA0 SIMATIC IFP1200 V2 ext. Hygienic Neutral 6AV7285-6NH00-0AB0 SIMATIC IFP1500 V2 ext.
Page 4 1. After you receive your product, download the relevant documentation, at a time no later than the first assembly/commissioning. Use the following options for the download: – Technical Support (https://support.industry.siemens.com): The documentation is assigned to the product via the article number. The article number can be found on the product and on the packaging label.
Page 5: Naming Conventions
Instead of the full product name, the short product name without the prefix "SIMATIC" and the suffix "V2 ext. Hygienic" is also used, for example: "IFP1200" in place of "SIMATIC IFP1200 V2 ext. Hygienic". Figures This manual contains figures for the described devices. The figures can deviate from the particularities of the delivered device.
Page 6: Table Of Contents
Table of contents Preface ..............................3 Overview ............................... 8 Product description ......................8 Scope of delivery ......................... 9 Layout of the devices ......................10 Interfaces .......................... 11 Accessories ........................11 Safety instructions ..........................12 Intended use ........................12 General safety instructions ....................12 Notes about usage ......................
Page 7 Operating Conditions ......................53 Information on insulation tests, protection class and degree of protection ......53 Dimension drawings ......................55 6.6.1 SIMATIC IFP1200 V2 ext. Hygienic ..................55 6.6.2 SIMATIC IFP1500 V2 ext. Hygienic ..................56 6.6.3 SIMATIC IFP1900 V2 ext. Hygienic ..................57 6.6.4...
Page 8: Overview
Overview Product description The Industrial Flat Panels V2 hygienic devices offer a robust front for use in the food and beverage industry as well as in the pharmaceutical industry. Features • Rugged front panel with stainless steel frame, anti-shatter film and minimized grooves and gaps in compliance with Hygienic Design Guideline DIN EN 1672-2 •...
Page 9: Scope Of Delivery
Overview 1.2 Scope of delivery Scope of delivery The scope of delivery of the HMI device includes the following components: Designation Figure Quantity HMI device Mounting instructions Power supply connector Strain relief plate with 3 screws T10, M3x8 Mounting gasket Clamping frame Mounting clips, stainless 14 (+2)
Page 10: Layout Of The Devices
Overview 1.3 Layout of the devices Layout of the devices This section describes the design of the HMI devices, using the SIMATIC IFP1500 V2 ext. Hygienic as an example. Front view and side view ① Front panel consisting of: • Stainless steel frame •...
Page 11: Interfaces
Mall under the respective article numbers. You can find an overview of the status and compatibility of the accessories portfolio in the "Cross-list" on the Internet (https://support.industry.siemens.com/cs/ww/en/view/40466415). Service packs The following service packs with clamping frame, mounting gasket and mounting clips are...
Page 12: Safety Instructions
Safety instructions Intended use The SIMATIC HMI hygienic HMI devices are designed for high-performance visualization tasks (operator control and monitoring) and ambient conditions such as those found in the food & beverage and pharmaceutical industries. The devices are generally designed for use near open processes (according to DIN EN 1672-2) and are intended primarily for use in splash zones.
Page 13 In order to protect plants, systems, machines, and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks.
Page 14: Notes About Usage
Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to...
Page 15 Safety instructions 2.3 Notes about usage Note The device is intended for operation in an SELV/PELV circuit according to IEC/EN 61131 or IEC/EN 61010-2-201 in a dry environment, which means a dry environment on the rear of the device. Additional information is available in the section "Operating Conditions (Page 53)". Industrial applications The HMI device is designed for industrial applications.
Page 16 Safety instructions 2.3 Notes about usage Reducing vibrations If the device is subjected to greater shocks or vibrations, you must take appropriate measures to reduce acceleration or amplitude. Risk analysis and measures WARNING Hazards emanating from unprotected machines or plants The results of a risk analysis can reveal any hazards emanating from unprotected machinery.
