User ManUal
This manual covers cabinets with electrical ratings
of: 120V 1650W & 220V 1650W.
Metro Heated Cabinets are for
Food Service applications only.
®
When ordering
electrical parts, always
confirm the rating
listed on data plate
located on the lower
left side of the unit.
Differences on voltage,
amps or wattage are
listed with bold text
in replacement part
descriptions.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metro DataVac MBQ-200D-QH
Summary of Contents for Metro DataVac MBQ-200D-QH
- Page 1 Metro ® Heated Banquet Cabinets User ManUal This manual covers cabinets with electrical ratings of: 120V 1650W & 220V 1650W. When ordering electrical parts, always confirm the rating listed on data plate located on the lower left side of the unit. Differences on voltage, amps or wattage are listed with bold text...
-
Page 2: Table Of Contents
Table of ConTenTs Section Page I. Introduction a. identifying Your cabinet ........2 B. Features ............3 II. Operating Instructions a. electric Heating System ........3 B. canned Fuel System ........3 c. count-up count-down timer clock ....4 III. Cleaning Instructions a. Shelf Removal installation ......4 B. electric Heating Module Removal installation ........4 c. Quad-Heat Dual Fuel Removal installation ........ -
Page 3: Introduction
I. InTRoDUCTIon sample of CabIneT labelIng A. IDENTIFYING YOUR CABINET mbQX-200D-QH there are two numbers, which you may want cabinet Series to record for future reference: the cabinet model number, serial number, and the module cabinet elect. serial number. Refer to the photo below to Rating type locate these numbers. it is recommended that blank = 20V, 650W all numbers be recorded in an appropriate X = 220V, 60HZ, 650W place, such as on this page (see below). also, please record the cabinet model number and cabinet Size module serial number on the Warranty card found at the back of this manual. Be sure to Double Door complete the remainder of the Warranty card (Blank for Single Door) and return it to Metro within fifteen (5) days of delivery of the cabinet. once you have Quad-Heat located and recorded these numbers, refer (Dual Fuel) to the sample numbers given to the right to identify the components of your cabinet. Location oF MoDuLe SeRiaL nuMBeR Location oF caBinet MoDeL nuMBeR anD SeRiaL nuMBeR (Silver Label on Side of cabinet) Model number ________________________________ Serial number ________________________________... -
Page 4: Features
B. FEATURES — ALL MODELS 120V 120V 220V 15 AMP PLUG 20 AMP PLUG 15 AMP PLUG In order to utilize your new cabinet to its full potential; take a minute to identify the following features that have been provided for your convenience. •... -
Page 5: Count-Up/Count-Down Timer/Clock
III. CleanIng InsTRUCTIons C. COUNT-UP/COUNT-DOWN TIMER/CLOCK CLOCK MODE CAUTION . Press the Mode button until the clock icon AT NO TIME SHOULD THE MODULE OR appears on screen next to the printed CABINET BE WASHED OR FLOODED WITH “cLocK” icon. WATER OR LIQUID SOLUTION. NEVER 2. Press and hold (Set) for two seconds. STEAM CLEAN. SEVERE DAMAGE OR ELECTRICAL HAZARD COULD RESULT. 3. “HouRS” will flash. . turn off power switch. 4. Press ( ▲ ) or ( ▼ ) to set. 2. unplug the unit from its power source. 5. Repeat process to set minutes or seconds. 6. to complete the process press (Set). WARNING NOTE: the two-second delay is to prevent ALLOW THE UNIT TO COOL BEFORE accidental changing of time. there is no CLEANING, AS THE INTERIOR OF THE delay in timer mode. CABINET MAY BE HOT ENOUGH TO BURN. COUNT-DOWN TIMER MODE A. SHELF REMOVAL/INSTALLATION can be used to countdown the minutes until the to remove the shelves, all shelves must first canned fuel needs to be replenished. be lowered onto the bottom shelf. Start with the shelf above the bottom shelf by lifting it off . Press the Mode button until the timer icon of the shelf hangers and by lowering the front appears on the screen next to the printed “tiMeR” icon. edge and raising the rear edge so that it can be lowered onto the bottom shelf. Repeat the 2. Press (Set). -
Page 6: Quad-Heat Dual Fuel
