C5 8 SERIES CABINETS — INSTRUCTIONS FOR USE
INSTALLATION AND SET-UP
The rack uprights
have been installed
at the factory. If
removed for cleaning,
reinstall by hanging
them on the shoulder
rivets on the side
walls of the cabinet.
TOP VIEW
SLIDE POSITION to MAXIMIZE
3" PAN CAPACITY OF UNIVERSAL SLIDES
Full Height
Single Door
18 Levels
(Position 2
nd
from Bottom)
Part No. RPC5-U9
(includes slides and uprights) (includes slides and uprights) (includes slides and uprights) (includes slides and uprights) (includes slides and uprights)
Slides sold in pairs. For additional pair of wire slides, order C5-USLIDEPR-C for Chrome or C5-USLIDEPR-S for Stainless Steel.
To order individual universal uprights only, see item #'s 29A, 29B, 29C.
(continued)
SLIDE INSTALLATION
29A
Full Height
Dutch Doors
17 Levels
14 Levels
(Position 2
(Position Bottom)
from Bottom)
Part No. RPC5-U9
Part No. RPC5-U7
*
RPC5-9-URT5
8 Required per
cabinet
*
29B
RPC5-9-URT7
4 Required per
cabinet
/
Height
/
Height
3
1
4
2
Cabinet
Cabinet
8 Levels
(Position 3
nd
from Bottom)
Part No. RPC5-U5
6
www.metro.com
*
29A
RPC5-9-URT5
4 Required per
cabinet
29C
RPC5-9-URT3
4 Required per
cabinet
Under Counter
Cabinet
5 Levels
rd
(Position Bottom)
Part No. RPC5-U3
SiteSelect
™
features
make slide
installation
easier.
*
L01-425
REV K 10/19
