InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA 18705
For Product Information Call: 1-800-992-1776,
Visit Our Web Site: www.metro.com
Metro
®
Heated
Banquet
Cabinets
TOP-MOUNTED MODULE
INSTRUCTIONS FOR USE
This manual covers cabinets with
electrical ratings of: 120V 1650W &
220V 1650W
When ordering electrical parts,
always confirm the rating listed
on data plate located on the lower
left side of the unit. Differences on
voltage, amps or wattage are listed
with bold text in replacement part
descriptions.
Metro Heated Cabinets are for
Food Service applications only.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metro DataVac MBQLT-200D-QH
Summary of Contents for Metro DataVac MBQLT-200D-QH
- Page 1 Metro ® Heated Banquet Cabinets TOP-MOUNTED MODULE INSTRUCTIONS FOR USE This manual covers cabinets with electrical ratings of: 120V 1650W & 220V 1650W When ordering electrical parts, always confirm the rating listed on data plate located on the lower left side of the unit. Differences on voltage, amps or wattage are listed with bold text in replacement part descriptions.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Introduction A. Identifying Your Cabinet ..........2 Features ................. 3 Operating Instructions A. Electric Heating System ..........3 Canned Fuel System ............3 C. Timer ..................3 III. Cleaning Instructions A. Shelf Removal Installation ........... 4 Electric Heating Module Removal Installation ............ -
Page 3: Identifying Your Cabinet
INTRODUCTION SAMPLE OF CABINET LABELING A. IDENTIFYING YOUR CABINET MBQT-180D-QHA There are two numbers, which you may want Cabinet Series to record for future reference: the cabinet model number, serial number, and the module Top-Mounted serial number. Refer to the photo below to Module locate these numbers. -
Page 4: Features
B. FEATURES — ALL MODELS THIS IS A HOT FOOD HOLDING CABINET AND IS NOT INTENDED TO In order to utilize your new cabinet to its full potential; take a minute to identify the following features that have SURE FOOD AND CABINETS ARE AT been provided for your convenience. -
Page 5: Cleaning Instructions
III. CLEANING INSTRUCTIONS C. QUAD-HEAT DUAL FUEL SYSTEM REMOVAL/INSTALLATION CAUTION 1. The heat conductive baffles spread the heat AT NO TIME SHOULD THE MODULE OR from the canned fuel drawers to the corner CABINET BE WASHED OR FLOODED WITH chimneys. The heat baffles are next to the WATER OR LIQUID SOLUTION. -
Page 6: Maintenance
NOTE: For every cleaning method, best results are always obtained when the cleaner and techniques are matched to the soil conditions involved. To ensure using the proper cleaner for stainless steel, contact your detergent representative. IV. MAINTENANCE A. CABINET MAINTENANCE Your cabinet has been designed to require very little maintenance. -
Page 7: Replacement Parts And Procedures
REPLACEMENT PARTS AND REPLACEMENT LIST A. CABINET — ALL MODELS Refer to the Cabinet Replacement Parts List on page 7 to identify the replacement parts. Cabinet Replacement Parts Diagram... - Page 8 CABINET REPLACEMENT PARTS LIST Item No. Part No. Description RPC14-042 HINGE RPSEFS-200RDOR RIGHT DOOR, MBQL-200D, MBQLT-200D, MBQT-200D RPSEFS-180RDOR RIGHT DOOR, MBQL-180D, MBQLT-180D, MBQT-180D RPSEFS-150RDOR RIGHT DOOR, MBQL-150D, MBQLT-120D, MBQT-150D RPSEFS-120RDOR RIGHT DOOR, MBQL-120D, MBQLT-120D, MBQT-120D RPC14-118A LATCH RPSEFS-200LDOR LEFT DOOR, MBQL-200D, MBQLT-200D, MBQT-200D RPSEFS-180LDOR LEFT DOOR, MBQL-180D, MBQLT-180D, MBQT-180D RPSEFS-150LDOR...
-
Page 9: Electric Heating Module
B. ELECTRIC HEATING MODULE e. To replace the blower or heating element, remove the (4) screws securing the blower CAUTION cover the module cover. Then, remove the (8) DO NOT ATTEMPT TO SERVICE THE screws holding module cover to the module MODULE UNLESS YOU ARE QUALIFIED chassis. - Page 10 Top-Mounted Heating Module — TBQ1700 BLOWER MODULE COVER COVER AIR DUCT COVER MODULE CHASSIS CONTROL PANEL I NTO STRI PS REPLACEMENT PARTS LIST Item No. Part No. Description RPC13-108 POWER CORD RPC13-110 STRAIN RELIEF RPC13-127 POWER SWITCH RPC13-129 THERMOSTAT RPC13-064 RED INDICATOR LIGHT RPHM20-2103 BLOWER...
-
Page 11: Quad-Heat System
D. QUAD-HEAT REPLACEMENT PARTS DIAGRAM REPLACEMENT PARTS LIST CABINET MODEL # Item Description MBQLT-200D-QH MBQLT-180D-QH MBQLT-150D-QH MBQLT-120D-QH CHIMNEY HANGER RPQH-HANG RPQH-HANG RPQH-HANG RPQH-HANG CHIMNEY RPQH-200CHIM RPQH-200CHIM RPQH-200CHIM RPQH-200CHIM CANNED FUEL DRAWER RPQH-DRAWER RPQH-DRAWER RPQH-DRAWER RPQH-DRAWER FLUE RPQH-XLFLUE RPQH-XLFLUE RPQH-XLFLUE RPQH-XLDFLUE... -
Page 12: Wiring Schematic
WIRING SCHEMATICS TBQ1700 MODULE WIRING DIAGRAM... - Page 13 InterMetro Industries Corporation (hereinafter referred to as “Seller”) warrants to the 02/16...
-
Page 15: Warranty
Thank you for purchasing a Metro Heated Banquet Cabinet. We are certain you will be more than satisfied with its quality and performance. Please fill in the warranty information space below so we may register your warranty. Also, so that we may learn more about our customers and hopefully be of continued service in the future, please take a moment to fill in the customer information space below. - Page 16 STAPLE HERE InterMetro Industries Corporation L01-417 Rev. D 02 North Washington Street, Wilkes-Barre, PA USA 18 705 Information and specifications are subject to change For Product Information Call: 1-800-992-1776 without notice. Please confirm at time of order. Visit Our Web Site: www.metro.com...
