Summary of Contents for Dynaudio ESOTAN X232
- Page 1 E S O T A N Owners Manual High-End Mobile Loudspeaker Systems...
- Page 4 In order for the sound to be tonally correct, dynamic and transparent, the drivers need to be mounted in an appropriate distance in relation to each other. For example, in a 2-way system the woofer and tweeter for each channel should be mounted in relative close proximity to one another,ideally as close to each other as physically possible.
- Page 5 135 mm max.43 mm 12.5 mm 12.5 mm 7.3 mm max.16.2 mm max.10 mm max.10 mm...
- Page 6 The Esotan systems include a crossover. See the following instructions to connect the crossover and loudspeakers. Recommendatory connection...
- Page 8 The Esotan systems include a crossover. See the following instructions to connect the crossover and loudspeakers. Recommendatory connection...
- Page 9 Connect terminal 3 to the + terminal of the power amplifier . Connect terminal 4 to the terminal of the power amplifier .
- Page 10 MF 171 62x41.2mm 62x41.2mm 101x59.2mm 172x77mm...
- Page 12 Dynaudio A/S,8660 Skanderborg,Denmark Sales&Marketing :1F,Red Tower North Creek Park . West Lize st.Wangjing.Chaoyang Dist.Beijing China . Tel:+86-010-84294566...