Page 17 Safety instructions 2.3 Notes about usage TFT displays NOTICE Burn-in effect A permanently displayed two-color or multi-color picture can cause a burn-in effect, i.e. the picture remains dimly visible for a certain period of time. The longer the image is burned in, the longer the image will last.
Page 18: Use In Hazardous Areas
Safety instructions 2.4 Use in hazardous areas Use in hazardous areas The following warnings apply to operating a device with Ex approval in hazardous areas. WARNING Explosion Hazard Do not disconnect while circuit is live unless area is known to be non-hazardous. Substitution of components may impair suitability for Class I, Division 2 or Zone 2.
Page 19: Important Notes On Touch Screen
(short connection, minimum conductor cross-section 4 mm Additional information on connecting the grounding cable can be found in the "Equipotential bonding" section of the "Industrial Flat Panels V2 (https://support.industry.siemens.com/cs/ww/en/view/109767495)" operating instructions. Industrial Flat Panels V2 Hygienic Compact Operating Instructions, 07/2024, A5E52905290-AB...
Page 20 Safety instructions 2.5 Important notes on touch screen WARNING Personal injury or property damage due to maloperation Incorrect operation of touch devices cannot be ruled out. This can result in personal injury or property damage. Take the following precautions: • Configure the plant so that safety-related functions are not operated with the touch screen.
Page 21: Notes On Operation
Safety instructions 2.5 Important notes on touch screen Notes on operation Note Do not touch the capacitive multi-touch screen during startup The HMI device automatically calibrates the capacitive multi-touch screen during startup. The touch screen is locked during calibration. Do not touch the touch screen during startup. Make sure that you do not rest on the touch screen with the palm of your hand during startup.
Page 22 Safety instructions 2.5 Important notes on touch screen Security functions in an industrial environment The capacitive multi-touch screen is locked for security reasons when the following disturbances occur: • There is a conductive liquid on the touch screen with ground contact via the enclosure or the operator, for example.
Page 23: Installing And Connecting The Device
Installing and connecting the device Preparing for installation 3.1.1 Checking the delivery package Procedure 1. When accepting a delivery, please check the packaging for visible transport damage. 2. If any transport damage is present at the time of delivery, lodge a complaint at the shipping company in charge.
Page 24 Installing and connecting the device 3.1 Preparing for installation 6. Please inform the delivery service immediately if the package contents are incomplete or damaged or do not correspond with your order. Fax the enclosed form "SIMATIC IPC/PG Quality Control Report". WARNING Electric shock and fire hazard due to damaged device A damaged device can be under hazardous voltage and trigger a fire in the machine or...
Page 25: Checking The Operating Conditions
Installing and connecting the device 3.1 Preparing for installation 3.1.2 Checking the operating conditions Note the following aspects before installing the device: 1. Familiarize yourself with the standards, approvals, EMC parameters and technical specifications for operation of the device. This information is available in the following chapters: –...
Page 26: Mounting Position
Installing and connecting the device 3.1 Preparing for installation Mounting position Choose one of the following permissible mounting positions for your HMI device. The permitted mounting positions and the associated operating temperatures are described in the following sections using the IFP1500 as an example. Mounting in landscape format All hygienic HMI devices are suitable for mounting in landscape format.
Page 27: Checking Clearances
Installing and connecting the device 3.1 Preparing for installation 3.1.4 Checking clearances The following clearances are required around the HMI device to ensure sufficient self- ventilation: • At least 15 mm to both the right and left of the mounting cutout (in x direction) to allow for insertion of the mounting clips during installation •...
Page 28: Preparing The Mounting Cutout
Installing and connecting the device 3.1 Preparing for installation 3.1.5 Preparing the mounting cutout Note Stability of the mounting cutout The material in the area of the mounting cutout must provide sufficient strength to guarantee lasting and safe mounting of the HMI device. To achieve the degrees of protection described below, it must be ensured that deformation of the material cannot occur due to the force of the mounting clips or operation of the device.
