Quick Installation Guide
TEG-S160TX
TEG-S240TX

Advertisement

loading
Need help?

Need help?

Do you have a question about the TEG-S240TX and is the answer not in the manual?

Questions and answers

Summary of Contents for TRENDnet TEG-S240TX

  • Page 1 Quick Installation Guide TEG-S160TX TEG-S240TX...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents English ... 1. Before You Start 2. Hardware Installation ... Technical Specifications ... Troubleshooting ... Version 05.11.2006...
  • Page 3: English

    An environment that is free from strong electromagnetic field generators (such as motors), vibration, dust and direct exposure to sunlight Leave at least 10 cm of space at the front and rear of the Switch for ventilation EIA Standard, 19 inch rack or sturdy, level surface that can support the...
  • Page 4: Hardware Installation

    2. Hardware Installation 1. Connect the AC Power Adapter to the TEG-S160TX/TEG-S240TX and then to a power outlet. 2. Connect a CAT-5e or CAT-6 RJ-45 network cable from the computer to an available Ethernet port on the TEG-S160TX/TEG-S240TX. English...
  • Page 5 Rack Mount The Switch can be mounted in an EIA standard-size, 19-inch rack, which can be placed in a wiring closet with other equipment. 3. Attach the mounting brackets to the Switch's front panel (one on each side), and secure them with the provided screws.
  • Page 6: Technical Specifications

    Power 100-240V AC Universal, 50/60 Hz Internal Power Supply Power 13.5 Watts. Max (TEG-S160TX) Consumption 19 Watts Max (TEG-S240TX) Operating: 0° ~ 40° C (32° ~ 104° F) Temperature Storage: -10° ~ 70° C (14° ~ 158° F) Humidity 5% ~ 90% (non-condescending)
  • Page 7 10Mbps Ethernet: 14,880pps (packet per second) Packet Filtering/ 100Mbps Fast Ethernet: 148,800pps Forwarding Rate 1000Mbps Gigabit Ethernet: 1,488,000pps MAC Address Self-learning, auto-aging Learning: 340KB per device (TEG-S160TX) RAM Buffer 500KB per device (TEG-S240TX) Filtering Address 8K entries per device Table Performance...
  • Page 8: Troubleshooting

    Fourth, verify that you have file and printer sharing enabled. Please contact Microsoft support for more information. After I connect my PCs to the Switch, I can only get onto the Internet from one computer. The Switch was not designed to share Internet between multiple computers.
  • Page 9 Return Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to TRENDnet must be pre- authorized by TRENDnet with RMA number marked on the outside of the package, and...
  • Page 10 ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF TRENDNET’S PRODUCTS. TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S...
  • Page 11 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
  • Page 12 English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com 20675 Manhattan Place Torrance, CA 90501 Copyright ©2006. All Rights Reserved. TRENDnet.
