- Page 1 SLS300 Lighting Stand Lighting Stand...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 02.08.2024, ID: 180075 (V3)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features................................9 Operation..............................10 Technical specifications........................20 Protecting the environment......................22 SLS300 Lighting Stand Lighting Stand... - Page 4 SLS300 Lighting Stand Lighting Stand...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in minor injury if it is not avoided.
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This light stand is intended to be used for the stable mounting and height-adjustable posi‐ tioning of spotlights. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 8 Safety instructions CAUTION! Risk of injury due to tipping of stand on an unsuitable ground! When the stand is installed on soft or uneven ground, the stand may tip over and cause injuries and property damage. Install the stand only on even and solid ground. CAUTION! Risk of injury due to tipping of the stand from excessive loading! In case of excessive loading, the stand might tip over, causing injury and property damage.
-
Page 9: Features
Features Features Special characteristics: Ideal for mobile discos and solo entertainers Quick and easy to assemble 3 m wide truss Can be extended up to a height of 2.65 m Maximum load capacity of the entire system: 25 kg Maximum load capacity per stand: 18 kg C hook (item no. -
Page 10: Operation
Operation Operation Unpack and check carefully there is no transportation damage before using the product. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 11 Operation CAUTION! Risk of injury due to tipping of the stand from excessive loading! In case of excessive loading, the stand might tip over, causing injury and property damage. Never exceed the specified maximum load for the stand. CAUTION! Risk of injury due to tipping of the stand from excessive or one-sided loading of the truss beam.
- Page 12 Operation Comply with regulations When installing and operating, make sure to follow the standards and regulations that apply in your country. SLS300 Lighting Stand Lighting Stand...
- Page 13 Operation Scope of delivery Before assembling the lighting stand, check that all the items on the following list have been delivered: Item Quantity Name Item Quantity Name Truss section T-piece with bolt T-piece without bolt Allen key Pipe without screw joint Stand Pipe with screw joint SLS300 Lighting Stand...
- Page 14 Operation Setup In principle, you can perform the following steps on your own. However, the work will be much easier with the assistance of a second person. Remove the rubber caps from the ends of the truss sections (A). Attach the two T-pieces (B) to the ends of tube (C). SLS300 Lighting Stand Lighting Stand...
- Page 15 Operation Connect the combination of (B) and (C) to the open side of one truss section (A). Then slide the tubes (D) through the T-pieces (B) into the truss section (A) and screw-connect the tubes (D). Attach the second truss section to the open end and screw-connect it. SLS300 Lighting Stand Lighting Stand...
- Page 16 Operation Attach the T-pieces (E) to the outer ends of the two truss sections (A). Secure the T-pieces (E) with the safety bolts. SLS300 Lighting Stand Lighting Stand...
- Page 17 Operation Unfold the feet of the stand (G) until the cross braces are in a horizontal position. Secure this position with the safety screw on the carriage to which the three feet are attached. Pull out the safety bolt and loosen the safety screw on the extension tube. Pull out the extension tube to the desired height, insert the safety bolt through the appropriate grid hole and slide the safety cotter through the hole in the safety bolt.
- Page 18 Operation Put the truss with the T-pieces onto the extension tube of the stands and attach the truss to the T-pieces (E) with the Allen screws. Attach the headlight or headlights to the truss, with adapters if necessary. Observe the instructions of the respective manufacturers.
- Page 19 Operation Disassembly Remove the spotlight(s). Loosen the Allen screws on the T-pieces (E) at the ends of the truss and pull the truss off the stands. To disassemble the truss, follow the assembly instructions in reverse order; only disas‐ semble it to the level you feel is required for transport or storage, as you will be setting it up again.
-
Page 20: Technical Specifications
Technical specifications Technical specifications Height, max. 2.65 m Total width of assembly 3.00 m Adjustable stand height 1.20 m … 2.65 m Æ 1.34 m Stand footprint Length of individual truss 2 × 1.50 m, optionally extensible to 4.50 m max. Stand tube diameter Æ... - Page 21 Technical specifications Further information Type Truss set Components Telescopic stand Including Truss beam Crank SLS300 Lighting Stand Lighting Stand...
-
Page 22: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
