88
C
8: T
HAPTER
ROUBLESHOOTING AND
Table 8 Symptoms, Causes, and Solutions
Symptom
Sending SMTP mail is slow.
Although multiple service
providers are configured, all
calls are going to the same
service provider which is a
private network
The Windows 95 "Connect
To" window opens upon
launching a Web browser.
ALERT LED remains lit
ALERT LED continues to flash
ALERT LED continues to fast
flash.
This may occur as a result of
replacing a workstation on the
LAN with a new computer.
When the handset of a
telephone attached to the 56K
LAN Modem is lifted, a dial
tone cannot be heard.
CD LED does not remain green. The user name and/or password
A connection has been
established (CD LED remains lit)
but data cannot be sent.
(continued)
M
AINTENANCE
Possible Cause
Only one workstation to one
server is supported at one time
for SMTP mail.
You may not have configured the
IP address and the subnet mask
in the Private Network
Parameters window.
Dial-Up Networking is setup for
use with a serial port modem.
An internal failure.
Self test failure or LAN Modem is
in firmware download mode
The DHCP server has issued all
of the available IP addresses, and
is unable to fulfill a request for a
new IP address.
The telephone line cable, power
cable and/or phone cable may
not be firmly connected.
Telephone cable may not be
inserted into the correct port.
A data call may be in progress.
for this service provider may not
be entered properly.
There is an interoperability
mismatch between the local and
remote applications.
Solution
If more than one workstation starts an SMTP mail
session to the same remote server at the same time,
the mail transfer rate for each additional workstation
will be slowed.
From the 56K LAN Modem's home page, click Service
Providers and then select the private network profile
you already configured. Enter the IP address and the
subnet mask for the private network.
To bypass the "Connect To" window:
1 Double-click the Internet control panel.
2 Click the Connection tab.
3 Check the "Connect to the Internet using a local
area network" radio button.
4 Click OK.
This allows all outgoing connections to run directly
through your LAN Modem.
Notify your reseller or technical support that the 56K
LAN Modem has failed the self-test.
Power cycle the LAN Modem. If the ALERT LED
continues to flash, the ISDN LAN Modem has failed the
self test. Contact your network supplier. If the ALERT
LED is not flashing, then the LAN Modem is now
operating correctly.
From another computer attached to the LAN Modem,
go to the LAN Modem's main configuration page.
Click Workstations. Select the name of computer you
removed and then click Select. Click Release
Workstation Entry. Reboot the workstation. The newly-
added workstation can now be assigned an IP address.
Check all cables and connectors to ensure that they are
inserted securely.
Ensure that the incoming analog telephone line has
been connected the port labeled "LINE" on the LAN
Modem's back panel.
Disconnect any data calls currently in progress.
Make sure that the user name and password for this
service provider are entered accurately on the Service
Provider page.
Make sure that the local and remote data applications
have communications capability and are properly
configured.
