Air purifier
Air Purifier
ServiceManual
Philips Consumer Lifestyle
AC3210 AC3220 AC3221 AC4220 AC4221
Published by Philips Consumer Lifestyle
Printed in the Netherlands
© Copyright reserved
Subject to modification

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC3210 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips AC3210

Summary of Contents for Philips AC3210

  • Page 1 Air purifier Air Purifier ServiceManual Philips Consumer Lifestyle AC3210 AC3220 AC3221 AC4220 AC4221 Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification...

  • Page 2: Change List

    Change List Version Detail Remark Date Owner Initial Service manual 2024.5.24 CC Chen Add service part list: EU: AC3210/12 AC3221/13 AC4220/12 2024.6.20 CC Chen UK: AC3220/10 AC4220/12 Change EU AC3220/10 Sensor cover 2024.7.10 CC Chen Assy PART Add service part list: KR: AC3220/10...

  • Page 3: Product Overview

    Product overview AC3210,AC3220,AC3221 AC4220, AC4221...
  • Page 4 AC3210 AC3220 AC3221...
  • Page 5 AC4220 AC4221...
  • Page 6 AC3210,AC3220,AC3221 Main PCBA Sensor PCBA light PM sensor...
  • Page 7 AC4220, AC4221 Sensor PCBA sensor Main PCBA LED light...

  • Page 8: Safety Precautions

    Safety precautions ◆ This manual is only for maintenance professionals r eference. ◆ Non-professionals do not disassemble the machine, So as not to cause injury to the a dultbody ◆ Please turn off and unplug the power cord when the appliance is m aintained. ◆...

  • Page 9: Disassembly Instruction

    DISASSEMBLY INSTRUCTION Before you start dismantling! For your safety be sure the plug is disconnected from the mains! If installation, perform the reverse operation, then test the basic functions accordingly. 1.Take the Front cover out and remove two Filters. 2.Remove five screws from the base, take out the base cover , three filter balls and three springs, then remove DC cover and 2pcs screws.
  • Page 10 DISASSEMBLY INSTRUCTION 4. Take out the sensor and remove two screws from the temperature and humidity sensor, then take out the cable of the sensor and remove 8pcs screws from lower filter housing. 5. Remove 8pcs screws from the upper filter housing and the related parts. 6.
  • Page 11 DISASSEMBLY INSTRUCTION 8. Remove 3cs screws from the Rubber buffer and take out the cable of motor and Impeller bracket. 9. Remove 6pcs screws from the top cover and take out the Light Guide. 10. Remove 4pcs screws from the control board and take out the Light ring band.
  • Page 12 AC3210,AC3220,AC3221...
  • Page 13 SERVICE PART LIST Unicorn Mono AC3210/12 EU (688001001383) Item Philips 12NC PCM CODE Part Name-English 1,2,3,4 642001016559 12880121CNOC16 UI panel ASSY AC3210/12 EU 642001016560 8001001383 Control PCBA WITH WIRE AC3210/12 EU 642001015125 30409060329 Light ring band 642001015126 22880NC8001 Light Guide...
  • Page 14 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 15 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 16 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 17 SERVICE PART LIST Unicorn Mono AC3210/12 UK (688001002078) Item Philips 12NC PCM CODE Part Name-English 1,2,3,4 642001016559 12880121CNOC16 UI panel ASSY AC3210/12 UK 642001017916 8001002078 Control PCBA AC3210/12 UK 642001015125 30409060329 Light ring band 642001015126 30103TP0173 Light Guide 642001016561 22880GY8009...
  • Page 18 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 19 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 20 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 21 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 22 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 23 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 24 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 25 AC4220, AC4221...
  • Page 26 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 27 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 28 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 29 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015140 12880121CNOC10 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 30 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 31 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 32 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
  • Page 33 642001015138 30101BK1422 Impeller with 8MM shaft hole 300008362851 31606010001 Washer 642001015139 22880BK8004 Impeller bracket cover 20,21,22 642001015116 12880121CNOC02 Front housing assy (Philips Logo) 642001015143 22880BK8003 Impeller bracket 642001015144 30902010064 Double shaft motor 642001015145 30305070019 Motor bracket 642001015146 30111BK0107 Rubber buffer...