on the floor of the cabinet. the control panel 3. the cabinet or component(s) must be will be facing the ceiling. unplug the module thoroughly rinsed to remove any residue that power supply cord from the cabinet supply may stain the materials. cord and remove the module from the cabinet. E. GENERAL CLEANING INSTRUCTIONS 2. Do not use abrasive cleaners. For every . LigHt SoiL cleaning method, best results are always if routine (daily) cleaning is practiced, a mild obtained when the cleaner and technique soap and warm water should be sufficient to are matched to the soil conditions involved. keep the unit clean. contact your detergent representative to 2. HeaVieR SoiL ensure the cleaning product being used is if cleaning has been postponed, solvent or recommended for use on stainless steel. emulsion type cleaners that can be applied Follow the manufacturer’s directions on with bare hands will give excellent results. cleaners. Never mix cleaners. Such cleaners are available under various CAUTION brand names. Detergent suppliers can recommend materials appropriate for use on DO NOT ALLOW THE CABINET POWER stainless steel. SUPPLY CORD RECEPTACLE TO COME IN CONTACT WITH WATER OR CLEANSERS. NOTE: For every cleaning method, best IT MUST BE DRY BEFORE PLUGGING THE results are always obtained when the cleaner MODULE POWER SUPPLY CORD INTO IT. and techniques are matched to the soil C. QUAD-HEAT DUAL FUEL SYSTEM conditions involved. to ensure using the REMOVAL/INSTALLATION proper cleaner for stainless steel, contact... -
Page 7: Replacement Parts And Procedures
V. ReplaCemenT paRTs anD ReplaCemenT lIsT A. CABINET — ALL MODELS Refer to the cabinet Replacement Parts List on page 7 to identify the replacement parts. Cabinet Replacement Parts Diagram... - Page 8 cabinet Replacement paRts list item no. part no. Description 1 RPC14-042 HINGE 2 RPSEFS-200RDOR RIGHT DOOR MBQ-200D UNITS ONLY RPSEFS-180RDOR RIGHT DOOR MBQ-180D, MBQ-180, MBQ-144 UNITS ONLY RPSEFS-150RDOR RIGHT DOOR MBQ-150D, MBQ-120, MBQ-90 UNITS ONLY RPSEFS-120RDOR RIGHT DOOR MBQ-120D & MBQ-2 UNITS ONLY 3 RPC14-118A LATCH 4 RPSEFS-200LDOR LEFT DOOR MBQ-200D UNITS ONLY RPSEFS-180LDOR LEFT DOOR MBQ-180D UNITS ONLY RPSEFS-150LDOR LEFT DOOR MBQ-150D UNITS ONLY ...
-
Page 9: Electric Heating Module
B. ELECTRIC HEATING MODULE CAUTION CAUTION IF NECESSARY TO RECONNECT POWER WHILE SERVICING, PRACTICE ExTREME DO NOT ATTEMPT TO SERVICE THE CAUTION SO AS NOT TO RECEIVE AN MODULE UNLESS YOU ARE QUALIFIED ELECTRICAL SHOCK FROM ExPOSED AND KNOWLEDGEABLE OF ELECTRICAL COMPONENTS. REPAIRS AND ELECTRICAL SAFETY. d. to replace the thermostat, switch or indicator Your module has been designed to be user- light, remove the four screws that hold the serviceable, assuming a basic knowledge control panel to the main body of the module to of the operation of electrical devices. this gain access to the part needing replacement. section has been written to guide the user step it will also be necessary to remove the cover by step, and in layman’s terms, through the from the top of the module to gain access to dismantling and servicing of the module. Before the terminal block. See diagram on page 9. attempting to service your module, read the appropriate Module Repair Procedures (found e. to replace the element or blower it is only elsewhere in this section) thoroughly. if you do necessary to remove the (4) screws around not understand the Repair Procedures or prefer the perimeter of the module top and remove not to service your module yourself, or if your the cover (carefully laying it to the side of the warranty is still in effect, please contact our module to prevent damage to the thermostat customer Service Department for the factory capillary tube which is attached to the authorized service agency nearest you. See module top). back cover for contact information. -
Page 10: Swivel-Lock Operation
D. SWIVEL-LOCK CASTER SYSTEM OPERATION the casters that are controlled by the swivel- lock mechanism are normally locked in the rigid or “travel” position. Stepping on the swivel-lock release loop allows the casters at that end of the cabinet to rotate out of the rigid position when the cabinet is moved in tight spaces or around sharp corners, without dragging. NOTE: You must Press down on the swivel-lock release loop until the casters are out of the rigid position. When you remove your foot from the swivel- lock release loop the casters will continue to be free to swivel until the cabinet is pulled for a distance from the opposite side and the casters swivel back into the rigid or “travel” position. - Page 11 Heat Module — BQ1700 and BQ1700X Confirm the electrical rating of the cabinet before ordering components. ReplaCeMent paRts list item no. part no. Description RP15A-MODCORD 22" MODULE CORD, 120V, 15 AMP RP20A-MODCORD 22" MODULE CORD, 120V, 20 AMP RP220-MDLCRD 22" MODULE CORD, 220V, 15 AMP RPC13-166 HEAT ELEMENT, 120V 1650W RPC13-167 HEAT ELEMENT, 220V 1650W RPHM20-2103 BLOWER, 120V RPHX20-2103 BLOWER, 220V RPC13-129 THERMOSTAT RPC06-313 CONTROL KNOB RPC13-245...