Page 29: Mounting The Device
Installing and connecting the device 3.2 Mounting the device Dimensions of the mounting cutout Width and height should be reversed accordingly when mounting in portrait format. Mounting the device 3.2.1 Notes on installation Before installing the device, please ensure that the installation location complies with the following: NOTICE Use according to IEC 61010-2-201 requires an appropriate enclosure...
Page 30: Positions Of The Mounting Clips
To achieve degree of protection IP69 for the respective device, the mounting clips must be fitted at the positions shown below. Device Positions of the mounting clips SIMATIC IFP1200 V2 ext. Hygienic Two short set screws are included in the scope of delivery. These are required if the material thickness at the installation cutout is >2.5 mm.
Page 31: Inserting The Mounting Seal
Installing and connecting the device 3.2 Mounting the device Device Positions of the mounting clips SIMATIC IFP2200 V2 ext. Hygienic 3.2.3 Inserting the mounting seal Note Use a new mounting gasket for each installation, because the promised degree of protection cannot be guaranteed otherwise.
Page 32: Mounting The Device With Clamping Frame And Mounting Clips
Installing and connecting the device 3.2 Mounting the device 4. Starting from the corner, successively attach all the remaining nubs into their holes. Note Devices with display diagonals 15" and higher Devices with display diagonals ≥15" have holes at the corners and elongated holes in the middle edge area.
Page 33 Installing and connecting the device 3.2 Mounting the device Procedure CAUTION Risk of injury when device falls An unsecured device may fall. This can result in damage to persons, machines and the device. Secure the device against dropping during the entire installation. If necessary, work in pairs when installing the device.
Page 34: Mounting The Strain Relief Plate
Mount the strain relief plate included in the scope of delivery in the same way as described in the "Industrial Flat Panels V2 (https://support.industry.siemens.com/cs/ww/en/view/109767495)" operating instructions. Connecting the device The specifications for the Extended variants in the "Industrial Flat Panels V2 (https://support.industry.siemens.com/cs/ww/en/view/109767495)"...
Page 35: Removing The Device
Installing and connecting the device 3.5 Removing the device The following figure shows an example of how to secure a USB connector in a captive manner. Removing the device The HMI device is generally removed in the reverse order used for installing and connecting. Procedure Proceed as follows: 1.
Page 36: Commissioning And Advanced Functions
1. Switch on the PC. 2. Switch on the power supply of the HMI device. 3. Download the SIMATIC IPC Panel Drivers and Tools software from the Internet (https://support.industry.siemens.com/cs/ww/en/view/109792891). 4. Run "start.exe". Extended functions If you have installed the SIMATIC IPC Panel Drivers and Tools software, then the following functions are available, for example: •...
Page 37: Maintenance And Repairs
Maintenance and repairs General information on maintenance and servicing Observe the following when servicing and repairing protective equipment such as ground circuits or overvoltage protection components: • Observe the maintenance and replacement intervals specified by the manufacturer. • Replace plant components, including external cables, fuses and batteries only with equivalent components approved by the respective manufacturer.
Page 38: Cleaning And Caring For The Device
Maintenance and repairs 5.2 Cleaning and caring for the device Cleaning and caring for the device The HMI device is designed for low-maintenance operation. If the HMI device is installed properly, it is typically only necessary to clean the glass front of the HMI device.
Page 39 Maintenance and repairs 5.2 Cleaning and caring for the device NOTICE Permissible and non-permissible cleaning agents and cleaning tools Impermissible and unsuitable cleaning agents and cleaning tools can damage the HMI device. Not permitted: • Do not clean the HMI device using aggressive solvents, cleaning agents or disinfectants, greasing or abrasive detergents, concentrated acids or caustic solutions.
Page 40: Cleaning The Device Front
Maintenance and repairs 5.2 Cleaning and caring for the device 5.2.2 Cleaning the device front Cleaning interval We recommend cleaning the HMI device at regular intervals, depending on the cleanliness requirements of the user: • After no more than 8 hours of continuous use, but no later than when the device becomes visibly dirty.
