Toa HY-RR2 Instruction Manual

REINFORCEMENT RING
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
1. SAFETY PRECAUTIONS
• Be sure to read the instructions in this section carefully before use.
• Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
• We also recommend you keep this instruction manual handy for future reference.
WARNING
• Leave the installation to your TOA dealer because the installation requires expert knowledge. Improper
installation may cause the speaker to fall, resulting in personal injury and/or property damage.
• Install the mounting hardware in a location that can structurally support the weight of the mounting hardware
and the speaker. Doing otherwise may result in the speaker falling down and causing personal injury and/or
property damage.
• Do not use other methods than specified to mount the unit. Incorrect mounting may cause the speaker to fall
off, possibly resulting in personal injuries.
• Tighten each screw securely. Ensure that the unit has no loose joints after installation to prevent accidents
that could result in personal injury.
• Use the specified speaker in combination. Doing otherwise may cause the speaker to fall off, resulting in
personal injury.
CAUTION
• Avoid touching the unit's sharp metal edge to prevent injury.
2. GENERAL DESCRIPTION
The HY-RR2 Reinforcement Ring is specially designed for use with the F-2352SC Ceiling Speaker System,
enabling the F-2352SC installation to a weak ceiling.
It also permits the F-2352SC to be installed to a wide range of locations in versatile mounting methods using
in conjunction with the HY-TB1 Tile Bar Bridge, HY-TR1 Trim Ring, or HY-AH1 Anchor Hanging Bracket.
3. SPECIFICATIONS
Mounting Hole Diameter
Finish
Dimensions
Weight
Usable Speaker
Note: The design and specifications are subject to change without notice for improvement.
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
7
ø200 mm (7 / ")
8
Surface-treated steel plate
ø260 mm (outer diameter) x 1.2 mm thick or
15
ø10 / " (outer diameter) x 3/64" thick
64
280 g
F-2352SC
INSTRUCTION MANUAL
HY-RR2