- Page 12 E. SWIVEL-LOCK CASTER SYSTEM REPLACEMENT PARTS DIAGRAM REPLACEMENT PARTS LIST Item No. Part No. Description RPSL-DDWeLD DouBLe DooR caBinet SWiVeL-LocK ReLeaSe RPSL-SDWeLD SingLe DooR caBinet SWiVeL-LocK ReLeaSe 2 RPSL-Retain ReLeaSe RetaineR BRacKet 3 RPSL6-caSteR 6" SWiVeL-LocK caSteR RPSL8-caSteR 8" SWiVeL-LocK caSteR 4 RPc02-97 6" SWiVeL caSteR RPc02-200 8" SWiVeL caSteR 5 RPSL-LocKtaB SWiVeL-LocK taB anD HaRDWaRe...
- Page 13 F. QUAD-HEAT REPLACEMENT PARTS DIAGRAM REPLACEMENT PARTS LIST CABINET MODEL # Item No. Description MBQ-200D-QH MBQ-180D-QH MBQ-150D-QH MBQ-120D-QH cHiMneY HangeR RPQH-Hang RPQH-Hang RPQH-Hang RPQH-Hang 2 cHiMneY RPQH-200cHiM RPQH-80cHiM RPQH-50cHiM RPQH-20cHiM 3 canneD FueL DRaWeR RPQH-DRaWeR RPQH-DRaWeR RPQH-DRaWeR RPQH-DRaWeR 4 FLue RPQH-DDFLue RPQH-DDFLue RPQH-DDFLue RPQH-DDFLue CABINET MODEL # Item No. Description MBQ-180-QH...
-
Page 14: Wiring Schematic
VI. WIRIng sCHemaTICs BQ1700 MODULE WIRING DIAGRAM 22" POWER SUPPLY CORD BLACK WHITE TERMINAL BLOCK STRAIN RELIEF GREEN GROUND SCREW (GREEN COLOR) POWER SWITCH BLOWER INDICATOR LIGHT ELEMENT HEAT THERMOSTAT THERMOMETER BULB... - Page 15 InterMetro Industries Corporation (hereinafter referred to as “S elle r” ) warrants to the ®...
-
Page 16: Warranty
Thank you for purchasing a Metro Heated Banquet Cabinet. We are certain you will be more than satisfied with its quality and performance. Please fill in the warranty information space below so we may register your warranty. Also, so that we may learn more about our customers and hopefully be of continued service in the future, please take a moment to fill in the customer information space below. Thank You CUT ALONG DOTTED LINE WARRANTY INFORMATION: CUSTOMER INFORMATION 1. Which one of the following best describes Cabinet Model No. your establishment? Module Serial No. ❑ Full-Service Restaurant Date Purchased ❑ Banquet Hall Customer Name ❑ Hotel Motel Address ❑ Hospital Nursing Home ❑ College University ❑ School Phone No. ❑ Employee Feeding ❑ Other For warranty coverage, this card must be returned to Metro. - Page 17 STAPLE HERE...
- Page 18 L01-399 InterMetro Industries Corporation Rev. C 2 North Washington Street, Wilkes-Barre, PA 18705 Information and specifications are subject to change without notice. Please confirm at time of order. For Product Information Call: 1-800-433-2232 Visit Our Web Site: www.metro.com...