Page 41: Working With Pressure Washers
Maintenance and repairs 5.2 Cleaning and caring for the device 5.2.3 Working with pressure washers The HMI device can be used on machines that are cleaned with high pressure. NOTICE Damage caused by steam cleaners Hot steam can damage the HMI device. Do not clean the HMI device with steam cleaners. Risk of contamination by high-pressure cleaner When high-pressure cleaners are used, areas that have already been cleaned can be contaminated again:...
Page 42: Working With Stainless Steel Surfaces
Maintenance and repairs 5.2 Cleaning and caring for the device We recommend the following temperature settings for the high-pressure cleaner: • For light soiling: 30 - 50 °C • For protein-containing soiling: Maximum 60 °C The HMI device may be damaged if the pressure is too high or is concentrated at a single point.
Page 43: Chemical Resistance
Maintenance and repairs 5.2 Cleaning and caring for the device 5.2.5 Chemical Resistance ECOLAB test The front panel has been tested for resistance to the following chemicals. Cleaning agent Type Concentration Topactive 200 Alkaline foam cleaning agent (thin film cleaner) Topaz MD5 Alkaline foam cleaning agent Topax 66...
Page 44: Spare Parts And Repairs
• Clean the stainless steel surface with a cleansing agent without active chlorine. Spare parts and repairs Repairs Contact your Siemens representative (https://www.siemens.com/aspa). Filter by expertise, product and region. Your contact person will let you know if a product can be repaired and how to return it.
Page 45: Technical Specifications
EU Declarations of Conformity The EU Declarations of Conformity are available to the relevant authorities at the following address: Siemens Aktiengesellschaft Gleiwitzer Straße 555 DE-90475 Nürnberg You can also download these on the Internet using the keyword "Declaration of Conformity"...
Page 46 • Equipment and Protective Systems Intended for use in Potentially Explosive Atmospheres Regulations 2016 (Explosion Protection) UK Declarations of Conformity The UK Declarations of Conformity are available to the relevant authorities at the following address: Siemens plc Princess Road Manchester M20 2UR United Kingdom You can also download these on the Internet using the keyword "Declaration of Conformity"...
Page 47 Notes on use in hazardous areas Observe the following FAQ regarding the use of an HMI device in hazardous areas: FAQ 291285 (https://support.industry.siemens.com/cs/ww/en/view/291285) When using the device in hazardous areas, ensure that all plugs connected to the device are secured in a captive manner, see section "Securing cables for use in hazardous areas (Page 34)".
Page 48 Technical specifications 6.1 Labels, certificates and approvals CCCEx approval The following approvals according to the following standards are valid for a device with the "CCC" marking. • Standards: – GB/T 3836.1 (Explosive atmospheres - Part 1: Equipment - General requirements) –...
Page 49: Electromagnetic Compatibility
EMC-compliant mounting of the device and the use of interference-proof cables provide the basis for interference-free operation. Observe the following manuals in addition to these operating instructions: • Designing interference-free controllers (https://support.industry.siemens.com/cs/ww/en/view/59193566) • Industrial Ethernet/PROFINET – Passive network components (https://support.industry.siemens.com/cs/ww/en/view/84922825) Industrial Flat Panels V2 Hygienic...
Page 50 Technical specifications 6.2 Electromagnetic compatibility Pulse-shaped disturbance The following table shows the electromagnetic compatibility of the modules with regard to pulse-shaped interference. The precondition for electromagnetic compatibility is that the device meets the specifications and guidelines for electrical installation. Pulse-shaped interference Tested with Corresponds to Test level...
Page 51: Mechanical Ambient Conditions
Technical specifications 6.3 Mechanical ambient conditions Emission of radio interference The following table shows the interference emission from electromagnetic fields according to EN 61000-6-4, measured at the following distance. Radiated emission (emitted interference) Frequency range Measuring distance Interference emission 30 MHz to 230 MHz 10 m <...
Page 52: Operating Conditions
Technical specifications 6.4 Climatic ambient conditions 6.3.2 Operating conditions The following information applies to a device installed according to the specifications in these operating instructions. The device was tested based on IEC 60721-3-3:2002 Class 3M3 with the following amendments and limitations: Type of condition Permitted range Vibration according to IEC 60068-2-6...
Page 53: Operating Conditions
Technical specifications 6.5 Information on insulation tests, protection class and degree of protection 6.4.3 Operating Conditions The following information applies to a device installed according to the specifications in these operating instructions. The HMI device is intended for weatherproof and stationary operation according to IEC 60721-3-3.
Page 54 Technical specifications 6.5 Information on insulation tests, protection class and degree of protection Protection against foreign objects and water The device meets the following requirements according to the following standards. Characteristic Standard Classification Protection class EN 61131-2 Protection class III Degree of protection on the •...
Page 55: Dimension Drawings
6.6 Dimension drawings Dimension drawings 6.6.1 SIMATIC IFP1200 V2 ext. Hygienic The following dimension drawings show the HMI device with mounting clips and clamping frame. The figure at the bottom contains the correct positions of the mounting clips. Industrial Flat Panels V2 Hygienic...
Page 56: Simatic Ifp1500 V2 Ext. Hygienic
Technical specifications 6.6 Dimension drawings 6.6.2 SIMATIC IFP1500 V2 ext. Hygienic The following dimension drawings show the HMI device with mounting clips and clamping frame. The figure at the bottom contains the correct positions of the mounting clips. Industrial Flat Panels V2 Hygienic Compact Operating Instructions, 07/2024, A5E52905290-AB...
Page 57: Simatic Ifp1900 V2 Ext. Hygienic
Technical specifications 6.6 Dimension drawings 6.6.3 SIMATIC IFP1900 V2 ext. Hygienic The following dimension drawings show the HMI device with mounting clips and clamping frame. The figure at the bottom contains the correct positions of the mounting clips. Industrial Flat Panels V2 Hygienic Compact Operating Instructions, 07/2024, A5E52905290-AB...
Page 58: Simatic Ifp2200 V2 Ext. Hygienic
Technical specifications 6.6 Dimension drawings 6.6.4 SIMATIC IFP2200 V2 ext. Hygienic The following dimension drawings show the HMI device with mounting clips and clamping frame. The figure at the bottom contains the correct positions of the mounting clips. Industrial Flat Panels V2 Hygienic Compact Operating Instructions, 07/2024, A5E52905290-AB...
Page 59: Technical Specifications
Technical specifications 6.7 Technical specifications Technical specifications Material The following material specifications apply to all hygienic HMI devices. Component Material Front frame Stainless steel 4301-304-00-I (X5CrNi18-10/ 1.4301/ V2A) according to ISO 15510 Front display glass Float glass, chemically toughened Anti-shatter film Transparent plastic film, prevents escape of glass fragments Mounting gasket Silicone, 70 Shore-A, blue...
Page 60: Dc Power Supply
Technical specifications 6.7 Technical specifications Interfaces Hygienic HMI device 12" 15" 19" 22" DisplayPort Yes, DisplayPort V1.2 USB Type A Yes, USB hub USB Type B, host Ext-Link USB Type A, maximum load 500 mA, equivalent to USB standard 2.0 Proprietary interface for internal communication DC power supply Hygienic HMI device...
Page 61: Technical Support
Internet at the following link: After Sales Information System SIMATIC IPC/PG (https://www.siemens.com/asis) Information about the manufacturer Siemens AG is the manufacturer of the HMI devices described in this document. The manufacturer address is: Siemens Aktiengesellschaft...
Page 62: List Of Abbreviations
List of abbreviations Abbreviations Direct Current Components and modules endangered by electrostatic discharge Electromagnetic Compatibility European standard Food and Drug Administration Ground High Frequency International Electronic Commission Ingress protection Light Emitting Diode Thin Film Transistor Underwriter’s Laboratory Universal Serial Bus Industrial Flat Panels V2 Hygienic Compact Operating Instructions, 07/2024, A5E52905290-AB...
